Sharp LC-24LE210E Service Manual

71
LC-24LE210
LC-24LE220
REF No. PARTS DESCRIPTION *
SN CODE EX CODE
R 0391 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 0394 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 0397 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 0398 VRS-CZ1JF682FY RES 0402 6,8KOHM 1% 1/16W SMD S AA AA
R 0403 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD S AA AA
R 0404 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD S AA AA
R 0407 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD S AA AA
R 0413 VRS-CZ1JF100JY RES 0402 10 OHM 5% 1/16W SMD S AA AA
R 0414 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 0415 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 0417 VRS-CY1JF103JY RES 0603 10KOHM 5% 1/10W SMD S AA AA
R 0418 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 0419 VRS-CY1JF100JY RES 0603 10 OHM 5% 1/10W SMD S AA AA
R 0420 VRS-CY1JF472JY RES 0603 4,7KOHM 5% 1/10W SMD S AA AA
R 0421 VRS-CY1JF472JY RES 0603 4,7KOHM 5% 1/10W SMD S AA AA
R 0422 VRS-CY1JF472JY RES 0603 4,7KOHM 5% 1/10W SMD S AA AA
R 0423 VRS-CY1JF220JY RES 0603 22 OHM 5% 1/10W SMD S AA AA
R 0424
VRS
-
CY1JF103JY
RES 0603 10KOHM 5% 1/10W SMD
S
AA
AA
R
0424
VRS
-
CY1JF103JY
RES
0603
10KOHM
5%
1/10W
SMD
S
AA
AA
R 0425 VRS-CZ1JF220JY RES 0402 22 OHM 5% 1/16W SMD S AA AA
R 0426 VRS-CY1JF473JY RES 0603 47KOHM 5% 1/10W SMD S AA AA
R 0427 VRS-CY1JF472JY RES 0603 4,7KOHM 5% 1/10W SMD S AA AA
R 0447 VRS-CZ1JF102JY RES 0402 1KOHM 5% 1/16W SMD S AA AA
R 0448 VRS-CZ1JF152JY RES 0402 1,5KOHM 5% 1/16W SMD S AA AA
R 0450 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0452 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0453 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0455 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0482
VRS CZ1JF221JY
RES 0402 220 OHM 5% 1/16W SMD
S
AA
AA
R 0482 VRS-CZ1JF221JY RES 0402 220 OHM 5% 1/16W SMD S AA AA
R 0484 VRS-CZ1JF221JY RES 0402 220 OHM 5% 1/16W SMD S AA AA
R 0485 VRS-CZ1JF472JY RES 0402 4,7KOHM 5% 1/16W SMD S AA AA
R 0486 VRS-CZ1JF472JY RES 0402 4,7KOHM 5% 1/16W SMD S AA AA
R 0498 VRS-CZ1JF472JY RES 0402 4,7KOHM 5% 1/16W SMD S AA AA
R 0500 VRS-CZ1JF472JY RES 0402 4,7KOHM 5% 1/16W SMD S AA AA
R 0501 VRS-CZ1JF102JY RES 0402 1KOHM 5% 1/16W SMD S AA AA
R 0502 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD S AA AA
R 0503 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 0504 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD S AA AA
R 0505 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD S AA AA
R 0509 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 0510 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD S AA AA
R 0511 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD S AA AA
R 0512 VRS-CZ1JF100JY RES 0402 10 OHM 5% 1/16W SMD S AA AA
R 0513 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 0522 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD S AA AA
R 0530 VRS-CZ1JF620JY RES 0402 62 OHM 5% 1/16W SMD S AA AA
R 0534 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0535 VRS-CZ1JF220JY RES 0402 22 OHM 5% 1/16W SMD S AA AA
R
0535
VRS CZ1JF220JY
RES
0402
22
OHM
5%
1/16W
SMD
S
AA
AA
R 0536 VRS-CZ1JF220JY RES 0402 22 OHM 5% 1/16W SMD S AA AA
R 0537 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD S AA AA
R 0538 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD S AA AA
R 0540 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0542 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD S AA AA
