21
LC-26D43U
3.White balance adjustment
1 Setting For detailed adjustment procedure refer to "Kameyama Model Integral WB Adjustment
Specifications V1.4".
1) Make the following settings for the set.
AV MODE: [DYNAMIC]
Backlight: +16
Aging time: Min. 60 minutes
2) Connect the white balance adjustment tool to the set.
2 Automatic adjust-
ment execution
[Command]
Process mode
KRSW0001
KKT10037
Setting
KYOF0000
OSDS0001
SBSL0016
Multi-point adjustment
MSET0001
Adjustment value
MSET0004
Point 6
WBI60928
MG6G****
MG6B****
MG6R****
Point 5
WBI50800
MG5G****
MG5B****
MG5R****
[Adjustment prcedure]
1) Using the remote controller,transmit the "monitor adjustment process" code.
2) Set the 6
th
point to the specified gradation level,With the strongest color being fixed, ,
turn down the R,G and B settings to their reference levels.
3) Set the 5
th
point to the specified gradation level.
Correct the G setting (800 x 6th point G setting /928) (rounded off), and make the R
and B settings to their reference levels.
4)
5)
6)
7)
8) With the MSET0003 command, write the adjustment values and turn off the AC
power.
* Initial R, G and B settings at point 6: Gradation level set at 928
* Initial R, G and B settings at points 1 thru 5:Correct the setting same remainder of
RGB setting at each point (This is because the adjustment is made to achieve the
same remainder of RGB setting/4 at each point. )
[Adjustment value]
As per the "standard set" submitted by Engineering Department
[LC-26D43U] Teaching Set.
[Adjustment reference] Instrument:[Minolta CA-210] Engineering instrument
Point 4
Level Reference Adj. spec Ins. spec
WBI40480
Point 6 928 X=0.272 ±0.0012 ±0.0020
MG4G****
MG4B****
Point 5 800 X=0.272 ±0.0012 ±0.0020
MG4R****
Point 4 480 X=0.272 ±0.0012 ±0.0020
Point 3
WBI30336
Point 3 366 X=0.272 ±0.0012 ±0.0020
MG3G****
MG3B****
Point 2 288 X=0.272 ±0.0020 ±0.0030
MG3R****
Point 1 184 X=0.272 ±0.0035 ±0.0045
Point 2
WBI20288
MG2G****
MG2B****
MG2R****
Note Set conditions for inspection
AV MODE: [DYNAMIC] (Reset)
Monochro: ON
Aging Time: Min. 60 minutes
Point 1
WBI10184
MG1G****
MG1B****
MG1R****
Writing
MSET0003
initialization
Adjustment item
Adjustment conditions
Adjustment procedure
Set the 4
th
point to the specified gradation level.
Correct the G setting (480 x 6th point G setting /928) (rounded off), and make the R
and B settings to their reference levels.
Set the 3rd point to the specified gradation level.
Correct the G setting (366 x 6th point G setting /928) (rounded off), and make the R
and B settings to their reference levels.
Set the 2nd point to the specified gradation level.
Correct the G setting (288 x 6th point G setting /928) (rounded off), and make the R
and B settings to their reference levels.
Set the 1
st
point to the specified gradation level.
Correct the G setting (184 x 6th point G setting /928) (rounded off), and make the R
and B settings to their reference levels.
y=0.277
y=0.277
y=0.277
y=0.277
y=0.277
y=0.277
