Sharp LC-15AV7U User Manual

15-7
A7121EL
Ref. No. Part No. Description
Q908 9HSQSY2SC2120F TRANSISTOR 2SC2120-Y(TE2 F T)
Q909 9HSQSY2SC2120F TRANSISTOR 2SC2120-Y(TE2 F T)
Q913 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Q916 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Q917 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Q918 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
Q923 9HSQSY02SA950F TRANSISTOR 2SA950-Y(TE2 F T)
Q924 9HSQSY02SA950F TRANSISTOR 2SA950-Y(TE2 F T)
Q925 9HSQSF02SC2785 TRANSISTOR 2SC2785(F)
RESISTORS
R17 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω
R18 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω
R21 9HSRXAJR5Z0274 CHIP RES. 1/10W J 270k Ω
R23 9HSRXAJR5Z0222 CHIP RES. 1/10W J 2.2k Ω
R24 9HSRXAJR5Z0824 CHIP RES. 1/10W J 820k Ω
R25 9HSRXAJR5Z0822 CHIP RES. 1/10W J 8.2k Ω
R26 9HSCX4JATZ0101 CARBON RES. 1/4W J 100 Ω
R34 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω
R38 9HSRXAJR5Z0101 CHIP RES. 1/10W J 100 Ω
R42 9HSRXAJR5Z0221 CHIP RES. 1/10W J 220 Ω
R46 9HSCX4JATZ0102 CARBON RES. 1/4W J 1k Ω
R48 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω
R49 9HSRXAJR5Z0182 CHIP RES. 1/10W J 1.8k Ω
R61 9HSRXAJR5Z0221 CHIP RES. 1/10W J 220 Ω
R62 9HSRXAJR5Z0221 CHIP RES. 1/10W J 220 Ω
R63 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω
R64 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω
R65 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω
R67 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω
R68 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω
R72 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω
R73 9HSRXAJR5Z0223 CHIP RES. 1/10W J 22k Ω
R74 9HSRXAJR5Z0223 CHIP RES. 1/10W J 22k Ω
R75 9HSRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R401 9HSRXAJR5Z0152 CHIP RES. 1/10W J 1.5k Ω
R402 9HSCX4JATZ0273 CARBON RES. 1/4W J 27k Ω
R403 9HSCX4JATZ0151 CARBON RES. 1/4W J 150 Ω
R404 9HSCX4JATZ0562 CARBON RES. 1/4W J 5.6k Ω
R406 9HSRXAJR5Z0332 CHIP RES. 1/10W J 3.3k Ω
R407 9HSRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R408 9HSCX4JATZ0821 CARBON RES. 1/4W J 820 Ω
R409 9HSCX4JATZ0103 CARBON RES. 1/4W J 10k Ω
R410 9HSCX4JATZ0122 CARBON RES. 1/4W J 1.2k Ω
R411 9HSRXAJR5Z01R0 CHIP RES. 1/10W J 1 Ω
R412 9HSRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R413 9HSRXAJR5Z0333 CHIP RES. 1/10W J 33k Ω
R414 9HSCX4JATZ0681 CARBON RES. 1/4W J 680 Ω
R415 9HSCX4JATZ0151 CARBON RES. 1/4W J 150 Ω
R416 9HSCX4JATZ0151 CARBON RES. 1/4W J 150 Ω
R417 9HSCX4JATZ0151 CARBON RES. 1/4W J 150 Ω
R418 9HSCX4JATZ0122 CARBON RES. 1/4W J 1.2k Ω
R419 9HSCX4JATZ0151 CARBON RES. 1/4W J 150 Ω
R420 9HSRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R421 9HSRXAJR5Z0331 CHIP RES. 1/10W J 330 Ω
R422 9HSRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R423 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω
R424 9HSRXAJR5Z0332 CHIP RES. 1/10W J 3.3k Ω
R425 9HSRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R428 9HSRXAJR5Z0220 CHIP RES. 1/10W J 22 Ω
R429 9HSRXAJR5Z0220 CHIP RES. 1/10W J 22 Ω
R430 9HSRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω
R431 9HSRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω
R432 9HSRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R433 9HSRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R434 9HSRXAJR5Z0153 CHIP RES. 1/10W J 15k Ω
R435 9HSRXAJR5Z0222 CHIP RES. 1/10W J 2.2k Ω
R461 9HSRXAJR5Z0331 CHIP RES. 1/10W J 330 Ω
R462 9HSRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R463 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω
