Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
75
LC-13AV6U
DUNTKD368WEF8
SUB Unit (Continued)
R7758 VRD-RA2BE000JY J 0 1/8W Carbon AA
R7759 VRS-TW2HF102JY J 1k 1/2W Metal Oxide AA
R7761 VRD-RA2BE2R7JY J 2.7 1/8W Carbon AA
R7767 VRD-RA2EE153JY J 15k 1/4W Carbon AA
MISCELLANEOUS PARTS
å F6700 QFS-ZA003WJZZ J Fuse, 1.6A/250V AD
å F6702 QFS-ZA003WJZZ J Fuse, 1.6A/250V AD
å F7701 QFS-C3225CEZZ J Fuse, 3.15A/250V AC
FH7701 QFSHD1013CEZZ+ J Fuse Holder AC
FH7702 QFSHD1014CEZZ+ J Fuse Holder AC
FB7002 RBLN-0095CEZZY J Ferrite Bead AD
FB7003 RBLN-0095CEZZY J Ferrite Bead AD
FB7005 RBLN-0090GEZZY J Ferrite Bead AB
FB7006 RBLN-0090GEZZY J Ferrite Bead AB
FB7007 RBLN-0090GEZZY J Ferrite Bead AB
FB7008 RBLN-0051TAZZY J Ferrite Bead AC
FB7701 RBLN-0037CEZZY J Ferrite Bead AB
FB7732 RBLN-0090GEZZY J Ferrite Bead AB
J3301 QJAKJ0101SEZZ J Headphone Jack AE
J3901 QJAKGA080WJZZ J Y/PB/PR (INPUT1) AE
J3902 QJAKFA039WJZZ J AUDIO(L/R) (INPUT1) AD
J3903 QJAKFA039WJZZ J AUDIO(L/R) (AUDIO OUT) AD
J5000 QSOCDA035WJZZ J S-VIDEO (INPUT2) AD
J5001 QJAKGA081WJZZ J VIDEO/AUDIO(L/R) AE
(INPUT1)
P3301 QPLGNA185WJZZ J Plug, 4-pin AB
P3901 QCNCMA012WJZZ J Connector, 15-pin AD
P3902 QCNCMA250WJZZ J Connector, 23-pin AE
P6700 QPLGNA390WJZZ J Plug, 2-pin AC
P6701 QPLGNA390WJZZ J Plug, 2-pin AC
P6702 QPLGNA390WJZZ J Plug, 2-pin AC
P6703 QPLGNA390WJZZ J Plug, 2-pin AC
P7301 QCNCMA012WJZZ J Connector, 15-pin AD
å P7703 QPLGN0269GEZZ J Plug, 2-pin AB
SC3601 QSOCN0896REZZ J Socket, 8-pin AC
HM6701 LX-GZ3002PEZZ J Screw AB
HM6702 LX-GZ3002PEZZ J Screw AB
HM6703 LX-GZ3002PEZZ J Screw AB
HM6704 LX-GZ3002PEZZ J Screw AB
HM6705 LX-GZ3002PEZZ J Screw AB
HM6706 LX-GZ3002PEZZ J Screw AB
HM6707 LX-GZ3002PEZZ J Screw AB
HM6708 LX-GZ3002PEZZ J Screw AB
HM6709 LX-GZ3002PEZZ J Screw AB
HM6710 LX-GZ3002PEZZ J Screw AB
HM6711 LX-GZ3002PEZZ J Screw AB
HM6712 LX-GZ3002PEZZ J Screw AB
HM6713 LX-GZ3002PEZZ J Screw AB
HM6714 LX-GZ3002PEZZ J Screw AB
HM6715 LX-GZ3002PEZZ J Screw AB
HM6716 LX-GZ3002PEZZ J Screw AB
HM7701 LX-GZ3002PEZZ J Screw AB
HM7702 LX-GZ3002PEZZ J Screw AB
HM7705 LX-GZ3002PEZZ J Screw AB
HM7706 LX-GZ3002PEZZ J Screw AB
HM7709 LX-GZ3002PEZZ J Screw AB
HM7710 LX-GZ3002PEZZ J Screw AB
HM7713 LX-GZ3002PEZZ J Screw AB
HM7714 LX-GZ3002PEZZ J Screw AB
HM7717 LX-GZ3001PEZZ J Screw AB
HM7718 LX-GZ3001PEZZ J Screw AB
HM7719 LX-GZ3001PEZZ J Screw AB
HM7720 LX-GZ3001PEZZ J Screw AB
HM7721 LX-GZ3002PEZZ J Screw AB
HM7722 LX-GZ3002PEZZ J Screw AB
HM7723 LX-GZ3002PEZZ J Screw AB
HM7724 LX-GZ3002PEZZ J Screw AB
HM7725 LX-GZ3002PEZZ J Screw AB
HM7726 LX-GZ3002PEZZ J Screw AB
HM7727 LX-GZ3002PEZZ J Screw AB
HM7728 LX-GZ3002PEZZ J Screw AB
HM7729 LX-GZ3002PEZZ J Screw AB
HM7730 LX-GZ3002PEZZ J Screw AB
HM7731 LX-GZ3002PEZZ J Screw AB
HM7732 LX-GZ3002PEZZ J Screw AB
HM7733 LX-GZ3002PEZZ J Screw AB
HM7734 LX-GZ3002PEZZ J Screw AB
HM7735 LX-GZ3002PEZZ J Screw AB
SG7703 QSPGCA003WJZZ J Spark Gap AH
PRDARA178WJFW J Heat Sink AM
PRDARA185WJFW J Heat Sink AL
QCNW-D459WJQZ J Connecting Cord AC
QCNW-D513WJPZ J Connecting Cord AC
QCNW-E225WJQZ J Connecting Cord AE
XBPS730P10JS0 J Screw, x4 AA
