LC-24LE210
LC-24LE220
Removing of major parts (Continued)
6
Control cover
Control button
KEY UNIT
[KM]
SP-R
SP-L
[LV]
[LV]
[KM]
[SP]
[LA]
[RA]
[RA]
[PD]
[PD]
[LA]
3. Disconnect all the connectors from all the PWBs.
4. Remove the Key Unit Ass’y
.
6
