WAVEFORMS

21PIN 21PIN

V/DVD_INTERFACE

10us 10us 20us

0.5V 0.2V 0.2V

1713

AV/DVD_INTERFACE

10us 10us 500us

0.2V 0.2V 0.2V

2814

10us 500us 500us

0.2V 0.2V 0.2V

3915

10us 500us 2ms

0.2V 0.2V 100mV

41016

500us 20us 2ms

0.2V 0.2V 100mV

51117

SOUND AMP/AUDIO DAC

500us 20us 2ms

0.2V 0.2V 100mV

61218

The following waveforms were measured at the poi

of the corresponding balloon number in the

schematic diagram.

NOTE:

I-1
