Sharp LC-24LE210E Service Manual

72
LC-24LE210
LC-24LE220
REF No. PARTS DESCRIPTION *
SN CODE EX CODE
LUG1705 QLUGHA006WJZZY METALLIC LUG SD01138-21 S AA AA
P 1701 QPLGN0185FJZZY CONNECTOR S13B-PH-SM4-TB S AA AC
P 2302 QPLGNA916WJZZY CONNECTOR A1251WRO-5PS-5E JW
T
SAA AB
P 2701 QPLGNA160WJZZY CONNECTOR SM04B-PASS-TBT(LF) S AA AB
P 3072 QPLGNA324WJZZY CONNECTOR SM04B-GHS-(FL)(SN) S AA AB
SC 1101 QSOCZA161WJZZ SCART RGB-11H S AA AD
SC 1501 QSOCNA229WJZZ SOCKET DHR20-151F200/H-DBR10-A0020D S AB AE
SC 1901 QSOCZA175WJZZY CONECTOR HDMI A111924-A-15-R S AB AE
Q
SC 1902 QSOCZA175WJZZY CONECTOR HDMI A111924-A-15-R S AB AE
SC 1903 QSOCZA175WJZZY CONECTOR HDMI A111924-A-15-R S AB AE
SC 4401 QCNCMA332WJSA C.I.CARD SLO
T
SAD AK
SC 8202 QCNCWA995WJZZY CONECTOR LVDS 51 PINS P-TWO 187059-51221 S AB AF
PRDARA577WJFW BL CHASSIS SAA AD
TLABN0134BMZZ CHASSIS LABEL 35X10MM S AA AA
PSPAZC213WJKZ HEAT CONDUCTOR SPACER S AA AD
LE210E/LE220E DUNTKF640FM**
LED Unit
D 5103 RH-PXA195WJQZY LED DIODE SMD BLUE/RED SML522BUWT86 ROHM S AA AC
C 5102 RC-KZA237WJZZY CERAM C EMK212BJ106KGFT 10UF 16V 10% S AA AA
R 5101 VRS-CY1JF101JY RES 0603 100 OHM 5% 1/10W SMD S AA AA
R 5108 VRS-CZ1JF121JY RES 0402 120 OHM 5% 1/16W SMD S AA AA
R 5109 VRS-CY1JF101JY RES 0603 100 OHM 5% 1/10W SMD S AA AA
DIODES
CAPACITORS
RESISTORS
P 5101 QPLGNA916WJZZY CONNECTOR A1251WRO-5PS-5E JW
T
SAA AB
RMC5101 RRMCUA053WJZZ R/C RECEIVER UNI
T
SAA AD
SLD5101 PSLDPA076WJFW SHIELD CASE SAA AA
R 4051 VRD-RA2BE822JY RES 8,2KOHM 5% 1/8W S AA AA
MISCELLANEOUS PARTS
DUNTKF534WE02
KEY Unit
RESISTORS
R 4052 VRD-RA2BE123JY RES 12K OHM 5% 1/8W S AA AA
R 4053 VRD-RA2BE822JY RES 8,2KOHM 5% 1/8W S AA AA
R 4054 VRD-RA2BE123JY RES 12K OHM 5% 1/8W S AA AA
P 4051 QCNCWA012JDE0 CONNECTOR S4B-EH S AA AA
S 4051 QSW-K0003AJZZ+ SWITCH EVQ-11A-05R_A MATSUSHITA S AA AA
S 4052 QSW-K0003AJZZ+ SWITCH EVQ-11A-05R_A MATSUSHITA S AA AA
S 4053 QSW-K0003AJZZ+ SWITCH EVQ-11A-05R_A MATSUSHITA S AA AA
S 4054 QSW-K0003AJZZ+ SWITCH EVQ-11A-05R_A MATSUSHITA S AA AA
4055
QWK0003JZZ
W TCH EVQ 11 05R M T U H T
MISCELLANEOUS PARTS
S 4055 QSW-K0003AJZZ+ SWITCH EVQ-11A-05R_A MATSUSHITA S AA AA
S 4056 QSW-K0003AJZZ+ SWITCH EVQ-11A-05R_A MATSUSHITA S AA AA
S 4057 QSW-K0003AJZZ+ SWITCH EVQ-11A-05R_A MATSUSHITA S AA AA
! RDENCA412WJQZ POWER WITH LED DRIVER 24" (FSP046-3FS01) S AV BG
LE210E/LE220E RDENCA412WJQZ
POWER Unit
