Sharp LC-24LE240E Service Manual

78
LC-24LE240
REF No. PARTS DESCRIPTION *
PRICE
CODE
R1249 30021960 RESSMD1/16W47RJ0402ROHS G ͲͲ
R1265 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1309 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1310 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1311 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1313
30022058
RES SMD 1/16W 22R J 0402 ROHS
G
R1313 30022058 RESSMD1
/
16W22RJ0402ROHS G ͲͲ
R1332 30022058 RESSMD1/16W22RJ0402ROHS G ͲͲ
R1355 30022041 RESSMD1/16W1KF0402ROHS G ͲͲ
R1356 30022041 RESSMD1/16W1KF0402ROHS G ͲͲ
R1357 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1358 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1364 30022041 RESSMD1/16W1KF0402ROHS G ͲͲ
R1365
30022041
RES SMD 1/16W 1K F 0402 ROHS
G
ͲͲ
R1365
30022041
RES

SMD

1/16W

1K

F

0402

ROHS
G
ͲͲ
R1366 30041373 RESSMDNET1/16W22RJ8P0402ROHS G ͲͲ
R1367 30041373 RESSMDNET1/16W22RJ8P0402ROHS G ͲͲ
R1368 30041373 RESSMDNET1/16W22RJ8P0402ROHS G ͲͲ
R1369 30041373 RESSMDNET1/16W22RJ8P0402ROHS G ͲͲ
R1370 30041373 RESSMDNET1/16W22RJ8P0402ROHS G ͲͲ
R1380 30041373 RESSMDNET1/16W22R
J8P0402ROHS G ͲͲ
R1382 30042505 RESSMDNET1
/
32W33RJ8P0402ROHS G ͲͲ
R1382
30042505
RES

SMD

NET

1/32W

33R

J

8P

0402

ROHS
G
R1383 30042505 RESSMDNET1/32W33RJ8P0402ROHS G ͲͲ
R1384 30042505 RESSMDNET1/32W33RJ8P0402ROHS G ͲͲ
R1385 30042505 RESSMDNET1/32W33RJ8P0402ROHS G ͲͲ
R1388 30042505 RESSMDNET1/32W33RJ8P0402ROHS G ͲͲ
R1389 30042505 RESSMDNET1/32W33RJ8P0402ROHS G ͲͲ
R1390 30042505 RESSMDNET1/32W33RJ
8P0402ROHS G ͲͲ
R1392 30042505 RESSMDNET1/32W33RJ8P0402ROHS G ͲͲ
/
R1393 30042505 RESSMDNET1/32W33RJ8P0402ROHS G ͲͲ
R1394 30042505 RESSMDNET1/32W33RJ8P0402ROHS G ͲͲ
R1395 30042505 RESSMDNET1/32W33RJ8P0402ROHS G ͲͲ
R1396 30042505 RESSMDNET1/32W33RJ8P0402ROHS G ͲͲ
R1397 30042505 RESSMDNET1/32W33RJ8P0402ROHS G ͲͲ
R1398 30042505 RESSMDNET1/32W33RJ
8P0402ROHS G ͲͲ
R1399 30042505 RESSMDNET1/32W33RJ8P0402ROHS G ͲͲ
R1401 30022085 RESSMD1/16W33RJ0402RoHS G ͲͲ
R1402 30022085 RESSMD1/16W33RJ0402RoHS G ͲͲ
R1408 30070980 FERRITSMD220R/100Mhz0.35RM0.3A402R G ͲͲ
R1409 30070980 FERRITSMD220R/100Mhz0.35RM0.3A402R G ͲͲ
R1411 30055434 RESSMD1/16W62RJ0402ROHS G ͲͲ
R1412 30055434 RESSMD1/16W62RJ0402ROHS G ͲͲ
R1415 30055434 RESSMD1/16W62RJ0402ROHS G ͲͲ
R1419
30070980
FERRIT SMD 220R/100Mhz 0 35R M 0 3A 402R
G
R1419 30070980 FERRITSMD220R
/
100M
h
z0.35RM0.3A402R G ͲͲ
R1420 30022132 RESSMD1/16W0R0402ROHS G ͲͲ
R1421 30022132 RESSMD1/16W0R0402ROHS G ͲͲ
R1422 30022132 RESSMD1/16W0R0402ROHS G ͲͲ
R1423 30022003 RESSMD1/16W470RJ0402ROHS G ͲͲ
R1424 30022085 RESSMD1/16W33RJ0402RoHS G ͲͲ
R1425 30022085 RESSMD1/16W33RJ0402RoHS G ͲͲ
R1427
30022085
RES SMD 1/16W 33R J 0402 RoHS
G
ͲͲ
R1427
30022085
RES

