Sharp LC-26AD5E-BK User Manual

Name: Sharp LC-26AD5E-BK
Brand: Sharp
Rating: 4 (1 reviews)

90 pages

To Next Page

To Previous Page

TROUBLESHOOTING GUIDE

POWER DOES NOT TUNER ON

Is F401 broken?

Is there voltage at pin

10 of IC401 at 18.9V?

Is there voltage at pin

4 of IC402 at 15.1V?

Change F401.

Check IC401 and peripheral

circuit.

Change MAIN PCB.

Yes

Check IC402 and peripheral

circuit. Or change IC402.

Yes

E-1

Table of Contents1
Sharp Corporation1
Service Manual1
Lcd Color Television1
Servicing Notices on Checking2
How to Order Parts2
Important2
- To Set the Hotel Mode3
- To Release the Hotel Mode3
Hotel Mode Function3
- 4 Digit Password Cancellation4
- Distinction of Pbf PCB4
ABOUT LEAD FREE SOLDER (Pbf)4
Parental Control - Rating Level4
General Specifications5
- Removal of Mechanical Parts and P.C. Boards10
- Back Cabinet10
- Operation Pcb10
Disassembly Instructions10
- Cover Lcd11
- Digital Pcb/ Main Pcb11
- Power Pcb11
Service Mode List14
Confirmation of Initial Data15
When Replacing Eeprom (Memory) IC15
Servicing Fixtures and Tools16
Install for Writing Tools16
Re-Write for Digital Soft Firmware17
Update for Vctp Software21
Update for Eeprom Data25
- White Balance27
- Adjustment Procedure27
- Basic Adjustments27
Electrical Adjustments27
- Contrast28
- Electrical Adjustment Parts Location Guide (Wiring Connection)31
- Power Does Not Tuner on32
Troubleshooting Guide32
- The Picture Does Not Appear33
- Tuner/Scart1/Scart2/Rca Audio out Block Diagram39
- Power/Regulator Block Diagram40
- Scaler/Sub Micon Block Diagram41
- Hdmi/D-Sub Block Diagram42
- Sound Amp/Headphone Jack/Component Jack Block Diagram43
- Digital Block Diagram44
- Power Block Diagram45
- Main (Top Side)46
Printed Circuit Boards46
- Main (Bottom Side)47
- Power/Remocon/Operation (Inserted Parts)48
- Solder Side48
- Digital (Top Side)50
- Digital (Bottom Side)50
- 21Pin Schematic Diagram51
- Power3 Schematic Diagram52
- Regulator Schematic Diagram53
- Av Jack/Switch Schematic Diagram54
- Sound Amp/Headphone Amp Schematic Diagram55
- Tuner Schematic Diagram56
- Scaler Schematic Diagram57
- Sub Micon/Rs-232C Schematic Diagram58
- Jack Schematic Diagram59
- Panel Interface Diagram60
- Interface_Hdmi IC Schematic Diagram61
- Power1 Schematic Diagram62
- Power2 Schematic Diagram63
- Operation/Remocon Schematic Diagram64
- Asic Schematic Diagram65
- Sdram Schematic Diagram66
- Common Interface Schematic Diagram67
- Power I/O Schematic Diagram68
- Interconnection Diagram70
- Waveforms71
Schematic Diagrams72
Waveforms72
Mechanical Exploded View73
- Mechanical Replacement Parts List76
- Electrical Replacement Parts List78
