12
LC-26D43U
10.Disconnect all the connectors from all the PWBs.
11.Remove the 2 screws and detach the Top Cover Ass’y.
12.Remove the 2 lock screws from the Top Cover Ass’y and detach the KEY Unit.
12
11
KEY Unit
Top Cover Ass'y
KM
