30
KB-6524PS
KB-6524PK
KB-6524PW
REF. NO. PART NO. DESCRIPTION Q'TY CODE
4-27 PDUC-B182MRF0 SENSOR DUCT 1 AR
4-28 PDUC-B183MRF0 EXHAUST DUCT 1 AR
4-29 PFILWB005MRP0 LAMP FILTER 1 AB
4-30 PSKR-B026MRP0 PARTITION AG BOTTOM 1 AM
4-31 PSKR-B027MRP0 PARTRITION AG REAR 1 AM
4-32 PHOK-B030MRF0 LATCH HOOK R 1 AG
4-33 PHOK-B031MRF0 LATCH HOOK L 1 AG
DOOR PARTS
5-1 DDORFB145MRK0 DOOR ASSY 24” [KB-6524PS] 1 BX
5-1 DDORFB146MRK0 DOOR ASSY 24” [KB-6524PK] 1 BX
5-1 DDORFB147MRK0 DOOR ASSY 24” [KB-6524PW] 1 BX
5-1 DDORFB148MRK0 DOOR ASSY 30” [KB-6525PS] 1 BY
5-1 DDORFB149MRK0 DOOR ASSY 30” [KB-6525PK] 1 BY
5-1 DDORFB150MRK0 DOOR ASSY 30” [KB-6525PW] 1 BY
5-1-1 FCOV-B470MRK0 DOOR FRAME ASSY 24” [KB-6524PS] 1 BT
5-1-1 FCOV-B471MRK0 DOOR FRAME ASSY 24” [KB-6524PK] 1 BT
5-1-1 FCOV-B472MRK0 DOOR FRAME ASSY 24” [KB-6524PW] 1 BT
5-1-1 FCOV-B473MRK0 DOOR FRAME ASSY 30” [KB-6525PS] 1 BT
5-1-1 FCOV-B474MRK0 DOOR FRAME ASSY 30” [KB-6525PK] 1 BT
5-1-1 FCOV-B475MRK0 DOOR FRAME ASSY 30” [KB-6525PW] 1 BT
5-1-2 GCOVHB067MRF0 CHOKE COVER 24” [KB-6524PS/PK/PW] 1 AY
5-1-2 GCOVHB068MRF0 CHOKE COVER 30” [KB-6525PS/PK/PW] 1 AY
5-1-3 LSTPPB062MRF0 LATCH HEAD R 1 AL
5-1-4 LSTPPB063MRF0 LATCH HEAD L 1 AL
5-1-5 MSPRTB035MRE0 LATCH SPRING 2 AD
5-1-6 XCTS740P12000 SCREW 2 AB
5-1-7 PSHEPB255MRE0 SEALER FILM 1 AM
5-1-8 LX-HZB001MRE0 SPECIAL SCREW 2 AA
5-1-9 XCPS740P08000 M4 X 8 SCREW - TAP PAN HEAD (R 7 AB
5-1-10 XHTS740P25000 SCREW 2
AB
5-1-11 JHNDMB001MRE0 DOOR HANDLE [KB-6524PS] 1 BL
5-1-11 JHNDMB002MRT0 DOOR HANDLE [KB-6524PK] 1 BL
5-1-11 JHNDMB003MRT0 DOOR HANDLE [KB-6524PW] 1 BL
5-1-11 JHNDMB004MRE0 DOOR HANDLE [KB-6525PS] 1 BL
5-1-11 JHNDMB005MRT0 DOOR HANDLE [KB-6525PK] 1 BL
5-1-11 JHNDMB006MRT0 DOOR HANDLE [KB-6525PW] 1 BL
5-1-12 PSPA-B006MRF0 DOOR HANDLE MOUNT [KB-6524PS/PK] [KB-6525PS/PK] 2 AU
5-1-12 PSPA-B007MRF0 DOOR HANDLE MOUNT [KB-6524PW] [KB-6525PW] 2 AU
5-1-13 XHTS740P12000 SCREW 2 AB
MISCELLANEOUS
6-1 TINSEB518MRK0 OP MANUAL ASSY 1 AM
6-2 TINSEB519MRR0 INSTALLATION INSTRUCTIONS 1 AA
6-3 XTPS740P20000 WOOD SCREW (M4 X 20, PANHEAD) 4 AA
6-4 TCAUAB048MRR0 DHHS/GRD/CAUTION LABEL 1 AD
6-5 TCAUAB050MRR0 MONITOR CAUTION LABEL 2 AD
6-6 TCAUAB059MRR0 CONSUMER WARNING LABEL 1 AA
6-7 TCAUHB009MRR0 USER CAUTION LABEL - ENG./NO P 1 AA
6-8 TCAUKB001MRR0 WAVEGUIDE COVER CLEANING LABEL 1 AA
6-9 TLAB-B074MRR0 MENU LABEL 1 AP
6-10 TMAPCB122MRR0 SCHEMATIC DIAGRAM 1 AC
SCREWS, NUTS, AND WASHERS
7-1 LX-BZA041WRE0 M4-POINTED-8 11
AA
7-2 LX-CZ0052WRE0 SCREW WITH WASHER 2 AA
7-3 LX-CZA084WREZ SCREW 3
AA
7-4 LX-CZA107WREZ SCREW WITH WASHER 2 AA
7-5 LX-NZB006MRE0 CAP NUT 2 AA
7-6 LX-NZB012MRE0 CAP NUT 4 AA
7-7 XCBS730P08000 M3 X 8 SCREW - TAP BINDING HEA 4 AB
7-8 XOTS740P12RV0 M4 X 12 SCREW - COMMON (RoHS) 8 AB
7-9 XEPS730P10XS0 M3 X 10 SCREW - STEEL P-TIGHT 7 AC
7-10 XHPS740P08K00 SCREW: 4MM X 8MM 5 AB
7-11 XHTS740P06000 4x6mm SCREW 2 AC
7-12 XHTS740P08000 M4 X 8 SCREW - T TAP TRUSS (Ro 5 AD
7-13 XOTS740P12000 CABINET SCREW/ CLEAR (RoHS) 58 AB
DRAWER & CONTROL PANEL
