Part Names of Main Unit
The examples used throughout this manual are based on the LC-13AV6U model.
• INPUT, CH (
)/(
), VOL (–)/(+) and MENU on the main unit have the same functions as the same buttons on the remote control.
Fundamentally, this operation manual provides a description based on operation using the remote control.
Listening with Headphones
Plug the headphone mini-plug into the headphone jack
located on the side of the LCD TV set.
Adjust the sound volume using VOL (+)/(–) on the remote
control.
On-screen display
20
VOLUME
NOTE
NOTE
• Headphones are not included in the supplied accessories.
• No sound is heard from the main unit speakers when a
headphone mini-plug is connected into the headphone jack.
• Do not set the volume at a high level. Hearing experts advise
against extended listening at high volume levels.
Controls
Remote sensor
SLEEP TIMER indicator
The SLEEP TIMER indicator lights up red when the SLEEP TIMER
is set to "ON".
POWER indicator
The POWER indicator lights up green when the power is on, and
red when in the standby mode (the indicator will not light up when
the main power is off).
Upper control panel
14°
Table stand
Easel type
The angle of the LCD TV set has to be kept at 14° .
Caution:
• Be careful not to hurt your fingers with the stand.
• Do not pick up the LCD TV set by its stand.
• Securely unfold the easel type table stand until you
hear a clicking sound.
Only use the easel type table stand after first unfolding
until a clicking sound is heard to ensure that it is stable.
Easel type table stand
Speaker
POWER
INPUT
CH (Channel) (
)/( )
VOL (Volume) (–)/(+)
MENU
Terminals
How to Fix the Cables
Pull the cables connected to each terminal. Insert the cables into the stand hole and fix the cables.
Stand hole
Rear View
ANT. (Antenna terminal)
Headphone jack
Stand
Round lock for Kensington
Security Standard slot*
AUDIO (R)
INPUT1
INPUT1
P
R
P
B
Y
AUDIO (L)
AUDIO (L)
S-VIDEO
VIDEO
AUDIO (R)
AUDIO (L)
AUDIO (R)
AUDIO OUT
INPUT2
*
Using the Kensington Lock
• This LCD TV set has a
Kensington Security Standard
slot for use with a Kensington
MicroSaver Security System.
Refer to the information that
came with the system for
instructions on how to use it to
secure the LCD TV set.
Caution!
Do not place any object under the table stand
Do not place any object under the table stand, as this could cause the LCD TV set to fall down, break-
ing the LCD panel as well as damaging the main unit.
To Next Page
