Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
73
LC-13AV6U
DUNTKD368WEF8
SUB Unit (Continued)
D3306 RH-EX0640GEZZY J Zener Diode, 12V AA
D3307 RH-EX0640GEZZY J Zener Diode, 12V AA
D3308 RH-EX0640GEZZY J Zener Diode, 12V AA
D3309 RH-EX0640GEZZY J Zener Diode, 12V AA
D3601 RH-EX1293CEZZY J Zener Diode, 24V AB
D3602 RH-EX1293CEZZY J Zener Diode, 24V AB
D3901 VHD1PS184++-1Y J Diode AB
D3921 RH-EX1271CEZZY J Zener Diode, 12V AB
D3922 RH-EX1271CEZZY J Zener Diode, 12V AB
D3923 RH-EX1271CEZZY J Zener Diode, 12V AB
D5000 RH-EX1271CEZZY J Zener Diode, 12V AB
D5001 RH-EX1271CEZZY J Zener Diode, 12V AB
D5002 RH-EX1271CEZZY J Zener Diode, 12V AB
D6701 VHDBAS316//-1Y J Diode AB
D6703 VHDBAS316//-1Y J Diode AB
D6705 VHD1PS184++-1Y J Diode AB
D6707 VHD1PS184++-1Y J Diode AB
D6710 VHDMA157A//-1Y J Diode AC
D6712 VHDMA157A//-1Y J Diode AC
D6715 VHDMA157A//-1Y J Diode AC
D6716 VHDMA157A//-1Y J Diode AC
D7001 VHDLi116+++-1Y J Diode AC
D7002 VHD1SS250//1EY J Diode AB
D7003 VHDLi124+++-1Y J Diode AC
D7004 VHDLi124+++-1Y J Diode AC
D7005 VHD1PS184++-1Y J Diode AB
D7301 VHDBAS316//-1Y J Diode AB
D7306 VHDBAS316//-1Y J Diode AB
D7307 VHDBAS316//-1Y J Diode AB
å D7701 RH-DX0476CEZZ J Diode AG
D7702 RH-DX0321CEZZY J Diode AC
D7703 RH-DX0490CEZZY J Diode AC
D7704 RH-DX0490CEZZY J Diode AC
D7711 RH-DX0066GEZZY J Diode AC
D7712 VHD1SS244//-1Y J Diode AB
D7713 RH-EX0640GEZZY J Zener Diode, 12V AA
D7714 VHD1SS244//-1Y J Diode AB
D7715 RH-EX0618GEZZY J Zener Diode, 6.2V AB
D7716 VHD1SS244//-1Y J Diode AB
D7717 VHD1SS244//-1Y J Diode AB
D7718 RH-EX0656GEZZY J Zener Diode AB
D7732 VHDSF30SC6+-1 J Diode AH
D7733 VHDSF30SC6+-1 J Diode AH
TH7701 RH-HXA019WJZZ J Thermistor AE
å VA7701 RH-VXA022WJZZ J Varistor AD
å VA7702 RH-VXA018WJN1 J Varistor AD
COILS
L6700 RCiLPA371WJZZ J Coil AC
L6702 RCiLPA371WJZZ J Coil AC
L7001 RCiLPA476WJZZ+ J Coil AC
L7002 RCiLPA356WJZZ+ J Coil AC
L7003 RCiLPA356WJZZ+ J Coil AC
L7004 RCiLPA476WJZZ+ J Coil AC
å L7703 RCiLFA167WJZZ J Coil AE
å L7704 RCiLFA167WJZZ J Coil AE
L7732 RCiLP0184CEZZ+ J Coil AD
TRANSFORMER
å T6701 RTRNZA085WJZZ J Transformer AL
å T6702 RTRNZA085WJZZ J Transformer AL
å T6703 RTRNZA085WJZZ J Transformer AL
å T6704 RTRNZA085WJZZ J Transformer AL
å T7001 RTRNWA169WJZZ J Transformer AG
å T7701 RTRNWA173WJZZ J Transformer AQ
CAPACITORS
C3301 VCESKA1HM225M+ J 2.2 50V Electrolytic AB
C3302 VCESKA1HM225M+ J 2.2 50V Electrolytic AB
C3303 VCKYCY1HB153KY J 0.015 50V Ceramic AA
C3304 VCKYCY1HB153KY J 0.015 50V Ceramic AA
C3306 VCESKA1HM105M+ J 1 50V Electrolytic AB
C3307 VCESKA1HM105M+ J 1 50V Electrolytic AB
C3308 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C3309 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C3310 VCESKA1CM107M+ J 100 16V Electrolytic AC
C3312 VCESKA1CM106M+ J 10 16V Electrolytic AB
C3313 VCKYTV1CB105KY J 1 16V Ceramic AC
C3314 RC-EZA216WJZZ J 1000 16V Electrolytic AD
C3315 RC-EZA216WJZZ J 1000 16V Electrolytic AD
C3316 RC-EZA216WJZZ J 1000 16V Electrolytic AD
