Sharp LC-26D43U - Page 11

11
LC-26D43U
5. Remove the 4 lock screws and detach the Vesa Angle.
6. Remove the 2 lock screws and detach the Stand Angle-B.
7. Remove the 2 lock screws and detach the Stand Cover.
8.Remove the 2 lock screws and detach the LCD ANG -DOWN.
9.Remove the 9 lock screws and detach the Main PWB Shield.
7
6
8
Stand Cover
Stand Angle-B
LCD ANG-DOWN
5
5
MAIN PWB Shield
9
Vesa Angle
