TROUBLESHOOTING GUIDE
(DVD SECTION)
DOES NOT DISPLAY DVD
Does this display
logo picture?
Does IC4001 gets
P.CON+3.3V and
P.CON+1.8V?
Check P.CON+3.3V and
P.CON+1.8V line.
Check pins 8 and 10 of
CP8501 and peripheral circuit.
Yes
No
Yes
No
Change IC4001.
Check the disc.
Yes
No
Is there signal
at pins 149 and 151
of IC4001?
E-5
33
35
Table of Contents
Service Manual
1
Table of Contents
1
Caution
2
Important Safeguards
3
When Replacing DVD Deck
6
Disc Removal Method at no Power Supply
7
ABOUT LEAD FREE SOLDER (Pbf)
8
General Specifications
9
Disassembly Instructions
16
Remove the
16
Disassembly Instructions
17
3 Remove the
18
2 Remove the
20
Service Mode List
22
Re-Write for DVD Firmware
23
Servicing Fixtures and Tools
23
Re-Write for Digital Soft Firmware
24
When Replacing Eeprom (Memory) IC
25
Electrical Adjustments
26
Troubleshooting Guide
30
DVD Block Diagram
39
Power Block Diagram
40
Printed Circuit Boards
43
H-1~H
72
Waveforms
73
Mechanical Exploded Views
76
DVD Deck Exploded View
78
Angle
79
DVD Deck Replacement Parts List
80
