E-17
ENGLISH
SYMPTOM REMEDY (not a malfunction)
When the Roller / Float was removed.
• Install the Roller / Float in order below.
AUTO RESTART
After a power failure, automatically resume
the operation when the power recovers.
Auto Restart can be set.
• Even when the plug is unplugged or the breaker
is thrown during the operation, the operation
resumes at the previous operation mode and
settings if the power recovers.
FLOAT
ROLLER
1. Insert the oat under
this tab.
2. Inner the tab
of oat into
the hole.
3. Insert the tab on the other
side of the oat into the
hole.
Fix the roller in the tray from side way.
NOTE
Check the direction
of the roller.
Float
Tab
Float
Cross-Section view
(with the unit OFF)
ON
(with the unit OFF)
CANCELLATION
(simultaneously for more 3 sec.)
If the , , lamp lights up
for 10 seconds, the setting is
complete.
(simultaneously for more 3 sec.)
KC-A60E_A50E_A40E.indd 17 11.5.11 2:41:44 PM
