11
Removing the Front Panel
Remove the front panel of the solar power inverter.
(1) Remove the 4 screws from the lower part of the front panel of the solar power inverter.
Then remove the front panel.
(2) The four glands shown below should be used for the purpose indicated. If there are any
unused or open glands, they should be covered.
Screws
Screws
(Front)
DC Disconnect
(PV Strings)
AC Disconnect
To Next Page
