PRICE
RANK
DESCRIPTION
NO.
PART CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
IM-MT899H/IM-MT899W
– 3 –
R446 VRS-CZ1JB821J J AA 820 ohms,1/16W
R447 VRS-CZ1JB103J J AA 10 kohm,1/16W
R451 VRS-CZ1JB102J J AB 1 kohm,1/16W
R452 VRS-CZ1JB563J J AA 56 kohms,1/16W
R453,454 VRS-CZ1JB104D J AA 100 kohm,1/16W
R455 VRS-CZ1JB273J J AA 27 kohms,1/16W
R456 VRS-CZ1JB102J J AB 1 kohm,1/16W
R458 VRS-CZ1JB105J J AB 1 Mohm,1/16W
R461 VRS-CZ1JB104J J AA 100 kohm,1/16W
R462 VRS-CZ1JB223J J AB 22 kohms,1/16W
R463 VRS-CZ1JB104J J AA 100 kohm,1/16W
R464 VRS-CZ1JB274J J AB 270 kohms,1/16W
R492 VRS-CZ1JB102J J AB 1 kohm,1/16W
R495 VRS-CZ1JB222J J AB 2.2 kohms,1/16W
R501,502 VRS-CZ1JB471J J AA 470 ohms,1/16W
R507,508 VRS-CZ1JB471J J AA 470 ohms,1/16W
R511,512 VRS-CZ1JB471J J AA 470 ohms,1/16W
R701,702 VRS-CZ1JB101J J AB 100 ohm,1/16W
R703 VRS-CZ1JB104J J AA 100 kohm,1/16W
R704 VRS-CG1JF223J J AC 22 kohms,1/16W
R710 VRS-CZ1JB222J J AB 2.2 kohms,1/16W
R711,712 VRS-CZ1JB562J J AB 5.6 kohms,1/16W
R713,714 VRS-CZ1JB103J J AA 10 kohm,1/16W
R715,716 VRS-CZ1JB104J J AA 100 kohm,1/16W
R719,720 VRS-CZ1JB822J J AA 8.2 kohms,1/16W
R721 VRS-CZ1JB330J J AA 33 ohms,1/16W
R723,724 VRS-CZ1JB682J J AB 6.8 kohms,1/16W
R725 VRS-CZ1JB101J J AB 100 ohm,1/16W
R726 VRS-CZ1JB393J J AB 39 kohms,1/16W
R727 VRS-CZ1JB153J J AA 15 kohms,1/16W
R728 VRS-CZ1JB102J J AB 1 kohm,1/16W
R729,730 VRS-CZ1JB222J J AB 2.2 kohms,1/16W
R731 VRS-CG1JF473J J AC 47 kohms,1/16W
R754 VRS-CZ1JB184J J AB 180 kohms,1/16W
R757 VRS-CZ1JB272J J AB 2.7 kohms,1/16W
R758 VRS-CZ1JB101J J AB 100 ohm,1/16W
R761 VRS-CZ1JB394J J AA 390 kohms,1/16W
R762 VRS-CZ1JB104J J AA 100 kohm,1/16W
R765,766 VRS-CZ1JB150J J AB 15 ohms,1/16W
R800 VRS-CZ1JB104J J AA 100 kohm,1/16W
R801 VRS-CZ1JB473J J AA 47 kohms,1/16W
R802 VRS-CZ1JB104J J AA 100 kohm,1/16W
R803 VRS-CZ1JB101J J AB 100 ohm,1/16W
R804 VRS-CZ1JB334J J AA 330 kohms,1/16W
R805 VRS-CZ1JB105J J AB 1 Mohm,1/16W
R806,807 VRS-CZ1JB104J J AA 100 kohm,1/16W
R808 VRS-CZ1JB564J J AA 560 kohms,1/16W
R809 VRS-CZ1JB473J J AA 47 kohms,1/16W
R810 VRS-CZ1JB223J J AB 22 kohms,1/16W
R812 VRS-CZ1JB474J J AB 470 kohms,1/16W
R813 VRS-CZ1JB103J J AA 10 kohm,1/16W
