Sharp KS-1800 - Page 12

12
Fig. 16
Thermostat rod
Outer pot hole
Switch leg ass’y
Center of outer pot
Lever to be swung
symmetrically
Stop ring
Switch leg ass’y
Thermostat rod
Fig. 17
Temperature test
Based on the temperature testing method explained earlier ensure proper performance for “COOK” and “WARM”.
Inner pot
Outer pot ass’y
Work bench
Fig. 14
Fig. 15
Thermostat ass’y
Outer pot ass’y
Inner pot
Heater plate ass’y
Inner pot to be normally in contact with
