112
Ref. No. Part No.
★
Description Code
Ref. No. Part No.
★
Description Code
LC-19SK25U/U-W
LC-19SB25U/U-W
LC-19SB15U
LC-19D45U
DUNTKE353FM01
SUB UNIT (Continued)
INTEGRATED CIRCUITS
IC501 VHIHHC4051F-1Y J HHC4051F AF
IC502 VHIHHC4051F-1Y J HHC4051F AF
IC503 VHIPQ050DNA-1Y J PQ050DNA AE
IC1101 VHIAN5832SA-1Y J AN5832SA AQ
IC1301 VHIBH3544F+-1Y J BH3544F AE
IC1302 VHIYDA147SZ-1Y J YDA147SZ AM
TRANSISTORS
Q501 VS2SC3928AR-1Y J 2SC3928AR AB
Q502 VS2SC3928AR-1Y J 2SC3928AR AB
Q503 VS2SC3928AR-1Y J 2SC3928AR AB
Q504 VS2SC3928AR-1Y J 2SC3928AR AB
Q505 VS2SC3928AR-1Y J 2SC3928AR AB
Q506 VS2SC3928AR-1Y J 2SC3928AR AB
Q507 VS2SC3928AR-1Y J 2SC3928AR AB
Q508 VS2SC3928AR-1Y J 2SC3928AR AB
Q509 VSRT1N141U/-1Y J RT1N144U AB
Q510 VSRT1N141U/-1Y J RT1N144U AB
Q511 VSRT1N141U/-1Y J RT1N144U AB
Q1101 VS2SC3928AR-1Y J 2SC3928AR AB
Q1102 VS2SC3928AR-1Y J 2SC3928AR AB
Q1103 VS2SC3928AR-1Y J 2SC3928AR AB
Q1301 VSRT1N441U/-1Y J RT1N441U AB
Q1303 VSDTC614TK+-1Y J DTC614TK AB
Q1304 VSDTC614TK+-1Y J DTC614TK AB
Q1305 VS2SC3928AR-1Y J 2SC3928AR AB
DIODES
D501 RH-EX0267TAZZY J Diode AB
D502 RH-EX0267TAZZY J Diode AB
D503 RH-EX0267TAZZY J Diode AB
D504 RH-EX0267TAZZY J Diode AB
D505 RH-EX0267TAZZY J Diode AB
D506 RH-EX0267TAZZY J Diode AB
D507 RH-EX0267TAZZY J Diode AB
D508 VHPGPFSV51T-1 J PhotoDiode AF
D1301 VHD1PS184++-1Y J Diode AB
D1302 RH-EX0267TAZZY J Diode AB
D1303 RH-EX0267TAZZY J Diode AB
D1304 RH-EX0262TAZZY J Zener Diode, 7.5V AB
D1309 VHDKDS4148/-1Y J Diode AA
COILS
L501 VPCEM100MR70NY J Peaking 10 µH AC
L1101 VPCNN220J2R9NY J Peaking 22 µH AB
L1102 VPCBM470K2R4NY J Peaking 47 µH AC
L1103 RCILPA950WJZZY J Coil AD
L1301 VPCNN101J7R7NY J Peaking 100 µH AB
L1302 RCILPA950WJZZY J Coil AD
L1303 RCILPA950WJZZY J Coil AD
L1304 RCILPA950WJZZY J Coil AD
L1305 RCILPA950WJZZY J Coil AD
CAPACITORS
C501 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C502 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C503 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C504 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C505 VCKYCY1HB103KY J 0.010 50V Ceramic AA
C506 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C507 VCCCCY1HH220JY J 22p 50V Ceramic AA
C508 VCCCCY1HH220JY J 22p 50V Ceramic AA
C509 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C510 VCCCCY1HH220JY J 22p 50V Ceramic AA
C511 VCCCCY1HH220JY J 22p 50V Ceramic AA
C512 VCCCCY1HH220JY J 22p 50V Ceramic AA
C513 VCCCCY1HH220JY J 22p 50V Ceramic AA
C514 VCKYCY1AB105KY J 1 10V Ceramic AB
C515 VCKYCY1AB105KY J 1 10V Ceramic AB
C516 VCKYCY1AB105KY J 1 10V Ceramic AB
C517 VCKYCY1AB105KY J 1 10V Ceramic AB
C518 VCKYCY1AB105KY J 1 10V Ceramic AB
C519 VCKYCY1AB105KY J 1 10V Ceramic AB
C520 VCKYCY1AB105KY J 1 10V Ceramic AB
C521 VCKYCY1AB105KY J 1 10V Ceramic AB
C522 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C523 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C524 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C525 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C527 VCKYCY1HB472KY J 4700p 50V Ceramic AA