R 0543 VRS-CZ1JF331JY RES 0402 330 OHM 5% 1/16W SMD S AA AA
R 0544 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 0545 VRS-CZ1JF331JY RES 0402 330 OHM 5% 1/16W SMD S AA AA
R 0546 VRS-CZ1JF392JY RES 0402 3,9KOHM 5% 1/16W SMD S AA AA
R 0547
VRS-CZ1JF151JY
RES 0402 150 OHM 5% 1/16W SMD
S
AA
AA
R
0547
VRS
-
CZ1JF151JY
RES
0402
150
OHM
5%
1/16W
SMD
S
AA
AA
R 0549 VRS-CY1JF100JY RES 0603 10 OHM 5% 1/10W SMD S AA AA
R 0550 VRS-CZ1JF472JY RES 0402 4,7KOHM 5% 1/16W SMD S AA AA
R 0551 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 0554 VRS-CZ1JF102JY RES 0402 1KOHM 5% 1/16W SMD S AA AA
R 0555 VRK-SB1FF560JY RES 56 OHM 5% 1/32W SMD S AA AA
R 0556 VRK-SB1FF560JY RES 56 OHM 5% 1/32W SMD S AA AA
R 0560 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 0658 VRS-CZ1JF822JY RES 0402 8,2KOHM 5% 1/16W SMD S AA AA
R 0702 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 0703
VRS CZ1JF103JY
RES 0402 10KOHM 5% 1/16W SMD
S
AA
AA
R 0703 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 1001 VRK-SB1FF330JY RES 33 OHM 5% 1/32W SMD S AA AA
R 1002 VRK-SB1FF330JY RES 33 OHM 5% 1/32W SMD S AA AA
R 1003 VRK-SB1FF330JY RES 33 OHM 5% 1/32W SMD S AA AA
R 1004 VRK-SB1FF330JY RES 33 OHM 5% 1/32W SMD S AA AA
R 1005 VRK-SB1FF330JY RES 33 OHM 5% 1/32W SMD S AA AA
R 1006 VRK-SB1FF330JY RES 33 OHM 5% 1/32W SMD S AA AA
R 1007 VRK-SB1FF330JY RES 33 OHM 5% 1/32W SMD S AA AA
R 1008 VRK-SB1FF330JY RES 33 OHM 5% 1/32W SMD S AA AA
R 1009 VRK-SB1FF560JY RES 56 OHM 5% 1/32W SMD S AA AA
R 1010 VRK-SB1FF560JY RES 56 OHM 5% 1/32W SMD S AA AA
R 1011 VRK-SB1FF560JY RES 56 OHM 5% 1/32W SMD S AA AA
R 1012 VRK-SB1FF560JY RES 56 OHM 5% 1/32W SMD S AA AA
R 1013 VRK-SB1FF560JY RES 56 OHM 5% 1/32W SMD S AA AA
R 1014 VRK-SB1FF560JY RES 56 OHM 5% 1/32W SMD S AA AA
R 1015 VRK-SB1FF560JY RES 56 OHM 5% 1/32W SMD S AA AA
R 1016 VRK-SB1FF560JY RES 56 OHM 5% 1/32W SMD S AA AA
R 1017 VRK-SB1FF560JY RES 56 OHM 5% 1/32W SMD S AA AA
REF No. PARTS DESCRIPTION *
SN CODE EX CODE
R 1018 VRK-SB1FF560JY RES 56 OHM 5% 1/32W SMD S AA AA
R 1019 VRK-SB1FF560JY RES 56 OHM 5% 1/32W SMD S AA AA
R 1020 VRK-SB1FF560JY RES 56 OHM 5% 1/32W SMD S AA AA
R 1021 VRK-SB1FF560JY RES 56 OHM 5% 1/32W SMD S AA AA
R 1022 VRK-SB1FF560JY RES 56 OHM 5% 1/32W SMD S AA AA
R 1109 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 1121 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 1123 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 1174 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 1228 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 1318 VRS-CY1JF472JY RES 0603 4,7KOHM 5% 1/10W SMD S AA AA
R 1514 VRS-CZ1JF220JY RES 0402 22 OHM 5% 1/16W SMD S AA AA
R 1517 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD S AA AA
R 1525 VRS-CZ1JF220JY RES 0402 22 OHM 5% 1/16W SMD S AA AA
R 1526 VRK-SB1FF220JY RES 22 OHM 5% 1/32W SMD S AA AA
R 1527 VRK-SB1FF220JY RES 22 OHM 5% 1/32W SMD S AA AA
R 2081 VRS-CZ1JF151JY RES 0402 150 OHM 5% 1/16W SMD S AA AA
R 2082
VRS
-
CZ1JF151JY
RES 0402 150 OHM 5% 1/16W SMD
S
AA
AA
R
2082
VRS
-
CZ1JF151JY
RES
0402
150
OHM
5%
1/16W
SMD
S
AA
AA
R 2314 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 2315 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 8133 VRS-CZ1JF471JY RES 0402 470 OHM 5% 1/16W SMD S AA AA
R 8136 VRS-CZ1JF221JY RES 0402 220 OHM 5% 1/16W SMD S AA AA
R 8137 VRS-CZ1JF822JY RES 0402 8,2KOHM 5% 1/16W SMD S AA AA
R 8138 VRS-CY1JF100JY RES 0603 10 OHM 5% 1/10W SMD S AA AA
R 8139 VRS-CY1JF100JY RES 0603 10 OHM 5% 1/10W SMD S AA AA
R 8140 VRS-CY1JF100JY RES 0603 10 OHM 5% 1/10W SMD S AA AA
