Sharp LC-19SK25U-W User Manual

111
Ref. No. Part No.
★
Description Code Ref. No. Part No.
★
Description Code
LC-19SK25U/U-W
LC-19SB25U/U-W
LC-19SB15U
LC-19D45U
DUNTKE352FM02
MAIN UNIT (Continued)
R2006 VRS-CH1JF101JY J 100 1/16W Metal Oxide AA
R2007 VRS-CZ1JF472JY J 4.7k 1/16W Metal Oxide AA
R2009 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R2010 VRS-CZ1JF473JY J 47k 1/16W Metal Oxide AA
R2013 VRS-CZ1JF473JY J 47k 1/16W Metal Oxide AA
R2014 VRS-CZ1JF473JY J 47k 1/16W Metal Oxide AA
R2015 VRS-CZ1JF473JY J 47k 1/16W Metal Oxide AA
R2016 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2017 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2018 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R2019 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R2020 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R2021 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R2022 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R2023 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2024 VRS-CZ1JF472JY J 4.7k 1/16W Metal Oxide AA
R2025 VRS-CZ1JF472JY J 4.7k 1/16W Metal Oxide AA
R2026 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R2027 VRS-TW2HF101JY J 100 1/2W Metal Oxide AA
R2028 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R2029 VRS-CZ1JF162FY J 1.6k 1/16W Metal Oxide AA
R2030 VRS-CZ1JF153FY J 15k 1/16W Metal Oxide AA
R2031 VRS-CZ1JF103FY J 10k 1/16W Metal Oxide AB
R2032 VRS-CZ1JF472JY J 4.7k 1/16W Metal Oxide AA
R2034 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R2043 VRS-CJ1JF102JY J 1k 1/16W Metal Oxide AA
R2044 VRS-CJ1JF333JY J 33k 1/16W Metal Oxide AA
R2045 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R2046 VRS-CZ1JF333JY J 33k 1/16W Metal Oxide AA
R2047 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R2048 VRS-CJ1JF102JY J 1k 1/16W Metal Oxide AA
R2049 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R2050 VRS-CZ1JF102FY J 1k 1/16W Metal Oxide AA
R2051 VRS-CZ1JF623FY J 62k 1/16W Metal Oxide AA
R2052 VRS-CZ1JF332JY J 3.3k 1/16W Metal Oxide AA
R2053 VRS-CZ1JF472JY J 4.7k 1/16W Metal Oxide AA
R2056 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R2057 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R2058 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R2061 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R2064 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R2068 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R8201 VRS-CZ1JF102FY J 1k 1/16W Metal Oxide AA
R8202 VRS-CZ1JF102FY J 1k 1/16W Metal Oxide AA
R8203 VRS-CY1JF161JY J 160 1/16W Metal Oxide AA
R8228 VRS-CY1JF161JY J 160 1/16W Metal Oxide AA
R8701 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R8702 VRS-CH1JF100JY J 10 1/16W Metal Oxide AA
R8703 VRS-CH1JF100JY J 10 1/16W Metal Oxide AA
R8704 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R8706 VRS-CH1JF100JY J 10 1/16W Metal Oxide AA
R8707 VRS-CH1JF100JY J 10 1/16W Metal Oxide AA
R8708 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R8710 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R9221 VRS-TV1JD101JY J 100 1/16W Metal Oxide AA
R9302 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R9303 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R9304 VRS-CZ1JF512FY J 5.1k 1/16W Metal Oxide AA
