Ref. No. Part No.
★
Description Code Ref. No. Part No.
★
Description Code
LC-19SK25U/U-W
LC-19SB25U/U-W
LC-19SB15U
LC-19D45U
DUNTKE333FM02
POWER INvERTER UNIT (Continued)
HM7510 LX-GZA010WJZZ J Screw AB
HM7511 LX-GZA011WJZZ J Screw AB
HM7512 LX-GZA011WJZZ J Screw AB
HM7513 LX-GZA011WJZZ J Screw AB
HM7514 LX-GZA011WJZZ J Screw AB
HM7515 LX-GZA011WJZZ J Screw AB
HM7516 LX-GZA011WJZZ J Screw AB
HM7517 LX-GZA011WJZZ J Screw AB
HM7518 LX-GZA011WJZZ J Screw AB
HM7519 LX-GZA011WJZZ J Screw AB
HM7520 LX-GZA011WJZZ J Screw AB
P7501 QPLGNA391WJZZ J Plug (to Panel) AD
P7502 QPLGNA391WJZZ J Plug (to Panel) AD
P7503 QPLGNA056WJZZ J Plug (to Panel) AB
P7504 QPLGNA056WJZZ J Plug (to Panel) AB
SC7501 QCNCMA012WJZZ J Connector (to Main) AD
!
SG7501 QSPGCA009WJZZ J Surge Absorber AG
TH7501 RH-HXA019WJZZ J HXA019WJ AE
RDA7501 PRDARA486WJFW J Heat Sink-A AF
RDA7502 PRDARA487WJFW J Heat Sink-B AF
XBBS930P06000 J Screw (for Heat Sink), x2 AA
LANGTA469WJFW J Fixing Metal AF
PSPAHB360WJ00 J Spacer AA
XBPSN30P06000 J Screw (for AC Angle) AA
DUNTKE352FM02
MAIN UNIT
INTEGRATED
IC301 VHIT7PAU04U-1Y J T7PAU04U AD
IC302 VHICS5340CZ-1Y J CS5340CZ AM
IC401 VHIBR24C21F-1Y J BR24C21F AG
IC402 VHINC7WZ14P-1Y J NC7WZ14P AD
IC403 VHIBR24L02F1EY J BR24L02F1E AE
IC405 VHINC7WZ14P-1Y J NC7WZ14P AD
IC702 VHIMP2367DN-1Y J MP2367DN AH
IC703 VHIMP1415C+-1Y J MP1415C AK
IC704 VHIMM3203B+-1Y J MM3203B AG
IC705 VHIMP1415C+-1Y J MP1415C AK
IC706 VHIMP1415C+-1Y J MP1415C AK
IC707 VHITAR5SB50-1Y J TAR5SB50 AC
IC708 VHIBD9306AF-1Y J BD9306AF AH
IC801 RH-IXC238WJQZQ J IXC238WJQZ BP
IC802 VHIHN24256A-1Y J HN24256A AN
IC803 VHIPQ033DNA-1Y J PQ033DNA AE
IC1001 VHINJM2902V-1Y J NJM2902V AD
IC2001 VHIPST8229N-1Y J PST8229N AC
IC2002 RH-IXC320WJQZQ J IXC320WJQZ AR
IC2004 VHIPQ1LAX95-1Y J PQ1LAX95 AD
IC8201 RH-IXC322WJQZQ J IXC322WJQZ BB
IC8701 VHIS29GL64A-1Q J S29GL64A AV
IC9201 RH-IXC209WJZZQ J IXC209WJZZ AN
IC9202 VHINJM2904V-1Y J NJM2904V AF
TRANSISTORS
Q301 VSRT1N141U/-1Y J RT1N144U AB
Q401 VSRT1N441U/-1Y J RT1N441U AB
Q402 VS2SC3928AR-1Y J 2SC3928AR AB
Q403 VS2SK3019++-1Y J 2SK3019 AB
Q404 VSRT1N441U/-1Y J RT1N441U AB
Q405 VS2SC3928AR-1Y J 2SC3928AR AB
Q406 VS2SC3928AR-1Y J 2SC3928AR AB
Q407 VSUM6K1NTN+-1Y J UM6K1NTN AC
Q701 VSRTQ035P02-1Y J RTQ035P02 AD
Q702 RH-TXA028WJZZY J TXA028WJ AC
Q703 VSRT1N141U/-1Y J RT1N144U AB
Q704 VS2SA1037KQ-1Y J 2SA1037K AA
Q705 VSRSR025N03-1Y J RSR025N03 AE
Q2001 VS2SC3928AR-1Y J 2SC3928AR AB
Q2002 VSRT1N441U/-1Y J RT1N441U AB
Q2003 VSRT1N141U/-1Y J RT1N144U AB
Q2004 VSRT1N141U/-1Y J RT1N144U AB
Q2005 VSRT1N141U/-1Y J RT1N144U AB
