– 35 –
IM-MT899H/IM-MT899W
7
8 9 10 11 12
CN601
CN101
LIFT MOTOR
SPINDLE MOTOR
SLED MOTOR
OPTICAL PICKUP(19)
TO MAIN PWB
P32 4-C
MECHANISM
FLEXIBLE
PWB(17)
TO MAIN PWB
P32 5-E
MAGNETIC HEAD(18)
M902
M903
M901
Figure 35 WIRING SIDE OF P.W.BOARD (4/4)
