ELECTRICAL REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION
REMOCON PCB ASS'Y
*** PCB ***
PCBDA0 A50Q01PDA0 REMOCON PCB ASS'Y CEG359A
*** DIODES ***
D2201 0021E9Q010 LED LTL-1BEFJ-002A
*** CONNECTORS ***
CP2201 069S250639 CONNECTOR PCB SIDE A2001WR2-5P
*** OTHERS ***
OS2201 077A033001 REMOTE RECEIVER ROM-V338TAO
DIGITAL PCB ASS'Y
*** PCB ***
PCBDH0 A50Q01PDH0 DIGITAL PCB ASS'Y CEG352A
*** RESISTORS ***
!
R3019 R808R9333J RC 33K OHM 1/16W
*** DIODES ***
D3004 D28R1QS040 DIODE EC31QS04-TE12L
D3401 DGERMA1110 DIODE SILICON MA111-(TX)
D3405 DGERMA1110 DIODE SILICON MA111-(TX)
D3406 DGERMA1110 DIODE SILICON MA111-(TX)
D3604 D77R1A1R10 DIODE VARISTA AVRL161A1R1NT
D3605 D77R1A1R10 DIODE VARISTA AVRL161A1R1NT
D3607 DDLRS160T0 DIODE SCHOTTKY BARRIER SS160-T
D3610 DGJRT54WS0 DIODE SCHOTTKY BARRIER BAT54WS
D6201 DE7RB5R62B DIODE ZENER UDZSNP5.6B TE-17
D6202 DE7RB5R62B DIODE ZENER UDZSNP5.6B TE-17
D6205 DGJRT54WS0 DIODE SCHOTTKY BARRIER BAT54WS
*** ICS ***
IC2801 I56M069540 SCALER R8J66954BG
IC2802 IGGM061600 256MB DDR2 SDRAM HYB18TC256160BF-3S
IC2804 S50Q01PF01 MEMORY DATA 32MBIT FLASH 48PIN TSOP EN29LV320AB-70TCP
IC2805 S50Q01PE01 MEMORY DATA EEPROM 256KBIT SO8 M24256-BWMN6TP
!
IC3001 I07F091300 1CH DC-DC CONVERTER BD9130NV
!
IC3002 I1LF010150 DC-DC CONVERTER CONTROLLER AL1015
!
IC3003 I0GF95ZN10 VO=0.8-3.5V I=1.5A TAPING PQ035ZN1HZPH
IC3004 TJ5MC61080 FET TPC6108(TE85L,F,M)
IC3601 S50Q01PE02 MEMORY DATA EEPROM 2K SOP8 S-24CS02AFJ-TB-GE
IC3603 I0WF0002A0 2IN1_HDMI_SW_IC STHDMI002ABTR
IC5801 I01FF58320 USA STEREO AN5832SA-E1V
IC6201 I9UF032290 RESET IC 2.9V TYPE PST3229NR
IC6202 S34L01PM01
MEMORY DATA FLASH MICOM ROM16K 2KX2 RAM1 R5F21124FP
IC6551 IC1J053580 A/D CONVERTER AK5358A
IC6552 I0QF02534V A/V SW 3INPUT 1OUTPUT NJM2534V(TE2)
IC6553 I0QF02534V A/V SW 3INPUT 1OUTPUT NJM2534V(TE2)
IC6554 I0UF015010 A/V SW 2INPUT 1OUTPUT MM1501XNRE
IC6555 I0UF015010 A/V SW 2INPUT 1OUTPUT MM1501XNRE
IC6556 I5CJ031570 A/V SW 2INPUT 1OUTPUT SN74LVC1G3157DCKR
K3-1
To Next Page