C528 VCKYCY1HB472KY J 4700p 50V Ceramic AA
C1101 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C1102 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C1103 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C1104 VCCCCY1HH220JY J 22p 50V Ceramic AA
C1105 VCCCCY1HH220JY J 22p 50V Ceramic AA
C1106 VCKYTV1CB105KY J 1 16V Ceramic AC
C1107 VCKYTV1CB105KY J 1 16V Ceramic AC
C1108 RC-KZA030WJZZY J 2.2 10V Ceramic AB
C1109 RC-KZA383WJZZY J 10 25V Ceramic AC
C1110 VCKYCY1AB334KY J 0.33 10V Ceramic AB
C1111 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1112 VCCCCY1HH330JY J 33p 50V Ceramic AA
C1113 RC-KZA508WJQZY J 3.3 25V Ceramic AC
C1114 VCCCCY1HH330JY J 33p 50V Ceramic AA
C1115 RC-KZA030WJZZY J 2.2 10V Ceramic AB
C1116 VCKYCY1AB104KY J 0.10 10V Ceramic AA
C1117 VCKYCY1CB223KY J 0.022 16V Ceramic AB
C1118 VCCCCY1HH220JY J 22p 50V Ceramic AA
C1119 VCCCCY1HH220JY J 22p 50V Ceramic AA
C1120 RC-KZA030WJZZY J 2.2 10V Ceramic AB
C1121 RC-KZA069WJZZY J 4.7 10V Ceramic AB
C1122 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1123 VCKYCY1AB104KY J 0.10 10V Ceramic AA
C1124 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C1125 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C1126 VCKYCY1CB224KY J 0.22 16V Ceramic AB
C1127 VCKYCY1AB104KY J 0.10 10V Ceramic AA
C1128 RC-KZA030WJZZY J 2.2 10V Ceramic AB
C1129 VCKYCY1AB334KY J 0.33 10V Ceramic AB
C1130 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C1131 VCERML1CN476MY J 47 16V CAPACITOR(AL) AC
C1132 VCEASX0JN107MY J 100 6.3V Electrolytic AC
C1301 VCKYCY1AB105KY J 1 10V Ceramic AB
C1302 VCKYCY1AB105KY J 1 10V Ceramic AB
C1303 VCKYCY1AB105KY J 1 10V Ceramic AB
C1304 VCKYCY1AB105KY J 1 10V Ceramic AB
C1305 VCKYCY1AB105KY J 1 10V Ceramic AB
C1306 VCEASX1CN476MY J 47 16V Electrolytic AC
C1308 VCEASX0JN107MY J 100 6.3V Electrolytic AC
C1309 RC-KZA195WJZZY J 10uF 10V Ceramic AB
C1310 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C1311 VCEASX1CN107MY J 100 16V Electrolytic AC
C1312 VCEASX1CN107MY J 100 16V Electrolytic AC
C1313 VCKYCY1AB105KY J 1 10V Ceramic AB
C1314 VCKYCY1AB105KY J 1 10V Ceramic AB
C1316 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1317 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1318 VCKYCY1EF104ZY J 0.10 25V Ceramic AA
C1319 VCKYCY1AB105KY J 1 10V Ceramic AB
C1320 VCKYCY1AB105KY J 1 10V Ceramic AB
C1321 VCKYCY1AB105KY J 1 10V Ceramic AB
C1322 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C1323 VCEASY1CN227MY J 220 16V Electrolytic AC
C1324 RC-KZA114WJZZY J 1uF 25V Ceramic AB
C1325 RC-KZA114WJZZY J 1uF 25V Ceramic AB
C1326 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C1327 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C1328 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C1329 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C1330 VCKYTV1CB474KY J 0.47 16V Ceramic AC
C1331 RC-KZA114WJZZY J 1uF 25V Ceramic AB
C1332 RC-KZA114WJZZY J 1uF 25V Ceramic AB
C1334 VCKYTV1CB474KY J 0.47 16V Ceramic AC
C1336 VCKYCZ1HB102KY J 1000p 50V Ceramic AB
