Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
71
LC-13SH1E
LC-15SH1E
CABINET AND MECHANICAL PARTS
(LC-13SH1E)
1 CCABAA755WJ01 S Cabinet A Ass’y AZ
1-1
Not Available
– Cabinet A —
1-2 HDECQA452WJSA S R/C, LED Cover
1-3 HDECQA459WJSA S LED Cover
1-4 HDECQA478WJSA S Leg Cover, x2
1-5 XEBSN30P08000 J Screw, x1 AA
2 CCABBA485WJ01 S Cabinet B Ass’y BB
2-1
Not Available
– Cabinet B —
2-2 GLEGGA042WJZZ S Rubber Leg, x2
2-3 LANGFA085WJFW J Kensington Angle AC
2-4 LANGTA159WJFW S Reinforcement Angle
2-5 PZETKA109WJZZ S Insulating Spacer, x1
2-6 XEBSN30P08000 J Screw, x1 AA
3 CDAi-A154WJ01 S Stand Ass’y BB
3-1 CDAi-A154WJ02 S Stand Base Ass’y
3-1-1 GDAi-A154WJSA S Stand Base
3-1-2 GLEGGA041WJSA S Rubber Leg, x2
3-1-3 PSPAZA083WJZZ J Spacer, x2 AB
3-2 GCOVAB023WJSA S Stand Cover
3-3 XESSN40P10000 J Screw, x8 AB
4 CCOVAB201WJ01 S Top Cover Ass’y AP
4-1
Not Available
– Top Cover —
4-2 JBTN-A353WJSA S Operation Button
4-3 JBTN-A354WJSA S Power Button
4-4 MSPRCA014WJFW J Spring, for Power Button AB
4-5 XEBSN30P08000 J Screw, x1 AA
5
Not Available
– 13" LCD Panel Unit Ass’y —
5-1 RLCDTA023WJZZ J 13" LCD Panel Unit CQ
5-2
Not Available
– Back Shield Ass’y —
5-2-1 PSLDMA542WJFW J Back Shield
5-2-2 LHLDZA429WJKZ J Lamp Holder-R(Bottom) AF
5-2-3 LHLDZA435WJKZ J Lamp Holder-L(Bottom) AF
5-2-4 PSHEPA229WJZZ J Reflection Sheet AK
5-2-5 TCAUZA031WJZZ J Caution Label AB
5-2-6 PMLT-A149WJZZ J Light Shielding Spacer, x2 AB
å 5-3 KLMP-A048WJZZ J Lamp Unit, x4 AV
5-4 LHLDZA433WJKZ J Lamp Holder-R(Top) AH
5-5 LHLDZA434WJKZ J Lamp Holder-L(Top) AH
5-6 LX-BZA084WJF7 J Screw, x4 AA
5-7 PCOVUA047WJZZ J Diffusion Plate, x1 AT
5-8 PSHEPA230WJZZ J Diffusion Sheet, x2 AH
6 GCOVAA984WJKA S Bass-Conne Cover AD
7 LCHSMA146WJKA S Chassis Frame AR
8 LX-BZ3442CEF9 J Screw, x4 AB
9 PSPAZA640WJKZ S Spacer, x1 AL
10 PSPAZA641WJKZ S Spacer, x1 AF
11 PSPAZA642WJKZ S Spacer, x1 AH
12 QCNW-D115WJQZ S Connecting Cord AE
13 QCNW-D228WJQZ S Connecting Cord AD
14 QCNW-D229WJQZ S Connecting Cord AB
15 QCNW-D231WJQZ S Connecting Cord AC
16 QCNW-D362WJQZ S Connecting Cord AC
17 QCNW-D363WJQZ S Connecting Cord AC
18 QEARPA132WJFW S Grounding Part, x1 AC
19 TLABMB319WJZZ S Model Label AD
(LC-13SH1E/E(F)/E(K)/E(R))
19 TLABMB475WJZZ S Model Label(LC-13SH1E(I)) AF
20 TLABNB105WJZZ S EICTA Label AA
21
Not Available
– Serial No. Label —
22 VSP7530PB678B J Speaker, x2 AL
24 XEBS930P14000 J Screw, x5 AA
25 XHBS830P10000 S Screw, x1 AA
26 XHPS730P08WS0 J Screw, x4 AA
27 XEBSN30P08000 J Screw, x15 AA
29 TLABSA029WJZZ J GOST Label AF
(LC-13SH1E(R))
30 RCORFA032WJZZ J Ferrite Core AK
35 GCOVHA069WJKA S AC Holder AE
36 LHLDK0002PEK0 J AC Cord Holder AA
å 37 QACCZA019WJPZ J AC Cord (LC-13SH1E/E AH
(F)/E(I)/E(R))
å 38 QACCBA024WJPZ J AC Cord (LC-13SH1E(K)) AS
To Next Page