R814 VRS-CZ1JB273J J AA 27 kohms,1/16W
R815 VRS-CZ1JB474J J AB 470 kohms,1/16W
R816,817 VRS-CZ1JB104J J AA 100 kohm,1/16W
R818 VRS-CZ1JB473J J AA 47 kohms,1/16W
R819 VRS-CZ1JB472J J AB 4.7 kohms,1/16W
R821 VRS-CZ1JB222J J AB 2.2 kohms,1/16W
R822 VRS-CZ1JB104J J AA 100 kohm,1/16W
R823 VRS-CZ1JB274J J AB 270 kohms,1/16W
R824 VRS-CZ1JB103J J AA 10 kohm,1/16W
R825 VRS-CZ1JB274D J AK 270 kohms,1/16W
R827 VRS-CZ1JB274D J AK 270 kohms,1/16W
R828 VRS-CZ1JB222J J AB 2.2 kohms,1/16W
R829 VRS-CZ1JB104J J AA 100 kohm,1/16W
R831 VRS-CZ1JB184D J AB 180 kohms,1/16W
R832 VRS-CZ1JB154D J AA 150 kohms,1/16W
R834 VRS-CZ1JB824D J AB 820 kohms,1/16W
R836 VRS-CZ1JB184D J AB 180 kohms,1/16W
R837 VRS-CZ1JB154D J AA 150 kohms,1/16W
R838 VRS-CZ1JB105D J AA 1 Mohm,1/16W
R841 VRS-CZ1JB104J J AA 100 kohm,1/16W
R842 VRS-CZ1JB100J J AB 10 ohm,1/16W
R850 VRS-CZ1JB104J J AA 100 kohm,1/16W
R853 VRS-CZ1JB274J J AB 270 kohms,1/16W
R854 VRS-CZ1JB103J J AA 10 kohm,1/16W
R855 VRS-CZ1JB224D J AA 220 kohms,1/16W
R856 VRS-CZ1JB155J J AA 1.5 Mohms,1/16W
R857 VRS-CZ1JB564D J AA 560 kohms,1/16W
R870 VRS-CZ1JB684J J AB 680 kohms,1/16W
R871 VRS-CZ1JB103J J AA 10 kohm,1/16W
R881 VRS-CZ1JB183J J AA 18 kohms,1/16W
R882 VRS-CZ1JB103J J AA 10 kohm,1/16W
R884,885 VRS-CZ1JB103J J AA 10 kohm,1/16W
R886 VRS-CZ1JB562J J AB 5.6 kohms,1/16W
R887~889 VRS-CZ1JB102J J AB 1 kohm,1/16W
R890 VRS-CZ1JB124J J AB 120 kohms,1/16W
R904 VRS-CZ1JB103J J AA 10 kohm,1/16W
R905 VRS-CZ1JB104J J AA 100 kohm,1/16W
R906 VRS-CZ1JB274J J AB 270 kohms,1/16W
R907 VRS-CZ1JB124J J AB 120 kohms,1/16W
R908 VRS-CZ1JB104J J AA 100 kohm,1/16W
R909 VRS-CZ1JB103J J AA 10 kohm,1/16W
R920 VRS-CZ1JB104J J AA 100 kohm,1/16W
RA01 VRS-CY1JB152J J AA 1.5 kohms,1/16W
RA02 VRS-CY1JB222J J AA 2.2 kohms,1/16W
RA03 VRS-CY1JB332J J AA 3.3 kohms,1/16W
RA04 VRS-CY1JB682J J AA 6.8 kohms,1/16W
RA05 VRS-CY1JB123J J AA 12 kohms,1/16W
RA06 VRS-CY1JB333J J AA 33 kohms,1/16W
OTHER CIRCUITRY PARTS
CN101 QCNCW046XAWZZ J AM Socket,22Pin
CN451 QCNCW862PAFZZ J AG Socket,14Pin
CN601 QCNCW862LAFZZ J AF Socket,11Pin
CNA01 QCNCW047GAWZZ J AF Socket,7Pin
1 F301 QFS-L631AAWNZ J AE Square Tip Type Fuse,630mA
FPC01 ———— — Flexible PWB (PWB-B)
