Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
74
LC-13SH1E
LC-15SH1E
å X1 QACCBA016WJPZ J AC Cord (LC-15SH1E(K)) AR
å X1 QACCKA006WJPZ J AC Cord (LC-15SH1E/E AL
(F)/E(I)/E(R))
X2 RRMCGA339WJSA S Wireless Remote Control AS
X3 TiNS-B517WJN2 S Operation Manual
X4 TiNS-B634WJN2 S Instruction Book(LC-13SH1E/
E(F), LC-15SH1E/E(F))
X5 TiNS-B635WJN2 S Instruction Book(LC-13SH1E,
LC-15SH1E)
X6 TiNS-B800WJZZ S Instruction Book(LC-13SH1E AL
(R), LC-15SH1E(R))
X7 TGAN-1688CEN1 J Guarantee Card(LC-13SH1E AN
(K), LC-15SH1E(K))
X8 TGAN-A077WJZZ J Guarantee Card(LC-13SH1E AE
(R), LC-15SH1E(R))
X9 Not Available – "AA" Size Battery, x2 —
SUPPLIED ACCESSORIES
SERVICE JIGS
(USE FOR SERVICING)
PACKING PARTS
(NOT REPLACEMENT ITEM)
S1 SPAKCB717WJZZ – Packing Case(LC-15SH1E) —
S1 SPAKCB718WJZZ – Packing Case(LC-13SH1E) —
S2 SPAKPA465WJZZ – Wrapping Paper —
(LC-15SH1E)
S2 SPAKPA466WJZZ – Wrapping Paper —
(LC-13SH1E)
S3 SPAKXA655WJZZ – Buffer Material(LC-15SH1E) —
S3 SPAKXA656WJZZ – Buffer Material(LC-13SH1E) —
S4 SSAKAA010WJZZ – Polyethylene Bag,(E(I)/E(K)/ —
E(R)x1, E(F)x2, Ex3)
S5 TLABKA002WJZZ – Carton Label —
S6 TLABSA029WJZZ – GOST Label —
(LC-13SH1E(R), LC-15SH1E(R))
QCNW-A553WJZZ J Extension Cable, 30-pin BA
(SC1203-LCD)
QCNW-A556WJZZ J Extension Cable, 50-pin AU
(SC1202-LCD)
QCNW-A555WJZZ J Extension Cable, 20-pin AU
(SC1201-LCD)
QCNW-D444WJQZ J Extension Cable, 5-pin AQ
(SC4201-SC105)
QCNW-D445WJQZ J Extension Cable, 8-pin AQ
(SC4001-SC3601)
JiGiNF-001 J Parallel Part-IIC CC
Interface Jig
Supplied Accessories
Wireless remote control
Operation manual
“AA” size batteries (×2)
AC cord
*Product shape may vary
from country to country.
LC-13SH1E
LC-15SH1E
LC-20SH1E
X2X1 X3 X9
