15-6
A7121EL
Ref. No. Part No. Description
D952 9HSDTZ001SS133 SWITCHING DIODE 1SS133(T-77)
D953 9HSDTZ001SS133 SWITCHING DIODE 1SS133(T-77)
D954 9HSDTZ001SS133 SWITCHING DIODE 1SS133(T-77)
D955 9HSDTZ001SS133 SWITCHING DIODE 1SS133(T-77)
D956 9HSDTB00MTZJ12 ZENER DIODE MTZJT-7712B
D957 9HSDTZ001SS133 SWITCHING DIODE 1SS133(T-77)
D958 9HSDTZ001SS133 SWITCHING DIODE 1SS133(T-77)
D959 9HSDTZ001SS133 SWITCHING DIODE 1SS133(T-77)
ICS
IC31 9HSSZBA0SHT034 IC VIF/SIF M61116FP TF0G
IC61 9HSSZBA0TSS268 EEP-ROM 128K M24128-BWMN6TP
IC601# 9HSPEC0LTV817F PHOTOCOUPLER LTV-817C-F
IC801 9HSSZBA0SQ0007 IC AUDIO SA7412
IC851 9HSSZBA0TMS003 IC MTS DECORDER AN5832SA-E1V
IC852 9HSSZBA0TTS162 IC SWITCHING TC4052BF(ELNF)
IC901 9HSSZBA0TSS229 VOLTAGE REGULATOR LD1117SC-R
IC904 9HSSZBA0SSH054 VOLTAGE REGULATOR PQ070XF01SZH
IC905 9HSSZBA0SJY041 IC VOLTAGE REGULATOR 5V KIA7805API/P
IC906 9HSSZBA0SSH054 VOLTAGE REGULATOR PQ070XF01SZH
IC1202 9HSSZAA0RHT162 IC DVP-V6 R8A02030A93FP-RF0Z
IC1205 9HSSZBA0TRM071 IC BR24L64F-WE2
COILS
L21 9HSJW5.0T PCB JUMPER D0.6-P5.0
L22 9HSLAXJATTU151 INDUCTOR 150µH-J-26T
L31 9HSJW5.0T PCB JUMPER D0.6-P5.0
L32 9HSLAXJATTU180 INDUCTOR 18µH-J-26T
L61 9HSJW5.0T PCB JUMPER D0.6-P5.0
L63 9HSJW5.0T PCB JUMPER D0.6-P5.0
L66 9HSLACKB3TU1R0 INDUCTOR CHIP LK16081R0K-T 1.0µH
L401 9HSLBD00ASF045 INDUCTOR RCH114NP-151KB
L403 9HSLBD00ASF045 INDUCTOR RCH114NP-151KB
L601# 9HSLBG00ZKT004 LINE FILTER 5.0MH 6Y075
L701 9HSJW5.0T PCB JUMPER D0.6-P5.0
L781 9HSJW5.0T PCB JUMPER D0.6-P5.0
L851 9HSJW5.0T PCB JUMPER D0.6-P5.0
L1200 9HSRXAJR5Z0330 CHIP RES. 1/10W J 33 OHM
L1227 9HSLBC003TU058 CHIP INDUCTOR BK1608LL241-T
L1301 9HSJW5.0T PCB JUMPER D0.6-P5.0
L1338 9HSLAXJATTU010 INDUCTOR 1.0µH-J-26T
L1346 9HSLAXJATTU010 INDUCTOR 1.0µH-J-26T
L1351 9HSLAXJATTU010 INDUCTOR 1.0µH-J-26T
L1356 9HSLAXJATTU010 INDUCTOR 1.0µH-J-26T
TRANSISTORS
Q401 9HSQWZ2SC4881F NPN TRANSISTOR POWER 2SC4881F HFE MAX320
Q402 9HSQSY02SA950F TRANSISTOR 2SA950-Y(TE2 F T)
Q403 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Q404 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Q405 9HSQSF02SA1175 TRANSISTOR 2SA1175(F)
Q406 9HSQSY2SC2120F TRANSISTOR 2SC2120-Y(TE2 F T)
Q407 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Q421# 9HSF2ZTPC8214H FET MOS SMD TPC8214-H
Q422 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Q424 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Q425 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Q461# 9HSF2ZTPC8214H FET MOS SMD TPC8214-H
Q462 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Q464 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Q601# 9HSFWZ2SK3563Q FET MOS 2SK3563(Q)
Q603# 9HSQSY2SC2120F TRANSISTOR 2SC2120-Y(TE2 F T)
Q707 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Q708 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Q709 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Q802 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Q901 9HSQSY2SC2120F TRANSISTOR 2SC2120-Y(TE2 F T)
Q902 9HSQSY2SC2120F TRANSISTOR 2SC2120-Y(TE2 F T)
Q903 9HSQSY2SC2120F TRANSISTOR 2SC2120-Y(TE2 F T)
Q905 9HSQSY02SA950F TRANSISTOR 2SA950-Y(TE2 F T)
Q906 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Q907 9HSQSY2SC2120F TRANSISTOR 2SC2120-Y(TE2 F T)