Q2006 VS2SC3928AR-1Y J 2SC3928AR AB
DIODES
D301 VHDKDS4148/-1Y J Diode AA
D406 VHD1PS184++-1Y J Diode AB
D411 VHD1PS184++-1Y J Diode AB
D701 VHDDG1M3+++-1Y J Diode AC
D702 VHDKDS4148/-1Y J Diode AA
D703 VHDKDS4148/-1Y J Diode AA
D704 VHDD1FH3+++-1Y J Diode AD
D706 VHDD1FH3+++-1Y J Diode AD
D707 VHDD1FH3+++-1Y J Diode AD
D708 VHDRB160M30-1Y J Diode AC
D801 VHDKDS4148/-1Y J Diode AA
D802 VHDKDS4148/-1Y J Diode AA
D2002 VHDKDS4148/-1Y J Diode AA
D2003 VHDKDS4148/-1Y J Diode AA
D2005 VHDKDS4148/-1Y J Diode AA
D2006 VHDKDS4148/-1Y J Diode AA
D2007 VHDKDS4148/-1Y J Diode AA
D2008 VHDKDS4148/-1Y J Diode AA
D2009 VHDKDS4148/-1Y J Diode AA
PACKAGED CIRCUITS
X301 RCRSCA145WJZZY J Crystal AE
X801 RCRSCA188WJQZY J Crystal AF
X802 RCRSCA164WJQZY J Crystal AE
COILS
L401 VPCUN100KR42NY J Peaking 10 µH AB
L701 RCILPA085WJZZY J Coil AD
L702 VPCBM330K1R7NY J Peaking 33 µH AC
L703 VPCBM330K1R7NY J Peaking 33 µH AC
L704 RCILPA083WJZZY J Coil AD
L705 VPCEM470M3R7NY J Peaking 47 µH AC
L706 RCILPA085WJZZY J Coil AD
L707 RCILPA085WJZZY J Coil AD
L708 RCILPA898WJZZY J Coil AC
L803 VPBGNR22J0000Y J Peaking 0.22µH AC
L804 VPCBM330K1R7NY J Peaking 33µH AC
FILTER
FL2001 RFILZA003WJPZY J Filter AD
CAPACITORS
C301 VCCCCZ1HH180JY J 18p 50V Ceramic AB
C302 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C303 VCCCCZ1HH220JY J 22p 50V Ceramic AB
C304 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C305 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C306 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C307 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C308 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C309 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C310 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C311 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C312 RC-KZA237WJZZY J 10 16V Ceramic AB
C313 RC-KZA237WJZZY J 10 16V Ceramic AB
C314 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C315 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C316 VCKYCY1AB105KY J 1 10V Ceramic AB
C401 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C402 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C403 VCCCCZ1HH330JY J 33p 50V Ceramic AB
C404 VCCCCZ1HH330JY J 33p 50V Ceramic AB
C405 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C406 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C407 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C408 VCCCCY1HH560JY J 56p 50V Ceramic AB
C409 VCCCCY1HH560JY J 56p 50V Ceramic AB
C410 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