C3323 RC-KZA216WJZZY J 2.2 50V Ceramic AC
C3324 VCKYCY1HF224ZY J 0.22 50V Ceramic AA
C3325 RC-KZA041WJZZY J 10 10V Ceramic AC
C3601 VCKYCY1HB332KY J 3300p 50V Ceramic AA
C3602 VCKYCY1HB332KY J 3300p 50V Ceramic AA
C3901 RC-EZA184WJZZ+ J 100 50V Electrolytic AD
C3902 VCESKA1CM106M+ J 10 16V Electrolytic AB
C3903 VCESKA1CM106M+ J 10 16V Electrolytic AB
C3904 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3905 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3921 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3922 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3926 VCKYTV1CB105KY J 1 16V Ceramic AC
C3927 VCKYTV1CB105KY J 1 16V Ceramic AC
C5001 VCCCCY1HH101JY J 100p 50V Ceramic AA
C5002 VCCCCY1HH101JY J 100p 50V Ceramic AA
C6700 RC-FZA034WJZZ J 0.15 250V Film AE
C6703 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C6704 RC-EZA482WJZZ J 1000 25V Electrolytic AD
C6705 RC-FZA034WJZZ J 0.15 250V Film AE
C6709 RC-EZA482WJZZ J 1000 25V Electrolytic AD
C6710 RC-KZ0072TAZZY J 1 25V Ceramic AC
C6711 RC-KZ0072TAZZY J 1 25V Ceramic AC
C6715 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C6716 RC-EZA482WJZZ J 1000 25V Electrolytic AD
C6718 RC-EZA482WJZZ J 1000 25V Electrolytic AD
C6719 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6720 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6722 RC-KZ0072TAZZY J 1 25V Ceramic AC
C6723 RC-KZ0072TAZZY J 1 25V Ceramic AC
C6725 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C6726 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C7001 RC-KZA124WJZZY J 0.022 50V Ceramic AD
C7002 VCKYCY1HB562KY J 5600p 50V Ceramic AA
C7003 RC-EZA464WJZZ+ J 1000 16V Electrolytic AD
C7004 VCKYCY1HB562KY J 5600p 50V Ceramic AA
C7005 VCCCCY1HH181JY J 180p 50V Ceramic AA
C7006 VCESKA1HM476M+ J 47 50V Electrolytic AD
C7007 VCKYCY1HF104ZY J 0.1 50V Ceramic AA
C7008 VCESKA1CM337M+ J 330 16V Electrolytic AD
C7009 VCKYTV1CF105ZY J 1 16V Ceramic AB
C7010 RC-EZA450WJZZ+ J 1500 10V Electrolytic AD
C7011 VCKYTV1CF105ZY J 1 16V Ceramic AB
C7012 VCESKA1CM337M+ J 330 16V Electrolytic AD
C7013 VCKYTV1CF105ZY J 1 16V Ceramic AB
C7014 VCESKA1CM107M+ J 100 16V Electrolytic AC
C7301 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C7302 RC-KZA116WJZZY J 4.7 6.3V Ceramic AC
C7303 VCKYCY1HB332KY J 3300p 50V Ceramic AA
C7304 VCCCCY1HH330JY J 33p 50V Ceramic AA
C7305 VCCCCY1HH330JY J 33p 50V Ceramic AA
C7306 VCCCCY1HH471JY J 470p 50V Ceramic AA
C7308 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C7309 VCKYCY1AB684KY J 0.68 10V Ceramic AB
C7310 VCKYCY1HB103KY J 0.01 50V Ceramic AA
å C7701 RC-FZA022WJZZ J 0.22 275V Film AD
C7702 RC-FZA022WJZZ J 0.22 275V Film AD
C7703 RC-EZA984WJZZ J 180 250V Electrolytic AP
C7704 RC-FZA180WJZZ J 0.1 580V Film AD
å C7707 RC-KZ0103GEZZ J 1000p 250V Ceramic AD
å C7708 RC-KZ0089GEZZ J 1000p Ceramic AC
C7711 RC-KZA271WJZZ J 470p 2kV Ceramic AC
C7712 RC-KZA216WJZZY J 2.2 50V Ceramic AC
C7713 VCKYPA1HB471K+ J 470p 50V Ceramic AA
C7714 VCQYTA1HM104J+ J 0.1 50V Mylar AB
