②
③
①
E-12
CARE INDEX
In case operating at the “MEDIUM” wind volume, the Indicator Light will turn on after approximately
720 hours. (30days×24hours=720)
(The lighting time will vary between approximately 360-1080 hours depending on the wind volume.)
Reminder to perform maintenance of parts below.
After performing maintenance, reset the Filter Indicator. (Ref. E-13)
HUMIDIFYING DISINSTALLATION
frame colour : gray
After maintenance, replace the parts accurately.
FILTER INDICATOR
• Notice an unpleasant odour from the air
outlet.
• Filter performance appears fall and / or
odour persist.
more than 3 sec.
Humidifying Filter
(Ref. E-13)
Water Tank
(Ref. E-13)
Humidifying Tray
(Ref. E-14)
• Filter Indicator Light turn on.
Unit (Ref. E-15)
Back Panel
(Ref. E-14)
Deodorizing Filter
(Ref. E-15)
HEPA Filter
(Ref. E-15)
CARE AND MAINTENANCE
KC-D60-50-40EU_WEST.indb 12 2017-02-22 15:33:00
