Sharp LC-22AD1E User Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
118
LC-22AD1E
DUNTKC164DE01
EXT-SP TERMINAL Unit
FB207 RBLN-0250TAZZY J Ferrite Bead AC
FB208 RBLN-0250TAZZY J Ferrite Bead AC
FB209 RBLN-0250TAZZY J Ferrite Bead AC
FB210 RBLN-0250TAZZY J Ferrite Bead AC
P202 QPLGNA058WJZZ J Plug, 4pin (SD) AC
P203 QTANAA003WJZZ J Terminal, 4pin AH
DUNTKC165DE01
SP-JACK Unit
FB202 RBLN-0250TAZZY J Ferrite Bead AC
FB203 RBLN-0250TAZZY J Ferrite Bead AC
FB204 RBLN-0250TAZZY J Ferrite Bead AC
FB205 RBLN-0250TAZZY J Ferrite Bead AC
J201 QJAKFA020WJZZ J Jack, 4pin AE
P201 QPLGNA058WJZZ J Plug, 4pin (SD) AC
DUNTKC166DE01
MAIN Unit
TUNER
NOTE: THE PARTS HERE SHOWN ARE SUPPIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
TU1101 VTUVT4T5FD532 J VHF Tuner BK
INTEGRATED CIRCUITS
IC401 VHiBA7046F/-1Y J BA7046F AF
IC801 VHiVPC3230D1EQ J VPC3230D-QA-B3 BD
IC802 VHiPQ1CZ21H-1Y J PQ1CZ21H2ZP AH
IC803 VHiBA033FP/-1Y J BA033FP-E2 AG
IC1601 VHiSDA5550M-1Y J SDA5550M-QB AY
IC1602 RH-iXA134WJN5Q J MBM29DL400TC90 AQ
IC1603 VHi62S8308X-1Q J A62S8308X-70SI AY
IC1604 VHiMM1501XN-1Y J MM1501XNRE AE
IC1605 VHi7WH157FK-1Y J TC7WH157FK AF
IC1606 VHiBA033FP/-1Y J BA033FP-E2 AG
IC1607 VHiPST9121N-1Y J IC-PST9121NR AE
IC1608 VHiLVC157T+-1Y J SN74LVC157APWR AF
IC1609 VHiLVC04AT+-1Y J SN74LVC04APWR AE
IC1610 VHiBA05FP++-1Y J BA05FP-E2 AF
IC1611 VHiPST9128N-1Y J IC-PST9128NR AE
IC1613 VHiBA025FP+-1Y J BA25BC0FP-E2 AG
IC1614 VHiTCVHC08T-1Y J TC74VHC08FT AF
IC1615 VHi74LVX86T-1Y J TC74LVX86FT AF
IC1616 VHiNC7SZ58P-1Y J NC7SZ58P6X AE
IC1623 VHiBA7046F/-1Y J BA7046F AF
IC1630 VHiNJM2584M-1Y J NJM2584M(TE1) AG
IC2510 RH-iXA385WJZZQ J KZ4E101811WFP AX
IC2511 VHiPST9128N-1Y J IC-PST9128NR AE
IC2521 VHiCXA2040A-1Q J CXA2040AQ AQ
IC2522 VHiMM1506XN-1Y J MM1506XNRE AD
IC2523 VHiMM1506XN-1Y J MM1506XNRE AD
IC2524 VHiMM1501XN-1Y J MM1501XNRE AE
IC3202 RH-iXA416WJZZQ J MSP4450G-QA-B8 BC
IC3203 VHiBH3543F+-1Y J BH3543F-E2 AE
IC3208 VHiNJM2584M-1Y J NJM2584M(TE1) AG
IC3209 VHiCD4052SJ-1Y J CD4052BCSJX AD
IC3401 RH-iXA167WJZZY J PQ025EZ01ZZ AL
IC3402 VHiTCHCT32F-1Y J TC74HCT32AF AD
IC3403 VHiTC7SH08U-1Y J TC7SH08FU AF
IC3405 VHiNJU26150-1Q J NJU26150FR1 AV
IC3406 VHiNJU26106-1Q J NJU26106FR1 AT
IC3407 RH-iXA707WJN1Y J AT24C64AN-10SI AL
IC3408 VHiNJM4565M-1Y J NJM4565M AE
IC3410 VHiBA05SFP+-1Y J BA05SFP-E2 AG
IC3411 VHiTC7SH08U-1Y J TC7SH08FU AF
IC3412 VHiTC7SH08U-1Y J TC7SH08FU AF
IC3501 RH-iXA799WJN1Q J M306V7FHFP BG
IC3502 VHiPST529JM-1Y J PST529JMT AE
IC3503 VHiBR2416E2-1Y J BR24C16F AK
IC3504 VHiTC7W66U/-1Y J TC7W66FU AE
IC3505 VHiBR24C32F-1Y J BR24C32F-E2 AH
IC3506 VHiTC7W66U/-1Y J TC7W66FU AE
IC3510 VHiPQ20VZ11-1Y J PQ20VZ11 AG
IC3512 VHiBA033FP/-1Y J BA033FP-E2 AG
IC3513 VHiHHCT244F-1Y J HD74HCT244FPEL AE
IC3642 VHiTC7W66U/-1Y J TC7W66FU AE
IC3643 VHiTC7W66U/-1Y J TC7W66FU AE
IC3645 VHiTC7W66U/-1Y J TC7W66FU AE
IC3700 VHiNJM2377M-1Y J NJM2377M AK
IC3701 VHiNJM2147M-1Y J NJM2147M-TE1 AF
IC3702 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC4501 VHi74LVC74A-1Y J SN74LVC74APWR AE
IC4502 VHi74LVC74A-1Y J SN74LVC74APWR AE
IC4503 VHi74LVC74A-1Y J SN74LVC74APWR AE
IC4504 VSSi4884DY+-1Y J SI4884DY-T1 AG
IC4505 VHiPQ1CZ21H-1Y J PQ1CZ21H2ZP AH
IC4506 VHi74LVC2G4-1Y J SN74LVC2G04DCK AD
IC4507 VHiLT1615ES-1Y J LT1615ES5 AP
IC4508 VHiLT1617ES-1Y J LT1617ES5 AP
IC4509 VHiLTC1872+-1Y J LTC1872ES6 AR
IC4510 VHiiCS570B+-1Y J ICS570BT AQ
