18
LC-13AV6U
Page No. Item
Initial
Function
Response precautions on servicing
Value (Do not change other items than designated.)
AUDIO ADJUSTMENT
SOUND3 BAND1 MIN TV -0400 EQUALIZER SETTING (WITH TV INPUT) Change to -700
OTHER -0400 EQUALIZER SETTING (WITH OTHER INPUT THAN TV) Change to -700
BAND1 CNT TV +0400 EQUALIZER SETTING (WITH TV INPUT) Change to +100
OTHER +0400 EQUALIZER SETTING (WITH OTHER INPUT THAN TV) Change to +100
BAND1 MAX TV +1200 EQUALIZER SETTING (WITH TV INPUT) Change to +900
OTHER +1200 EQUALIZER SETTING (WITH OTHER INPUT THAN TV) Change to +900
BAND2 MIN TV -0400 EQUALIZER SETTING (WITH TV INPUT) Change to -200
OTHER -0400 EQUALIZER SETTING (WITH OTHER INPUT THAN TV) Change to -200
BAND2 CNT TV -0100 EQUALIZER SETTING (WITH TV INPUT) Change to +100
OTHER -0100 EQUALIZER SETTING (WITH OTHER INPUT THAN TV) Change to +100
BAND2 MAX TV +0200 EQUALIZER SETTING (WITH TV INPUT) Change to +400
OTHER +0200 EQUALIZER SETTING (WITH OTHER INPUT THAN TV) Change to +400
BAND3 MIN TV -0250 EQUALIZER SETTING (WITH TV INPUT) Change to -150
OTHER -0250 EQUALIZER SETTING (WITH OTHER INPUT THAN TV) Change to -150
AUDIO ADJUSTMENT
SOUND4 BAND4 MIN TV +0150 EQUALIZER SETTING (WITH TV INPUT) Change to -600
OTHER +0150 EQUALIZER SETTING (WITH OTHER INPUT THAN TV) Change to -600
BAND4 CNT TV +0450 EQUALIZER SETTING (WITH TV INPUT) Change to -300
OTHER +0450 EQUALIZER SETTING (WITH OTHER INPUT THAN TV) Change to -300
BAND4 MAX TV +0750 EQUALIZER SETTING (WITH TV INPUT) Change to 0
OTHER +0750 EQUALIZER SETTING (WITH OTHER INPUT THAN TV) Change to 0
BAND5 MIN TV -0525 EQUALIZER SETTING (WITH TV INPUT)
NOT USED
OTHER -0525 EQUALIZER SETTING (WITH OTHER INPUT THAN TV)
NOT USED
BAND5 CNT TV +0275 EQUALIZER SETTING (WITH TV INPUT)
NOT USED
OTHER +0275 EQUALIZER SETTING (WITH OTHER INPUT THAN TV)
NOT USED
BAND5 MAX TV +1075 EQUALIZER SETTING (WITH TV INPUT)
NOT USED
OTHER +1075 EQUALIZER SETTING (WITH OTHER INPUT THAN TV)
NOT USED
Page No. Item
Initial
Function
Response precautions on servicing
Value (Do not change other items than designated.)
VIDEO ADJUSTMENT PROCESS SPECIFICATIONS
VIDEO ADJUSTMENT
DVP1 DVP DATA 0000 F0 ------(----)
—
DVP-RELATED GENERAL-PURPOSE VARIABLE SETTINGS NOT USED
DVP TEST PATTERN 0 TEST PATTERN SELECT SEE THE ADJUSTMENT PROCESS MODE TEST PATTERNS.
VCDOFFSET 15 VERTICAL COUNT-DOWN MINIMUM OSCILLATION CYCLE NOT USED
VCDWINDOW 30 VERTICAL COUNT-DOWN SYNC RANGE NOT USED
VIDEO ADJUSTMENT
DVP3 N358 TV CONTRAST 128 IMAGE SETTING (TV) NOT USED
N358 AV CONTRAST 128 IMAGE SETTING (COMPOSITE, S VIDEO) NOT USED
N358 TV BRIGHT 128 BRIGHTNESS SETTING (TV) Change to 118
N358 AV BRIGHT 128 BRIGHTNESS SETTING (COMPOSITE, S VIDEO) Change to 118
N358 TV COLOR 40 COLOR DENSITY SETTING (TV) NOT USED
N358 AV COLOR 40 COLOR DENSITY SETTING (COMPOSITE, S VIDEO) NOT USED
N358 TV TINT 128 TINT SETTING (TV) Change to 140
N358 AV TINT 128 TINT SETTING (COMPOSITE, S VIDEO) Change to 155
N358 TV SHARP V 100 V PICTURE QUALITY SETTING (TV) NOT USED
N358 AV SHARP V 100 V PICTURE QUALITY SETTING (COMPOSITE, S VIDEO) NOT USED
N358 TV SHARP H1 150 H PICTURE QUALITY SETTING 1 (TV) NOT USED
N358 AV SHARP H1 150 H PICTURE QUALITY SETTING 1 (COMPOSITE, S VIDEO) NOT USED
N358 TV SHARP H2 130 H PICTURE QUALITY SETTING 2 (TV) NOT USED
N358 AV SHARP H2 150 H PICTURE QUALITY SETTING 2 (COMPOSITE, S VIDEO) NOT USED