SMD

1/16W

33R

J

0402

RoHS
G
ͲͲ
R1479 30022118 RESSMD1/16W75RJ0402RoHS G ͲͲ
R1480 30022118 RESSMD1/16W75RJ0402RoHS G ͲͲ
R1481 30022118 RESSMD1/16W75RJ0402RoHS G ͲͲ
R1482 30022118 RESSMD1/16W75RJ0402RoHS G ͲͲ
R1483 30022118 RESSMD1/16W75RJ0402RoHS G ͲͲ
R1486 30022118 RESSMD1/16W75RJ0402RoHS G ͲͲ
R1489 30022118 RESSMD1
/
16W75RJ0402RoHS G ͲͲ
R1489
30022118
RES

SMD

1/16W

75R

J

0402

RoHS
G
R1494 30022003 RESSMD1/16W470RJ0402ROHS G ͲͲ
R1495 30021987 RESSMD1/16W4.7KJ0402RoHS G ͲͲ
R1496 30021987 RESSMD1/16W4.7KJ0402RoHS G ͲͲ
R1505 30022003 RESSMD1/16W470RJ0402ROHS G ͲͲ
R1512 30022085 RESSMD1/16W33RJ0402RoHS G ͲͲ
REF No. PARTS DESCRIPTION *
PRICE
CODE
R1513 30022085 RESSMD1/16W33RJ0402RoHS G ͲͲ
R1514 30022085 RESSMD1/16W33RJ0402RoHS G ͲͲ
R1515 30022118 RESSMD1/16W75RJ0402RoHS G ͲͲ
R1516 30022118 RESSMD1/16W75RJ0402RoHS G ͲͲ
R1517 30022118 RESSMD1/16W75RJ0402RoHS G ͲͲ
R1524
30021987
RES SMD 1/16W 4 7K J 0402 R HS
G
R1524 30021987 RESSMD1
/
16W4.7KJ0402RoHS G ͲͲ
R1527 30021987 RESSMD1/16W4.7KJ0402RoHS G ͲͲ
R1528 30021987 RESSMD1/16W4.7KJ0402RoHS G ͲͲ
R1530 30022132 RESSMD1/16W0R0402ROHS G ͲͲ
R1533 30022043 RESSMD1/16W1MJ0402ROHS G ͲͲ
R1543 30021991 RESSMD1/16W100RJ0402ROHS G ͲͲ
R1562 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1563
30021996
RES SMD 1/16W 10K J 0402 ROHS
G
ͲͲ
R1563
30021996
RES

SMD

1/16W

10K

J

0402

ROHS
G
ͲͲ
R1567 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1568 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1569 30022056 RESSMD1/16W220RJ0402RoHS G ͲͲ
R1570 30022056 RESSMD1/16W220RJ0402RoHS G ͲͲ
R1571 30022056 RESSMD1/16W220RJ0402RoHS G ͲͲ
R1572 30022056 RESSMD1/16W220RJ0402RoHS G ͲͲ
R1587 30022118 RESSMD1
/
16W75RJ0402RoHS G ͲͲ
R1587
30022118
RES

