Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
76
LC-13AV6U
DIODES
D4201 RH-EX0610GEZZY J Zener Diode, 4.7V AA
D4202 RH-EX0610GEZZY J Zener Diode, 4.7V AA
D4203 RH-EX0610GEZZY J Zener Diode, 4.7V AA
D4204 RH-EX0610GEZZY J Zener Diode, 4.7V AA
RESISTORS
R4201 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R4202 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4203 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R4204 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4205 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
SWITCHES
S4201 QSW-P0614CEZZ J POWER AF
SW4202 QSW-K0003AJZZ+ J CH (Channel) (Ù)AB
SW4203 QSW-K0003AJZZ+ J CH (Channel) (ù)AB
SW4204 QSW-K0003AJZZ+ J INPUT AB
SW4205 QSW-K0003AJZZ+ J MENU AB
SW4206 QSW-K0003AJZZ+ J VOL (Volume) (+) AB
SW4207 QSW-K0003AJZZ+ J VOL (Volume) (–) AB
MISCELLANEOUS PARTS
SC4201 QSOCN0596REZZ J Socket, 5-pin AB
DUNTKD369WEF8
OPERATION Unit
TUNER
NOTE: THE PARTS HERES SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
TU1301 VTU115VUA05AH J Tuner AZ
INTEGRATED CIRCUITS
IC1003 VHiPQ018EH1-1Y J PQ018EH01ZPH AF
IC1004 RH-iXB150WJZZQ J R8A66605A02FP BG
IC1202 VHiBUF12800-1Y J BUF12800AIPWPR AL
IC1203 RH-iXA828WJZZY J BD9300FV-FE2 AH
IC1205 RH-iXA828WJZZY J BD9300FV-FE2 AH
IC1300 RH-iXB302WJN1Q J MSP3445G-QA-S1 AT
IC1301 VHiNJM2147M-1Y J NJM2147M-TE1 AF
IC1701 RH-iXB075WJZZQ J LR38875 AX
IC1702 VHiFSA4157+-1Y J FSA4157P6X AE
IC2001 VHiPQ1L333M-1Y J PQ1L333M2SP AD
IC2003 RH-iXA630WJN2Q J M30622MWP-273F AZ
IC2004 VHiPST3229N1EY J PST3229 AD
IC2005 VHiBR24L64F-1Y J BR24L64F-WE2 AK
TRANSISTORS
Q1000 VSFMMT718//-1Y J FMMT718 AE
Q1002 VS2SC3928AR-1Y J 2SC3928AR AB
Q1201 VSDTC144EE/-1Y J DTC144EE AA
Q1202 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q1207 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q1209 VSDTC144EE/-1Y J DTC144EE AA
Q1211 VSDTC144EE/-1Y J DTC144EE AA
Q1213 VSDTC144EE/-1Y J DTC144EE AA
Q1215 VSRSS040P03-1Y J RSS040P03 AE
Q1216 VSUML2N++++-1Y J UML2N AC
Q1217 VSDTC144EE/-1Y J DTC144EE AA
Q1218 VSFMMT718//-1Y J FMMT718 AE
Q1220 VSUML2N++++-1Y J UML2N AC
Q1221 VSUML1N++++-1Y J UML1N AC
Q1222 VSRHP020N06-1Y J RHP020N06 AD
Q1223 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q1224 VSDTC114EE/-1Y J DTC114EE AB
Q1300 VS2SC3928AR-1Y J 2SC3928AR AB
Q1301 VS2SC3928AR-1Y J 2SC3928AR AB
Q1302 VS2SC3928AR-1Y J 2SC3928AR AB
Q1303 VS2SB1695++-1Y J 2SB1695 AC
Q1305 VSiMZ1A////-1Y J IMZ1A AC
Q1306 VSiMZ1A////-1Y J IMZ1A AC
Q2001 VSDTC144EE/-1Y J DTC144EE AA
Q2002 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q2003 VSDTC144EE/-1Y J DTC144EE AA
DIODES
D1000 VHDDAN222//-1Y J Diode AA
D1201 VHDDAN222//-1Y J Diode AA
D1205 VHDRB521S30-1Y J Diode AC
D1206 VHDHSU119//-1Y J Diode AB
D1207 VHDHSU119//-1Y J Diode AB
D1209 VHDRB051L40-1Y J Diode AD
D1221 VHDRB051L40-1Y J Diode AD
D1300 VHDDAN222//-1Y J Diode AA
D1301 RH-EX1394CEZZY J Zener Diode, 5.6V AB
D1302 RH-EXA099WJZZY J Zener Diode, 24V AB
D1303 VHDDAN222//-1Y J Diode AA
CRYSTALS
X1000 RCRSCA097WJZZY J Crystal AG
X1300 RCRSB0250GEZZ J Crystal, 18.432MHz AG
FILTER AND COILS
FL2001 RFiLZA003WJPZY J Filter, 16MHz AD
L1001 VPCNN220J2R9NY J Peaking 22µH AB
L1201 VPCNN100J1R6NY J Peaking 10µH AB
L1202 VPCNN470J5R4NY J Peaking 47µH AB
DUNTKD424FMF8
MAIN Unit