R9305 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R9306 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R9308 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R9311 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R9313 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R9314 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R9316 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R9318 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R9320 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R9321 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R9322 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R9323 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R9324 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R9326 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R9361 VRS-CZ1JF223JY J 22k 1/16W Metal Oxide AA
R9362 VRS-CZ1JF472JY J 4.7k 1/16W Metal Oxide AA
R9363 VRS-CZ1JF473JY J 47k 1/16W Metal Oxide AA
R9364 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R9365 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R9366 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R9367 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R9368 VRS-CZ1JF101JY J 100 1/16W Metal Oxide AA
R9369 VRS-CZ1JF220JY J 22 1/16W Metal Oxide AA
R9371 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
FERRITE BEADS
FB301 RBLN-0210TAZZY J Ferrite Bead AB
FB302 RBLN-0210TAZZY J Ferrite Bead AB
FB303 RBLN-0210TAZZY J Ferrite Bead AB
FB401 RBLN-0060TAZZY J Ferrite Bead AB
FB402 RBLN-0060TAZZY J Ferrite Bead AB
FB403 RBLN-0060TAZZY J Ferrite Bead AB
FB404 RBLN-0060TAZZY J Ferrite Bead AB
FB405 RBLN-0051TAZZY J Ferrite Bead AC
FB406 RBLN-0051TAZZY J Ferrite Bead AC
FB701 RBLN-0253TAZZY J Ferrite Bead AA
FB801 RBLN-0253TAZZY J Ferrite Bead AA
FB802 RBLN-0253TAZZY J Ferrite Bead AA
FB803 RBLN-0253TAZZY J Ferrite Bead AA
FB804 RBLN-0253TAZZY J Ferrite Bead AA
FB805 RBLN-0253TAZZY J Ferrite Bead AA
FB806 RBLN-0253TAZZY J Ferrite Bead AA
FB807 RBLN-0253TAZZY J Ferrite Bead AA
FB808 RBLN-0253TAZZY J Ferrite Bead AA
FB809 RBLN-0210TAZZY J Ferrite Bead AB
FB810 RBLN-0210TAZZY J Ferrite Bead AB
FB811 RBLN-0210TAZZY J Ferrite Bead AB
FB812 RBLN-0210TAZZY J Ferrite Bead AB
FB813 RBLN-0210TAZZY J Ferrite Bead AB
FB814 RBLN-0210TAZZY J Ferrite Bead AB
FB815 RBLN-0210TAZZY J Ferrite Bead AB
FB816 RBLN-0210TAZZY J Ferrite Bead AB
FB817 RBLN-0210TAZZY J Ferrite Bead AB
FB818 RBLN-0210TAZZY J Ferrite Bead AB
FB1201 RBLN-0210TAZZY J Ferrite Bead AB
FB1202 RBLN-0210TAZZY J Ferrite Bead AB
FB2001 RBLN-0006TAZZY J Ferrite Bead AB
FB2002 RBLN-0006TAZZY J Ferrite Bead AB
FB2003 RBLN-0006TAZZY J Ferrite Bead AB
FB2004 RBLN-0006TAZZY J Ferrite Bead AB
FB8701 RBLN-0210TAZZY J Ferrite Bead AB
FB9201 RBLN-0006TAZZY J Ferrite Bead AB
FB9202 RBLN-0006TAZZY J Ferrite Bead AB
FB9203 RBLN-0006TAZZY J Ferrite Bead AB
FB9204 RBLN-0006TAZZY J Ferrite Bead AB
MISCELLANEOUS PARTS
J401 QJAKJ0008GEZZ J Jack AD
LUG1201 QLUGHA006WJZZY J Lug AC
LUG1202 QLUGHA006WJZZY J Lug AC
P2001 QPLGNA324WJZZY J Plug AC
P2003 QPLGNA328WJZZY J Plug AD
P801 QPLGNA144WJZZY J Plug AF
SC401 QSOCN0344FJZZ J Socket AM
SC402 QSOCZA136WJZZQ J Socket AG
SC1201 QCNCWA251WJZZY J Connector AH
SC1202 QCNCWA251WJZZY J Connector AH
SC1204 QCNCWA010WJZZY J Connector AE
SC9201 QCNCW2367WJZZY J Connector AG
PSPAHB360WJ00 J Spacer AA
DUNTKE353FM01
SUB UNIT
TUNER
TU1101 RTUDAA016WJQZ J Tuner BD
