106
Ref. No. Part No.
★
Description Code
Ref. No. Part No.
★
Description Code
LC-19SK25U/U-W
LC-19SB25U/U-W
LC-19SB15U
LC-19D45U
DUNTKE333FM02
POWER INvERTER UNIT (Continued)
D7526 RH-EX0649GEZZY J Zener Diode, 16V AB
D7527 RH-DX0476CEZZ J Bridge Diode AG
D7528 VHD1SS355//-1Y J Diode AB
D7529 VHD1SS355//-1Y J Diode AB
D7530 VHD1SS355//-1Y J Diode AB
D7531 VHD1SS355//-1Y J Diode AB
vARISTORS
!
VA7501 RH-VXA022WJZZ J Varistor AD
!
VA7502 RH-VXA071WJQZ J Varistor AD
COILS
!
L7501 RCILFA273WJZZ J Coil AG
!
L7502 RCILFA272WJZZ J Coil AF
L7503 RCILPA974WJZZ J Coil AE
TRANSFORMERS
!
T7501 RTRNZA126WJZZ J Transformer AL
!
T7502 RTRNZA126WJZZ J Transformer AL
!
T7503 RTRNWA294WJZZ J Transformer AN
CAPACITORS
C7502 RC-EZA216WJZZ J 1000uF 16V Ceramic AD
C7503 RC-KZA524WJZZ J 10pF 3KV Ceramic AC
C7504 VCKYCY1HB223KY J 0.022 50V Ceramic AA
C7505 RC-KZA524WJZZ J 10pF 3KV Ceramic AC
C7506 VCKYCY1HB223KY J 0.022 50V Ceramic AA
C7507 RC-KZA524WJZZ J 10pF 3KV Ceramic AC
C7508 VCKYCY1HB223KY J 0.022 50V Ceramic AA
C7509 RC-KZA524WJZZ J 10pF 3KV Ceramic AC
C7510 VCKYCY1HB223KY J 0.022 50V Ceramic AA
C7511 RC-KZA213WJZZY J 4.7uF 25V Ceramic AC
C7512 RC-KZA213WJZZY J 4.7uF 25V Ceramic AC
C7513 RC-KZA114WJZZY J 1uF 25V Ceramic AB
C7514 RC-KZA114WJZZY J 1uF 25V Ceramic AB
C7515 RC-KZA114WJZZY J 1uF 25V Ceramic AB
C7516 RC-KZA114WJZZY J 1uF 25V Ceramic AB
C7517 VCKYCY1HB332KY J 3300p 50V Ceramic AA
C7518 VCKYCY1HB473KY J 0.047 50V Ceramic AA
C7519 VCCCCY1HH331JY J 330p 50V Ceramic AA
C7520 VCKYCY1HB472KY J 4700p 50V Ceramic AA
C7521 VCKYCY1HB223KY J 0.022 50V Ceramic AA
C7522 VCKYCY1CF474ZY J 0.47 16V Ceramic AB
C7523 VCKYPA1HF473Z+ J 0.047 50V Ceramic AB
C7524 RC-KZA114WJZZY J 1uF 25V Ceramic AB
C7525 RC-KZA213WJZZY J 4.7uF 25V Ceramic AC
!
C7526 RC-FZA022WJZZ J 0.22uF 275V Ceramic AD
!
C7527 RC-FZA018WJZZ J 0.1uF 275V Ceramic AC
!
C7528 RC-EZB126WJZZ J 220uF 200V Ceramic AL
C7529 RC-FZA162WJZZ J 6800P 1KV Ceramic AF
C7530 RC-KZ1005CEZZ+ J 470pF 1KV Ceramic AC
C7531 RC-FZA320WJZZ+ J 47000pF 50V Film AC
C7532 VCKYTV1HB152KY J 1500p 50V Ceramic AB
!
C7534 RC-KZ0104GEZZ J 1500uF 250V Ceramic AG
!