R 8141 VRS-CY1JF273JY S. CHIP RES. 27-OHM TAPED S AA AA
R8142
VRS CZ1JF221JY
RES 0402 220 OHM 5% 1/16W SMD
S
AA
AA
R 8142 VRS-CZ1JF221JY RES 0402 220 OHM 5% 1/16W SMD S AA AA
R 8143 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD S AA AA
R 8144 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD S AA AA
R 8145 VRS-CZ1JF333JY RES 0402 33KOHM 5% 1/16W SMD S AA AA
R 8146 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 8147 VRS-CZ1JF333JY RES 0402 33KOHM 5% 1/16W SMD S AA AA
R 8148 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 8149 VRS-CZ1JF473JY RES 0402 47KOHM 5% 1/16W SMD S AA AA
R 8150 VRS-CY1JF104JY RES 0603 100KOHM 5% 1/10W SMD S AA AA
R 8159 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 8164 VRS-CY1JF104JY RES 0603 100KOHM 5% 1/10W SMD S AA AA
R 8166 VRS-CZ1JF104JY RES 0402 100KOHM 5% 1/16W SMD S AA AA
R 8167 VRS-CZ1JF471JY RES 0402 470 OHM 5% 1/16W SMD S AA AA
R 8168 VRS-CZ1JF333JY RES 0402 33KOHM 5% 1/16W SMD S AA AA
R 8169 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 8170 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 8171 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 8173 VRS-CZ1JF104JY RES 0402 100KOHM 5% 1/16W SMD S AA AA
R 8174 VRS-CZ1JF471JY RES 0402 470 OHM 5% 1/16W SMD S AA AA
R 8175 VRS-CZ1JF333JY RES 0402 33KOHM 5% 1/16W SMD S AA AA
R
8175
VRS CZ1JF333JY
RES
0402
33KOHM
5%
1/16W
SMD
S
AA
AA
R 8176 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD S AA AA
R 8178 VRS-CZ1JF104JY RES 0402 100KOHM 5% 1/16W SMD S AA AA
R 8179 VRS-CZ1JF104JY RES 0402 100KOHM 5% 1/16W SMD S AA AA
R 8180 VRS-CY1JF101JY RES 0603 100 OHM 5% 1/10W SMD S AA AA
R 8181 VRS-CY1JF101JY RES 0603 100 OHM 5% 1/10W SMD S AA AA
R 8184 VRS-CZ1JF104JY RES 0402 100KOHM 5% 1/16W SMD S AA AA
DM 0002 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD - ONLY FOR LC24LE220E S AA AA
FB 0014 VRS-CY1JF000JY RES 0603 0 OHM 5% 1/10W SMD S AA AA
MISCELLANEOUS PARTS
FB 0015 RBLN-A529WJZZY FERRITE MI0603M121R-10 S AA AA
FB 0016 RBLN-A529WJZZY FERRITE MI0603M121R-10 S AA AA
FB 0017 RBLN-A529WJZZY FERRITE MI0603M121R-10 S AA AA
FB 0018 VRS-CY1JF000JY RES 0603 0 OHM 5% 1/10W SMD S AA AA
FB 0019 VRS-CY1JF000JY RES 0603 0 OHM 5% 1/10W SMD S AA AA
FB 0020 VRS-CY1JF000JY RES 0603 0 OHM 5% 1/10W SMD S AA AA
FB 0201 RBLN-A529WJZZY FERRITE MI0603M121R-10 S AA AA
FB 0202 RBLN-A529WJZZY FERRITE MI0603M121R-10 S AA AA
FB 0203 RBLN-A529WJZZY FERRITE MI0603M121R-10 S AA AA
FB 0204
RBLN
-
A529WJZZY
FERRITE MI0603M121R
-
10
S
AA
AA
FB
0204
RBLN
-
A529WJZZY
FERRITE
MI0603M121R
-
10
S
AA
AA
FB 0205 RBLN-A529WJZZY FERRITE MI0603M121R-10 S AA AA
FB 0206 RBLN-A529WJZZY FERRITE MI0603M121R-10 S AA AA
FB 0207 RBLN-A529WJZZY FERRITE MI0603M121R-10 S AA AA
FB 0208 RBLN-A529WJZZY FERRITE MI0603M121R-10 S AA AA
FB 0301 RBLN-A528WJZZY FERRITE HI0805N600R-10 S AA AA
FB 1501 RBLN-A529WJZZY FERRITE MI0603M121R-10 S AA AA
FB 1502 RBLN-A529WJZZY FERRITE MI0603M121R-10 S AA AA
FB 1503 RBLN-A529WJZZY FERRITE MI0603M121R-10 S AA AA
J 1003 QJAKJA024WJZZ HEADPHONE CKX-035-347DBZ S AA AB
J1301
QJAKJ0047CEZZ
EARPHONE JACK HSJ0998 72
S
AA
AG
J 1301 QJAKJ0047CEZZ EARPHONE JACK HSJ0998-72 S AA AG
J 1305 QJAKEA086WJ00 JACK RCA-101H(BK) S AA AB
J 1401 QJAKKA007WJZZ JACK RCA--512HAT-00A-03 S AB AE
J 4001 QJAKJA024WJZZ HEADPHONE CKX-035-347DBZ S AA AB
J 8101 QSOCZA205WJQZ SOCKET UAR27-4K5C0L S AA AB
LUG1701 QLUGHA006WJZZY METALLIC LUG SD01138-21 S AA AA
LUG1702 QLUGHA006WJZZY METALLIC LUG SD01138-21 S AA AA
LUG1704 QLUGHA006WJZZY METALLIC LUG SD01138-21 S AA AA
