Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
80
LC-13AV6U
DUNTKD424FMF8
MAIN Unit (Continued)
FB1701 RBLN-0006TAZZY J Ferrite Bead AB
FB1702 RBLN-0006TAZZY J Ferrite Bead AB
FB1703 RBLN-0006TAZZY J Ferrite Bead AB
P2002 QPLGNA111WJZZ J Plug, 6-pin AB
SC1201 QCNCWA010WJZZYJ Connector, 15-pin AE
SC1701 QSOCNA222WJZZY J Socket, 80-pin AH
SC2001 QCNCWA010WJZZYJ Connector, 15-pin AE
SC2002 QCNCWA251WJZZYJ Connector, 23-pin AH
SC2003 QSOCN0596REZZ J Socket, 5-pin AB
LUG2001
QLUGHA006WJZZY J Lug AC
LUG2002
QLUGHA006WJZZY J Lug AC
1 CCABAA755WJ02 J Cabinet A Ass'y BA
1-1
Not Available
– Cabinet A —
1-2 HDECQA478WJSA J Leg Cover, x2 AC
1-3 HDECQA556WJSA J R/C,LED Cover AE
1-4 HDECQA557WJKA J LED Cover AF
1-5 TLABZA459WJZZ J "EnergyStar" Label AD
1-6 TLABZA635WJZZ J "EnergyStar" Label AC
1-7 XEBSN30P08000 J Screw, x1 AA
2 CCABBA723WJ01 J Cabinet B Ass'y BE
2-1
Not Available
– Cabinet B —
2-2 GLEGGA042WJZZ J Rubber Leg, x2 AB
2-3 LANGFA085WJFW J Kensington Angle AC
2-4 LANGTA159WJFW J Reinforcement Angle AP
2-5 PZETKA172WJZZ J Insulating Sheet, x1 AM
2-6 XEBSN30P08000 J Screw, x1 AA
3 CDAi-A225WJ02 J Stand Ass'y AY
3-1 GDAi-A225WJKA J Stand, Base AN
3-2 GCOVAB023WJSA J Stand Cover AN
3-3 GLEGGA041WJSA J Rubber Leg, x2 AE
3-4 MHNG-A130WJZZ J Tilt Hinge AV
3-5 XEBS940P10000 J Screw, x3 AB
3-6 XESSN40P10000 J Screw, x8 AB
4 CCOVAB494WJ01 J Top Cover Ass'y AP
4-1
Not Available
– Top Cover —
4-2 JBTN-A353WJSA J Operation Button AK
4-3 JBTN-A354WJSA J Power Button AF
4-4 MSPRCA014WJFW J Spring, for Power Button AB
4-5 XEBSN30P08000 J Screw, x1 AA
5 R1LK130V3GZ12Z J 13" LCD Panel Module Unit DA
5-1
Not Available
– 13" LCD Panel Unit —
5-2
Not Available
– Back Shield Ass'y —
5-2-1 PSLDMA542WJFW J Back Shield AR
5-2-2 LHLDZA429WJKZ J Lamp Holder-R(Bottom) AF
5-2-3 LHLDZA435WJKZ J Lamp Holder-L(Bottom) AF
5-2-4 PSHEPA229WJZZ J Reflection Sheet AK
5-2-5 TCAUZA031WJZZ J Caution Label AB
5-2-6 PMLT-A149WJZZ J Light Shielding Spacer, x2 AB
å 5-3 KLMP-A113WJ01 J Lamp Unit, x4 AZ
5-4 LHLDZA433WJKZ J Lamp Holder-R(Top) AH
5-5 LHLDZA434WJKZ J Lamp Holder-L(Top) AH
5-6 LX-BZA084WJF7 J Screw, x4 AA
5-7 PCOVUA047WJZZ J Diffusion Plate, x1 AT
5-8 PSHEPA230WJZZ J Diffusion Sheet, x2 AH
6 CCHSMA184WJ04 J Chassis Frame Ass'y AF
6-1
Not Available
– Chassis Frame —
6-2 PSPAHA552WJ00 J Spacer, x1 AD
6-3 PSPAHA554WJ00 J Spacer, x1 AB
6-4 PSPAHA556WJ00 J Spacer, x1 AB
7 GCOVAA984WJKA J Bass-Cone Cover AF
8 GCOVHA069WJKA J AC Holder AE
9 LHLDKA005WJK0 J AC Cord Holder AD
10 LHLDZA642WJZZ J LED Holder AE
11 TLABMC151WJSA J Model Label AD
12
Not Available
– Serial No. Label —
13 QCNW-D115WJQZ J Connecting Cord AH
14 QCNW-D362WJQZ J Connecting Cord AD
15 QCNW-E297WJQZ J Connecting Cord AF
16 QPWBMC876WJPZ J Connecting Cord AR
17 QEARPA132WJFW J Grounding Part AD
18 VSP7530PB678B J Speaker, x2 AL
19 LX-BZ3442CEF9 J Screw, x4 AB
20 XEBS930P14000 J Screw, x5 AA
21 XEBSN30P08000 J Screw, x15 AA
DUNTKD425WEF8
R/C, LED Unit
TRANSISTORS
Q4101 VSKRC104S//-1Y J KRC104S AA
Q4102 VSKRC104S//-1Y J KRC104S AA
Q4103 VSKRC104S//-1Y J KRC104S AA
Q4105 VSKRC104S//-1Y J KRC104S AA
DIODES
D4101 RH-PXA014WJZZ+ J POWER Indicator AD
D4102 RH-PXA014WJZZ+ J SLEEP TIMER Indicator AD
D4104 RH-EX0610GEZZY J Zener Diode, 4.7V AA
D4105 RH-EX0610GEZZY J Zener Diode, 4.7V AA
D4106 RH-EX0610GEZZY J Zener Diode, 4.7V AA
D4109 RH-EX0610GEZZY J Zener Diode, 4.7V AA
CAPACITOR
C4101 VCESKA1CM106M+ J 10 16V Electrolytic AB
RESISTORS
R4101 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R4102 VRS-CY1JF681JY J 680 1/16W Metal Oxide AA
R4103 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4105 VRS-CY1JF681JY J 680 1/16W Metal Oxide AA
R4106 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
SC4101 QSOCN0896REZZ J Socket, 8-pin AC
RMC4101
RRMCUA034WJQZ J Remote Sensor AE
LHLDZA642WJZZ J LED Holder AE
CABINET AND MECHANICAL PARTS
To Next Page
