ELECTRICAL REPLACEMENT PARTS LIST
CP7201 9JD06G3VWT01A CONNECTOR PCB SIDE 20389-Y30E
SH4301 9JD126D000044 TERMINAL PIN YQ-36
SH4302 9JD126D000044 TERMINAL PIN YQ-36
SH4303 9JD126D000044 TERMINAL PIN YQ-36
SH4304 9JD126D000044 TERMINAL PIN YQ-36
SH4305 9JD126D000044 TERMINAL PIN YQ-36
SH4306 9JD126D000044 TERMINAL PIN YQ-36
SH4307 9JD126D000044 TERMINAL PIN YQ-36
POWER PCB ASS'Y
*** PCB ***
PCB240 9JDA31Z01E240L POWER PCB ASS'Y CEF273A
*** RESISTORS ***
! R403 9JDR3X28BR22J R,METAL OXIDE 0.22 OHM 3W
! R406 9JDR3K681S22J R,METAL OXIDE 0.022 OHM 1W
! R412 9JDR63881R22J R,FUSE 0.22 OHM 1W
! R416 9JDR655842R2J R,FUSE 2.2 OHM 1/4W
! R466 9JDR5X2AD151J R,CEMENT 150 OHM 5W
! R494 9JDR3K78A681J R,METAL OXIDE 680 OHM 2W
! R497 9JDR65581010J R,FUSE 1 OHM 1W or
! R497 9JDR63881010J R,FUSE 1 OHM 1W
! R533 9JDR3X28B473J R,METAL OXIDE 47K OHM 3W
*** CAPACITORS ***
! C402 9JDP2122B334M CMP 0.33 UF 275V ECQUL
! C405 9JDE71LHH331D CE 330 UF 400V or
! C405 9JDE77CHH331M CE 330 UF 400V
! C406 9JDCD39E0M13M CC 0.001 UF 250V
C422 9JDE7EY78101D CE 100 UF 100V
! C423 9JDP4NAE6823H CMPP 0.082 UF 800V
! C424 9JDE8E6FH220M CE 22 UF 400V
! C427 9JDCD39B0MQ2K CC 470 PF 250V
! C433 9JDE7EYF4471M CE 470 UF 35V
! C434 9JDE7EYF4102M CE 1000 UF 35V
! C435 9JDE7EYF3102M CE 1000 UF 25V
! C436 9JDCD39E0M13M CC 0.001 UF 250V
! C438 9JDE7EYF4102M CE 1000 UF 35V
! C440 9JDE7EYF0222M CE 2200 UF 6.3V
! C441 9JDE7ESU5100M CE 10 UF 50V
! C444 9JDE7ESU0221M CE 220 UF 6.3V
! C448 9JDP2122B104M CMP 0.1 UF 275V ECQUL
C449 9JDE7EYF2102M CE 1000 UF 16V
C453 9JDE7EYF2102M CE 1000 UF 16V
! C463 9JDCD39B0MQ2K CC 470 PF 250V
C466 9JDE7EYF4471M CE 470 UF 35V
! C475 9JDP4NAE6823H CMPP 0.082 UF 800V
*** DIODES ***
D401 9JDD4AT01H3E0 DIODE RECTIFIER 1H3-E
! D404 9JDD6C047110A DIODE VARISTA ENE471D-10A
D406 9JDD28R1QS040 DIODE EC31QS04-TE12L
D407 9JDD28R1QS040 DIODE EC31QS04-TE12L or
D407 9JDD4CRSK34A0 DIODE SCHOTTKY SK34A
! D408 9JDD2Z05SB800 DIODE,BRIDGE D5SB80
D411 9JDDGERMA1110 DIODE SILICON MA111-(TX) or
D411 9JDDD7R0S3550 DIODE SILICON 1SS355 TE-17
D412 9JDD97U03R91B DIODE,ZENER MTZJ3.9B T-77
D413 9JDDGERMA1110 DIODE SILICON MA111-(TX) or
D413 9JDDD7R0S3550 DIODE SILICON 1SS355 TE-17
D414 9JDDGERMA1110 DIODE SILICON MA111-(TX) or
D414 9JDDD7R0S3550 DIODE SILICON 1SS355 TE-17
D415 9JDDE7RB3R92B DIODE ZENER UDZS3.9B TE-17
D416 9JDD97U02001B DIODE,ZENER MTZJ20B T-77
D419 9JDDD7R0S3550 DIODE SILICON 1SS355 TE-17
D420 9JDDD7R0S3550 DIODE SILICON 1SS355 TE-17
K2-9
