113
Ref. No. Part No.
★
Description Code Ref. No. Part No.
★
Description Code
LC-19SK25U/U-W
LC-19SB25U/U-W
LC-19SB15U
LC-19D45U
DUNTKE353FM01
SUB UNIT (Continued)
C1341 VCKYCZ1HB102KY J 1000p 50V Ceramic AB
RESISTORS
R507 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R508 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R509 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R510 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R511 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R512 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R513 VRS-CY1JF303JY J 30k 1/16W Metal Oxide AA
R514 VRS-CY1JF303JY J 30k 1/16W Metal Oxide AA
R515 VRS-CY1JF303JY J 30k 1/16W Metal Oxide AA
R516 VRS-CY1JF303JY J 30k 1/16W Metal Oxide AA
R517 VRS-CY1JF303JY J 30k 1/16W Metal Oxide AA
R518 VRS-CY1JF303JY J 30k 1/16W Metal Oxide AA
R519 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R520 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R521 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R522 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R523 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R524 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R525 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R526 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R527 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R528 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R529 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R530 VRS-CY1JF271JY J 270 1/16W Metal Oxide AA
R531 VRS-CY1JF271JY J 270 1/16W Metal Oxide AA
R532 VRS-CY1JF271JY J 270 1/16W Metal Oxide AA
R533 VRS-CY1JF271JY J 270 1/16W Metal Oxide AA
R534 VRS-CY1JF271JY J 270 1/16W Metal Oxide AA
R535 VRS-CY1JF271JY J 270 1/16W Metal Oxide AA
R536 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R537 VRS-CH1JF104JY J 100k 1/16W Metal Oxide AA
R538 VRS-CH1JF104JY J 100k 1/16W Metal Oxide AA
R539 VRS-CH1JF104JY J 100k 1/16W Metal Oxide AA
R540 VRS-CH1JF104JY J 100k 1/16W Metal Oxide AA
R545 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R546 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R547 VRS-CY1JF680JY J 68 1/16W Metal Oxide AA
R548 VRS-CY1JF680JY J 68 1/16W Metal Oxide AA
R549 VRS-CY1JF393JY J 39k 1/16W Metal Oxide AA
R550 VRS-CY1JF393JY J 39k 1/16W Metal Oxide AA
R551 VRS-CH1JF393JY J 39k 1/16W Metal Oxide AA
R552 VRS-CH1JF393JY J 39k 1/16W Metal Oxide AA
R553 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R554 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R555 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R556 VRS-CY1JF474JY J 470k 1/16W Metal Oxide AA
R557 VRS-CY1JF474JY J 470k 1/16W Metal Oxide AA
R558 VRS-CY1JF474JY J 470k 1/16W Metal Oxide AA
R559 VRS-CY1JF474JY J 470k 1/16W Metal Oxide AA
R560 VRS-CY1JF474JY J 470k 1/16W Metal Oxide AA
R561 VRS-CY1JF474JY J 470k 1/16W Metal Oxide AA
R1101 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R1102 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R1103 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R1104 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1105 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1106 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1107 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1108 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1109 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1110 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1111 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1112 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1115 VRS-CY1JF184JY J 180k 1/16W Metal Oxide AA
R1117 VRS-CY1JF153JY J 15k 1/16W Metal Oxide AA
R1118 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R1119 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1120 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R1121 VRS-CY1JF331JY J 330 1/16W Metal Oxide AA
R1122 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1123 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1124 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R1125 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1126 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R1127 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1129 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1301 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1302 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R1303 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R1305 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R1306 VRS-CY1JF182JY J 1.8k 1/16W Metal Oxide AA
R1307 VRS-CY1JF182JY J 1.8k 1/16W Metal Oxide AA
R1308 VRS-TW2ED220JY J 22 1/4W Metal Oxide AB
R1309 VRS-TW2ED220JY J 22 1/4W Metal Oxide AB
R1311 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1312 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1313 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1314 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R1315 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R1316 VRS-TW2ED220JY J 22 1/4W Metal Oxide AB
R1317 VRS-TW2ED220JY J 22 1/4W Metal Oxide AB
R1318 VRS-CY1JF183JY J 18k 1/16W Metal Oxide AA
R1319 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R1320 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R1322 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R1323 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1324 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R1326 VRS-CZ1JF182JY J 1.8k 1/16W Metal Oxide AA
R1328 VRS-CZ1JF224JY J 220k 1/16W Metal Oxide AA
R1329 VRS-CZ1JF562JY J 5.6k 1/16W Metal Oxide AA
R1330 VRS-CZ1JF562JY J 5.6k 1/16W Metal Oxide AA
R1331 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1332 VRS-CY1JF184JY J 180k 1/16W Metal Oxide AA
R1333 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1334 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
FERRITE BEADS
FB501 RBLN-A045WJZZY J Ferrite Bead AB
FB502 RBLN-A045WJZZY J Ferrite Bead AB
FB503 RBLN-A045WJZZY J Ferrite Bead AB
FB504 RBLN-A045WJZZY J Ferrite Bead AB
FB505 RBLN-A045WJZZY J Ferrite Bead AB
FB506 RBLN-A045WJZZY J Ferrite Bead AB
FB507 RBLN-A204WJZZY J Ferrite Bead AA
FB508 RBLN-A204WJZZY J Ferrite Bead AA
FB509 RBLN-A204WJZZY J Ferrite Bead AA
FB510 RBLN-A204WJZZY J Ferrite Bead AA
FB511 RBLN-A204WJZZY J Ferrite Bead AA
FB512 RBLN-A204WJZZY J Ferrite Bead AA
FB1101 RBLN-A206WJZZY J Ferrite Bead AA
FB1102 RBLN-A206WJZZY J Ferrite Bead AA
FB1103 RBLN-A206WJZZY J Ferrite Bead AA
FB1301 RBLN-A215WJZZY J Ferrite Bead AB
FB1302 RBLN-A215WJZZY J Ferrite Bead AB
FB1303 RBLN-A215WJZZY J Ferrite Bead AB
FB1304 RBLN-A215WJZZY J Ferrite Bead AB
MISCELLANEOUS PARTS
J501 QJAKKA007WJZZ J Jack AG
J502 QTANZA050WJZZ J Terminal AG
J503 QJAKFA060WJZZ J Jack AD
J1301 QJAKJA014WJZZ J Jack AD
P501 QCNCMA250WJZZ J Connector AE
P502 QCNCMA250WJZZ J Connector AE
P1301 QPLGNA160WJZZY J Plug AD
TP501 QLUGHA006WJZZY J Lug AC
TP502 QLUGHA006WJZZY J Lug AC
PSPAHB360WJ00 J Spacer AA
