Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
117
LC-22AD1E
DUNTKC162DE01
R/C, LED Unit
INTEGRATED CIRCUIT
IC101 VHiTPS850++-1Y J TPS850 AG
TRANSISTORS
Q101 VS2SC2712Y/-1Y J 2SC2712Y AB
Q102 VS2SC3928AR-1Y J 2SC3928AR AB
Q103 VS2SC2712Y/-1Y J 2SC2712Y AB
Q104 VS2SC3928AR-1Y J 2SC3928AR AB
Q105 VS2SC2712Y/-1Y J 2SC2712Y AB
Q106 VS2SC2712Y/-1Y J 2SC2712Y AB
DIODES AND LED’S
D101 RH-EXA092WJZZY J Zener Diode AB
D102 RH-PX0421CEZZY J Photo Diode, AD
POWER INDICATOR
D103 RH-PX0198TAZZY J Photo Diode, AC
OPC INDICATOR
D104 RH-PX0419CEZZY J Photo Diode, AC
R/C INDICATOR
CAPACITORS
C101 VCKYTV1CF225ZY J 2.2 16V Ceramic AB
C103 VCEASX1HN106MY J 10 50V Electrolytic AC
C104 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C105 VCKYCY1HB222KY J 2200p 50V Ceramic AA
C106 VCKYCY1HB222KY J 2200p 50V Ceramic AA
RESISTORS
R101 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R104 VRS-CY1JF393JY J 39k 1/16W Metal Oxide AA
R105 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R106 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R107 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R109 VRS-CY1JF273FY J 27k 1/16W Metal Oxide AA
R110 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R112 VRS-CY1JF273FY J 27k 1/16W Metal Oxide AA
R113 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R115 VRS-CY1JF273FY J 27k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
J101 QJAKJ0068CEZZ J Jack, Headphone AG
P101 QPLGNA066WJZZ J Plug, 12pin (RA) AD
RMC101
RRMCU0239CEZZ J Remote Receiver AG
SLD1 PSLDM4646CEFW J Shield (Remote Receiver) AD
DUNTKC163DE01
OPERATION Unit
DIODES
D131 RH-EXA092WJZZY J Zener Diode, 12V AB
D132 RH-EXA092WJZZY J Zener Diode, 12V AB
RESISTORS
R131 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R132 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R133 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R134 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
SWITCHES
S131 QSW-K0108CEZZY J Switch, Vol (-) AD
S132 QSW-K0108CEZZY J Switch, Vol (+) AD
S133 QSW-K0108CEZZY J Switch, CH down AD
S134 QSW-K0108CEZZY J Switch, CH up AD
S135 QSW-K0108CEZZY J Switch, MENU AD
S136 QSW-P0035GEZZ J Switch,
MAIN POWER
AF
S137 QSW-K0108CEZZY J Switch, TV/VIDEO AD
MISCELLANEOUS PART
P132 QPLGN0564TAZZY J Plug, 5pin (KA) AC
To Next Page