J701 VHLGP1FD202-1 J AT Jack,Optical/Line
J702 QJAKM0018AWZZ J AG Jack,Mic In
J703 QJAKM0015AWZZ J AL
Jack,Remote Control/Headphones
J801 QJAKC0008AWZZ J AE Jack,DC IN
JK301 QJAKZ0017AWZZ J AH Jack,USB
M901 RMOTV0044AWZZ J AW Motor Ass’y [Spindle]
M902 RMOTS0002AWZZ J AT Motor Ass’y [Sled]
M903 RMOTV0033AWZZ J AW Motor Ass’y [Lift]
SW401 QSW-M0010AWZZ J AE Switch,Key Type [Eject]
SW402 QSW-M0010AWZZ J AE Switch,Key Type [Open/Close]
SW901 QSW-M0013AWZZ J AF Switch,Push Type [Disc Protect]
SWA01 QSW-K0237AFZZ J AC Switch,Key Type [Record]
SWA02 QSW-K0237AFZZ J AC Switch,Key Type [Play]
SWA03 QSW-K0237AFZZ J AC Switch,Key Type [Stop]
SWA04 QSW-K0237AFZZ J AC Switch,Key Type [Skip Up]
SWA05 QSW-K0237AFZZ J AC Switch,Key Type [Skip Down]
SWA06 QSW-K0237AFZZ J AC Switch,Key Type [Volume +]
SWA07 QSW-K0237AFZZ J AC Switch,Key Type [Volume -]
SWA08 QSW-K0237AFZZ J AC Switch,Key Type [Mode]
SWA09 QSW-K0237AFZZ J AC Switch,Key Type
[Synchronised Recording]
MD MECHANISM PARTS
1 LANGK0211AWZZ J AC Shaft Guide
2 LANGK0283AWZZ J AD Pickup Guide
3 LCHSM0134AWM1 J AN Chassis Ass’y
4 LHLDX3013AWM1 J AL Cartridge Holder Ass’y
5 MLEVF0084AWFW J AD Lever,Lift Link
6 MLEVF0085AWFW J AC Lever,Lift Move
7 MLEVF0086AWFW J AD Lever,Lift
8 MLEVF0087AWFW J AC Lever,Eject Protect
9 MSPRP0060AWFJ J AB Spring,Thrust
10 MSPRP0067AWFJ J AB Spring,Grip Rack
11 MSPRT0058AWFJ J AB Spring,Eject Lever
12 MSPRT0059AWFJ J AB Spring,Cancel Lever
13 NBRGC0004AWZZ J AB Metal
14 NGERH0096AWZZ J AC Gear,Drive
15 NGERH0125AWZZ J AB Wheel,Drive
16 NSFTD0011AWZZ J AG Shaft,Drive Screw
17 QPWBH0018AWZZ J AH Mechanism Flexible PWB
18 RCILH0003AWM1 J AT Magnetic Head Unit
1 19 92LHPM280 J BT Optical Pickup Unit
501 LX-BZ0049AWZZ J AB Screw,ø1.4×1.8mm
502 LX-BZ0050AWZZ J AB Screw,ø1.4×2.5mm
503 LX-BZ0051AWZZ J AB Screw,ø1.4×3.8mm
504 LX-BZ0059AWZZ J AB Screw,ø1.4×1.8mm
505 LX-BZ0079AWZZ J AB Screw,ø1.4×1.2mm
506 LX-BZ0823AFZZ J AA Screw,ø1.4×1.2mm
507 LX-BZ0979AFZZ J AB Screw,ø1.4×1.8mm
508 LX-WZ9290AFZZ J AA Washer,ø0.8×ø2.4×0.2mm
M901 RMOTV0044AWZZ J AW Motor,Ass’y [Spindle]
M902 RMOTS0002AWZZ J AT Motor,Ass’y [Sled]
M903 RMOTV0033AWZZ J AW Motor,Ass’y [Lift]