SMD

1/16W

75R

J

0402

RoHS
G
R1597 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1601 30021987 RESSMD1/16W4.7KJ0402RoHS G ͲͲ
R1603 30022058 RESSMD1/16W22RJ0402ROHS G ͲͲ
R1605 30022084 RESSMD1/16W33KJ0402RoHS G ͲͲ
R1606 30022039 RESSMD1/16W18KF0402RoHS G ͲͲ
R1609 30041373 RESSMDNET1/16W22RJ8P0402ROHS G ͲͲ
R1610 30041373 RESSMDNET1/16W22RJ8P
0402ROHS G ͲͲ
/
R1613 30041373 RESSMDNET1/16W22RJ8P0402ROHS G ͲͲ
R1614 30021987 RESSMD1/16W4.7KJ0402RoHS G ͲͲ
R1615 30021987 RESSMD1/16W4.7KJ0402RoHS G ͲͲ
R1617 30021987 RESSMD1/16W4.7KJ0402RoHS G ͲͲ
R1618 30021987 RESSMD1/16W4.7KJ0402RoHS G ͲͲ
R1619 30022118 RESSMD1/16W75RJ0402RoHS G ͲͲ
R1620 30022118 RESSMD1/16W75RJ0402RoHS G
ͲͲ
R1621 30022118 RESSMD1/16W75RJ0402RoHS G ͲͲ
R1632 30022041 RESSMD1/16W1KF0402ROHS G ͲͲ
R1635 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1636 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1638 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1639 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1642 30021987 RESSMD1/16W4.7KJ0402RoHS G ͲͲ
R1661
30021987
RES SMD 1/16W 4 7K J 0402 RoHS
G
R1661 30021987 RESSMD1
/
16W4.7KJ0402RoHS G ͲͲ
R1662 30022041 RESSMD1/16W1KF0402ROHS G ͲͲ
R1663 30021987 RESSMD1/16W4.7KJ0402RoHS G ͲͲ
R1666 30021991 RESSMD1/16W100RJ0402ROHS G ͲͲ
R1667 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1668 30022041 RESSMD1/16W1KF0402ROHS G ͲͲ
R1671 30021987 RESSMD1/16W4.7KJ0402RoHS G ͲͲ
R1672
30021987
RES SMD 1/16W 4 7K J 0402 RoHS
G
ͲͲ
R1672
30021987
RES

SMD

1/16W

4
.
7K

J

0402

RoHS
G
ͲͲ
R1676 30022041 RESSMD1/16W1KF0402ROHS G ͲͲ
R1677 30021991 RESSMD1/16W100RJ0402ROHS G ͲͲ
R1678 30021987 RESSMD1/16W4.7KJ0402RoHS G ͲͲ
R1679 30021991 RESSMD1/16W100RJ0402ROHS G ͲͲ
R1684 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1685 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1686 30022099 RESSMD1
/
16W39KJ0402ROHS G ͲͲ
R1686
30022099
RES

SMD

1/16W

39K

J

0402

ROHS
G
R1689 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1691 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1692 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1693 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ
R1697 30021996 RESSMD1/16W10KJ0402ROHS G ͲͲ

Sharp LC-24LE240E Specifications

General

Response time	8 ms
Display diagonal	24 \
Display brightness	250 cd/m²
Native aspect ratio	16:9
LED backlighting type	Edge-LED
Supported video modes	1080p
Contrast ratio (dynamic)	30000:1
Display diagonal (metric)	60 cm
Supported graphics resolutions	1920 x 1080 (HD 1080)
3D	No
Number of AV connections	1
Annual energy consumption	28 kWh
Product color	Black
Mercury content	0 mg
Panel mounting interface	75 x 75 mm
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-T
RMS rated power	5 W
Number of speakers	2
HDMI version	1.3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	0
Video formats supported	DIVX, H.264, MPEG4
Power consumption (off)	0.01 W
Power consumption (standby)	0.5 W
Power consumption (typical)	19 W

Weight and Dimensions

Depth (with stand)	149 mm
Height (with stand)	405 mm
Weight (with stand)	5200 g
Depth (without stand)	36 mm
Width (without stand)	580 mm
Height (without stand)	380 mm