C7535 RC-KZ0104GEZZ J 1500uF 250V Ceramic AG
C7538 RC-EZA216WJZZ J 1000uF 16V Ceramic AD
C7539 RC-EZA216WJZZ J 1000uF 16V Ceramic AD
C7540 VCKYCY1EB224KY J 0.22 25V Ceramic AB
C7541 RC-KZ1010CEZZ J 2200pF 1KV Ceramic AD
C7542 RC-EZA461WJZZ+ J 470uF 16V Ceramic AC
C7543 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C7545 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C7546 VCKYCY1HB332KY J 3300p 50V Ceramic AA
C7547 VCKYCY1HB332KY J 3300p 50V Ceramic AA
C7548 VCKYCY1HB332KY J 3300p 50V Ceramic AA
C7549 VCKYCY1HB332KY J 3300p 50V Ceramic AA
C7550 RC-KZA212WJZZY J 2.2uF 16V Ceramic AB
C7551 VCCCTV1HH681JY J 680p 50V Ceramic AB
RESISTORS
RJ11 VRS-TQ2BD000JY J 0 1/8W Metal Oxide AA
RJ12 VRS-TQ2BD000JY J 0 1/8W Metal Oxide AA
RJ13 VRS-TQ2BD000JY J 0 1/8W Metal Oxide AA
RJ14 VRS-TQ2BD000JY J 0 1/8W Metal Oxide AA
RJ15 VRS-TQ2BD000JY J 0 1/8W Metal Oxide AA
RJ16 VRS-TQ2BD000JY J 0 1/8W Metal Oxide AA
RJ17 VRS-TQ2BD000JY J 0 1/8W Metal Oxide AA
R7502 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R7503 VRS-CY1JF431JY J 430 1/16W Metal Oxide AA
R7505 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R7506 VRS-TV2BD431JY J 430 1/8W Metal Oxide AA
R7507 VRS-TV2BD103JY J 10k 1/8W Metal Oxide AA
R7510 VRS-TV2BD103JY J 10k 1/8W Metal Oxide AA
R7511 VRS-CY1JF393FY J 39k 1/16W Metal Oxide AA
R7512 VRS-TV2BD124FY J 120k 1/8W Metal Oxide AA
R7513 VRS-CY1JF363FY J 36k 1/16W Metal Oxide AA
R7514 VRS-CY1JF203FY J 20k 1/16W Metal Oxide AA
R7515 VRS-CY1JF683FY J 68k 1/16W Metal Oxide AA
R7516 VRS-TV2BD153FY J 15k 1/8W Metal Oxide AA
R7517 VRS-CY1JF104FY J 100k 1/16W Metal Oxide AA
R7518 VRS-CY1JF104FY J 100k 1/16W Metal Oxide AA
R7519 VRS-CY1JF683FY J 68k 1/16W Metal Oxide AA
R7520 VRS-CY1JF154FY J 150k 1/16W Metal Oxide AA
R7521 VRS-TV2BD103JY J 10k 1/8W Metal Oxide AA
R7522 VRS-TV2BD201JY J 200 1/8W Metal Oxide AA
R7523 VRS-CY1JF393FY J 39k 1/16W Metal Oxide AA
R7524 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R7525 VRS-CY1JF471FY J 470 1/16W Metal Oxide AA
R7527 VRS-CY1JF513JY J 51k 1/16W Metal Oxide AA
R7528 VRS-TV2BD513JY J 51k 1/8W Metal Oxide AA
R7529 VRS-CY1JF302FY J 3k 1/16W Metal Oxide AA
R7530 VRS-CY1JF132FY J 1.3k 1/16W Metal Oxide AA
R7531 VRS-CY1JF202FY J 2k 1/16W Metal Oxide AA
R7532 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R7535 VRS-CY1JF102FY J 1k 1/16W Metal Oxide AA
R7536 VRS-CY1JF102FY J 1k 1/16W Metal Oxide AA
R7537 VRS-CY1JF102FY J 1k 1/16W Metal Oxide AA
R7538 VRS-CY1JF102FY J 1k 1/16W Metal Oxide AA
!
R7539 VRS-TQ2EF474JY J 470k 1/4W Metal Oxide AA
!
R7540 VRS-TQ2EF474JY J 470k 1/4W Metal Oxide AA
R7541 VRS-TV2BD334JY J 330k 1/8W Metal Oxide AA
R7542 VRS-TV2BD334JY J 330k 1/8W Metal Oxide AA
R7543 VRS-TV2BD334JY J 330k 1/8W Metal Oxide AA
R7544 VRS-TV2BD124JY J 120k 1/8W Metal Oxide AA
R7545 VRS-VV3LB513J J 51k 3.0W Metal Oxide AB
R7547 VRS-TV2BD102JY J 1k 1/8W Metal Oxide AA
R7548 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R7549 VRS-TV2BD472JY J 4.7k 1/8W Metal Oxide AA
R7550 VRS-TV2BD123JY J 12k 1/8W Metal Oxide AA
R7551 VRS-TQ2EF100JY J 10 1/4W Metal Oxide AA
R7552 VRS-TV2BD182JY J 1.8k 1/8W Metal Oxide AA
R7553 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R7554 VRS-TV2BD822FY J 8.2k 1/8W Metal Oxide AA
R7555 VRS-TV2BD122JY J 1.2k 1/8W Metal Oxide AA
R7556 VRS-CY1JF392FY J 3.9k 1/16W Metal Oxide AA
R7557 VRS-TV2BD682FY J 6.8k 1/8W Metal Oxide AA
R7558 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R7560 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R7561 VRS-CY1JF512FY J 5.1k 1/16W Metal Oxide AA
R7562 VRS-CY1JF512FY J 5.1k 1/16W Metal Oxide AA
R7563 VRS-CY1JF512FY J 5.1k 1/16W Metal Oxide AA
R7564 VRS-CY1JF512FY J 5.1k 1/16W Metal Oxide AA
R7565 VRS-CY1JF333FY J 33k 1/16W Metal Oxide AA
!
R7566 RR-HZ0052CEZZY J Resistance (8.2M) AC
MISCELLANEOUS PARTS
!
CN7502 QSOCAA003WJZZ J Socket (AC Inlet) AD
!
F7502 QFS-ZA038WJZZ J Fuse, 2.5A 250V AD
HM7501 LX-GZA011WJZZ J Screw AB
HM7502 LX-GZA011WJZZ J Screw AB
HM7503 LX-GZA011WJZZ J Screw AB
HM7504 LX-GZA011WJZZ J Screw AB
HM7505 LX-GZA011WJZZ J Screw AB
HM7506 LX-GZA011WJZZ J Screw AB
HM7507 LX-GZA010WJZZ J Screw AB
HM7508 LX-GZA010WJZZ J Screw AB
HM7509 LX-GZA010WJZZ J Screw AB
