15-12
A7121EL
FUNCTION CBA
Ref. No. Part No. Description
RESISTORS
R1101 9HSCX4JATZ0103 CARBON RES. 1/4W J 10k Ω
R1102 9HSCX4JATZ0101 CARBON RES. 1/4W J 100 Ω
R1103 9HSCX4JATZ0152 CARBON RES. 1/4W J 1.5k Ω
R1104 9HSCX4JATZ0152 CARBON RES. 1/4W J 1.5k Ω
R1105 9HSCX4JATZ0222 CARBON RES. 1/4W J 2.2k Ω
R1106 9HSCX4JATZ0272 CARBON RES. 1/4W J 2.7k Ω
R1107 9HSCX4JATZ0472 CARBON RES. 1/4W J 4.7k Ω
R1108 9HSCX4JATZ0682 CARBON RES. 1/4W J 6.8k Ω
R1109 9HSCX4JATZ0103 CARBON RES. 1/4W J 10k Ω
R1110 9HSCX4JATZ0101 CARBON RES. 1/4W J 100 Ω
SWITCHES
SW1101 9HSST0101AL038 TACT SWITCH SKQSAB
SW1102 9HSST0101AL038 TACT SWITCH SKQSAB
SW1103 9HSST0101AL038 TACT SWITCH SKQSAB
SW1104 9HSST0101AL038 TACT SWITCH SKQSAB
SW1105 9HSST0101AL038 TACT SWITCH SKQSAB
SW1107 9HSST0101AL038 TACT SWITCH SKQSAB
SW1111 9HSST0101AL038 TACT SWITCH SKQSAB
MISCELLANEOUS
CL1107 9HSX1A7121-003 WIRE ASSEMBLY 4PIN SW 15V 4PIN/85MM
FUNCTION CBA + IR SENSOR CBA + JUNCTION-A & B CBA [9HS1ESA14126]
9HS1ESA14126 FUNCTION CBA + IR SENSOR CBA + JUNCTION-A & B CBA
Consists of the following:
---------- FUNCTION CBA
---------- IR SENSOR CBA
---------- JUNCTION-A CBA
---------- JUNCTION-B CBA
Ref. No. Part No. Description
IR SENSOR CBA
CAPACITOR
C1142 9HSE1JMAVSL2R2 ELECTROLYTIC CAP. 2.2µF/50V M H7
DIODE
D1142 9HSPWK333HTF45 LED LAMP 333HT/F45-50K
TRANSISTOR
Q1142 9HSQSZKRC103MP NPN TRANSISTOR KRC103M-AT/P
RESISTORS
R1143 9HSCX4JATZ0121 CARBON RES. 1/4W J 120 Ω
R1146 9HSCX4JATZ0331 CARBON RES. 1/4W J 330 Ω
MISCELLANEOUS
CL1104 9HSX1A7121-001 WIRE ASSEMBLY 5PIN SENSOR 15V 5PIN/70MM
RV1142 9HSSESJRSKK057 SENSOR REMOTE RECEIVER KSM-603SR2E
Ref. No. Part No. Description
JUNCTION-A CBA
MISCELLANEOUS
CL801 9HSX1A7120-008 WIRE ASSEMBLY 2PIN SPEAKER 2PIN/180MM
Ref. No. Part No. Description
JUNCTION-B CBA
MISCELLANEOUS
CL802 9HSX1A7120-008 WIRE ASSEMBLY 2PIN SPEAKER 2PIN/180MM
Ref. No. Part No. Description
