15-11
A7121EL
R1341 9HSRXAJR5Z0330 CHIP RES. 1/10W J 33 Ω
R1342 9HSRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω
R1343 9HSCX4JATZ0101 CARBON RES. 1/4W J 100 Ω
R1344 9HSRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1346 9HSRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1348 9HSRXAJR5Z0101 CHIP RES. 1/10W J 100 Ω
R1349 9HSRXAJR5Z0101 CHIP RES. 1/10W J 100 Ω
R1350 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω
R1352 9HSRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω
R1353 9HSRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1354 9HSRXAJR5Z0222 CHIP RES. 1/10W J 2.2k Ω
R1355 9HSRXAJR5Z0222 CHIP RES. 1/10W J 2.2k Ω
R1356 9HSRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R1357 9HSRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R1358 9HSRXAJR5Z0222 CHIP RES. 1/10W J 2.2k Ω
R1359 9HSRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1360 9HSRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1361 9HSRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R1362 9HSRXAJR5Z0470 CHIP RES. 1/10W J 47 Ω
R1363 9HSRXAJR5Z0471 CHIP RES. 1/10W J 470 Ω
R1710 9HSCX4JATZ0103 CARBON RES. 1/4W J 10k Ω
MISCELLANEOUS
AC601# 9HSAC0172LW024 AC CORD W/O A GND WIRE UL/CSA 1700MM BLACK
B10 9HS1EM423993 POW HEAT SINK A7120UH
BC61 9HSLBF00STU030 BEADS INDUCTOR FBR07HA121SB-00
BC62 9HSJW5.0T PCB JUMPER D0.6-P5.0
BC65 9HSLBF00STU030 BEADS INDUCTOR FBR07HA121SB-00
BC602 9HSLBF00STU030 BEADS INDUCTOR FBR07HA121SB-00
BC929 9HSLBF00STU030 BEADS INDUCTOR FBR07HA121SB-00
CF31 9HSBB455PMR004 CERAMIC FILTER SFSRA4M50CF00-B0
F601# 9HSAGE20CW3402 FUSE STC4A125V U/CT
FH601 9HSH01Z00LY002 FUSE HOLDER MSF-015 LF (B110)
FH602 9HSH01Z00LY002 FUSE HOLDER MSF-015 LF (B110)
GP642# 9HSAZ000LD6005 GAP. FNR-G3.10D
J152 9HSLBF00STU026 BEAD INDUCTORS FBA04HA600VB-00
JK701 9HSYEJ040JC001 Y/C JACK YKF51-5646N
JK703 9HSXRJ010SNJ01 RCA JACK AV-4B-54H YELLOW
JK704 9HSXRJ010SNJ04 RCA JACK WHITE AV-4B-58H WHITE
JK705 9HSYRJ010SNJ01 RCA JACK AV-4A-57H RED
JK706 9HSXRJ010SNJ05 RCA JACK AV-4B-55H
JK707 9HSXRJ010SNJ02 RCA JACK AV-4B-56H
JK708 9HSXRJ010SNJ03 RCA JACK AV-4B-57H
JK709 9HSXRJ010SNJ04 RCA JACK WHITE AV-4B-58H WHITE
JK710 9HSYRJ010SNJ01 RCA JACK AV-4A-57H RED
JK801 9HSYSL010SNJ01 MINIATURE JACK(PB FREE) CKX-035-318AZ4
JK1701 9HSXRJ010SNJ06 JACK RCA PCB S AV-4B-70HH
JS67 9HSJW5.5T PCB JUMPER D0.6-P5.5
JS426 9HSJW5.0T PCB JUMPER D0.6-P5.0
JS466 9HSJW5.0T PCB JUMPER D0.6-P5.0
JS701 9HSRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 Ω
JS702 9HSJW5.0T PCB JUMPER D0.6-P5.0
JS704 9HSJW5.0T PCB JUMPER D0.6-P5.0
JS705 9HSJW5.0T PCB JUMPER D0.6-P5.0
JS706 9HSJW5.0T PCB JUMPER D0.6-P5.0
JS904 9HSJW5.0T PCB JUMPER D0.6-P5.0
L9 9HSGBJB3080 SCREW B-TIGHT D3X8 BIND HEAD+
SA601# 9HSVQZ10D471KB SURGE ABSORBER 470V+-10PER
SF11 9HSBB456LMR004 FILTER CERAMIC BAND PASS SAFHS45M7VAJZ00B05
T401# 9HSTZ2PC0MS007 TRANS INVERTER ETJV27ZK26AC
T403# 9HSTZ2PC0MS007 TRANS INVERTER ETJV27ZK26AC
T601# 9HSTT2PC0KT019 TRANS POWER 7701
TU61 9HSTUNATSMS001 TUNER UNIT ENV56M07D8F
X1301 9HSXC276LLN002 XTAL OSCILLATOR 27.00MHz 15PPM
Ref. No. Part No. Description
