Sharp LC-13SH1E Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
62
LC-13SH1E
LC-15SH1E
Ref. No. Part No. ★ Description Code
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by
å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which does no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
★ MARK: SPARE PARTS-DELIVERY SECTION
LCD PANEL
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
LC-13SH1E
DUNTKC857WE06 – SUB Unit —
DUNTKC858WE06 – OPERATION Unit —
DUNTKC859WE06 – R/C,LED Unit —
DUNTKC860FM05 – MAIN Unit —
LC-15SH1E
DUNTKC857WE05 – SUB Unit —
DUNTKC858WE05 – OPERATION Unit —
DUNTKC859WE05 – R/C,LED Unit —
DUNTKC860FM04 – MAIN Unit —
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
RLCDTA023WJZZ J 13" LCD Panel Unit CQ
(LC-13SH1E)
RLCDTA024WJZZ J 15" LCD Panel Unit CT
(LC-15SH1E)
DUNTKC857WE06 (LC-13SH1E)
DUNTKC857WE05 (LC-15SH1E)
SUB UNIT
INTEGRATED CIRCUITS
IC3301 VHiAN17821A-1 J AN17821A AH
IC7701 VHiSTRW67652E J I.C. AL
å IC7702 RH-FXA003WJZZ J PC123Y82 AD
å IC7703 RH-FXA003WJZZ J PC123Y82 AD
IC7704 VHiSE005N++-F S I.C. AF
IC7705 VHiKA7809AP-1 J KIA7809API AE
IC7706 VHiPQ050ES1-1+ J PQ050ES1MXP AE
TRANSISTORS
Q3305 VS2SC3928AR-1Y J 2SC3928AR AB
Q3600 VSKRC102S//-1Y J KRC102S AA
Q3601 VSKRC102S//-1Y J KRC102S AA
Q3901 VS2SA1530AR-1Y J 2SA1530AR AB
Q3902 VS2SA1530AR-1Y J 2SA1530AR AB
Q3903 VS2SC3928AR-1Y J 2SC3928AR AB
Q3904 VS2SD1306-E-1Y J 2SD1306 AC
Q3905 VS2SD1306-E-1Y J 2SD1306 AC
Q3906 VS2SD1306-E-1Y J 2SD1306 AC
Q3907 VS2SD1306-E-1Y J 2SD1306 AC
Q3908 VS2SA1530AR-1Y J 2SA1530AR AB
Q3909 VS2SC3928AR-1Y J 2SC3928AR AB
Q6700 VS2SC6000++-1Y S 2SC6000 AD
Q6701 VS2SC6000++-1Y S 2SC6000 AD
Q6702 VS2SA1530AR-1Y J 2SA1530AR AB
Q6706 VSUPA606T//-1Y J UPA606T AD
Q6707 VS2SC6000++-1Y S 2SC6000 AD
Q6708 VS2SC6000++-1Y S 2SC6000 AD
Q6709 VS2SA1530AR-1Y J 2SA1530AR AB
Q6713 VSUPA606T//-1Y J UPA606T AD
Q7701 VS2SA1013//1E+ J 2SA1013 AD
Q7702 VSKRC104S//-1Y J KRC104S AA
Q7703 VS2SB1443TV1E+ J 2SB1443TV AE
Q7704 VS2SB1443TV1E+ J 2SB1443TV AE
Q7706 VSKRC101S//-1Y S KRC101S AA
Q7707 VSKRC104S//-1Y J KRC104S AA
Q7708 VS2SC2235Y/1E+ J 2SC2235Y AE
Q7710 VSKRA102S//-1Y J KRA102S AA
Q7711 VS2SB1443TV1E+ J 2SB1443TV AE
Q7712 VSKRC104S//-1Y J KRC104S AA
Q7713 VS2SA1530AR-1Y J 2SA1530AR AB
Q7714 VSKRC102S//-1Y J KRC102S AA
DIODES
D3300 VHDDAN202K/-1Y J Diode AB
D3604 RH-EX0652GEZZY J Zener Diode AB
D3605 RH-EX0652GEZZY J Zener Diode AB
D3901 VHDDAN202K/-1Y J Diode AB
D3903 VHD1SS119//-1Y J Diode AA
D3908 RH-EX0630GEZZY J Zener Diode, 9.1V AA
D3911 RH-EX0630GEZZY J Zener Diode, 9.1V AA
D3912 RH-EX0630GEZZY J Zener Diode, 9.1V AA
D3913 RH-EX0630GEZZY J Zener Diode, 9.1V AA
D3914 RH-EX0630GEZZY J Zener Diode, 9.1V AA
D3915 RH-EX0630GEZZY J Zener Diode, 9.1V AA
D3916 RH-EX1244CEZZY J Zener Diode AB
D3917 RH-EX1244CEZZY J Zener Diode AB
D5000 RH-EX0630GEZZY J Zener Diode, 9.1V AA
D5001 RH-EX0630GEZZY J Zener Diode, 9.1V AA
D5002 RH-EX0630GEZZY J Zener Diode, 9.1V AA
D6701 VHD1SS355//-1Y J Diode AB
D6703 VHD1SS355//-1Y J Diode AB
D6705 VHDDAN202K/-1Y J Diode AB
D6707 VHDDAN202K/-1Y J Diode AB
D6710 VHDMA157A//-1Y J Diode AC
D6712 VHDMA157A//-1Y J Diode AC
D6715 VHDMA157A//-1Y J Diode AC
D6716 VHDMA157A//-1Y J Diode AC
D7701 RH-DX0476CEZZ J Diode AG
D7703 VHDSF30JC6+1E S Diode AG
D7705 RH-DX0490CEZZY J Diode AC
