WAVEFORMS
FLASH MICON
20ns 20ns 10us
200mV 200mV 100mV
1 7 13
TUNER
20ns 10us 10us
200mV 0.5V 100mV
2 8 14
HDMI SCALER VIDEO/AUDIO AV SWITCH 2
20ns 20us 2ms
200mV 500mV 100mV
3 9 15
JACK 3
0.2us 20us 2ms
200mV 500mV 100mV
4 10 16
SOUND
2ms 10us 1ms
500mV 0.5V 200mV
5 11 17
2ms 10us 1ms
500mV 200mV 200mV
6 12 18
The following waveforms were measured
at the point of the corresponding balloon
number in the schematic diagram.
NOTE:
I-1
