Sharp LC-26SA1E - DUNTKD604 FM12;FM13 (AV Unit) (LC-26 SA1 E;RU, LC-32 SA1 E;RU); Lcd Panel and Tuner; Independently.); Printed Wiring Board Assemblies (Not Replacement Item)

LC-26SA1E/RU, LC-32SA1E/RU
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES (NOT REPLACEMENT ITEM)
N DUNTKD604FM12 N J AV Unit (LC-26SA1E/F/I/K/RU)
N DUNTKD604FM13 N J AV Unit (LC-32SA1E/F/I/K/RU)
N DUNTKD605FM10 N J POWER Unit (LC-26SA1E/F/I/K/RU)
N DUNTKD605FM11 N J POWER Unit (LC-32SA1E/F/I/K/RU)
N DUNTKD606FMV0 N J OPERATION Unit
N DUNTKD607FMV0 N J R/C,LED Unit
N DUNTKD608FM06 N J TUNER Unit (LC-26SA1E/F/I/K/RU)
N DUNTKD608FM07 N J TUNER Unit (LC-32SA1E/F/I/K/RU)
N DUNTKD890FM12 N J MAIN Unit (LC-26SA1E/F/I/K/RU)
N DUNTKD890FM13 N J MAIN Unit (LC-32SA1E/F/I/K/RU)
[2] LCD PANEL AND TUNER(NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT
INDEPENDENTLY.)
N R1LK260T3LF14 N J 26V LCD Panel Module Unit (LC-26SA1E/RU)
N R1LK315T3LF14 N J 32V LCD Panel Module Unit (LC-32SA1E/RU)
!
TU201 RTUNQA021WJZZ AW J U/V Tuner
[3] DUNTKD604FM12/FM13 (AV Unit) (LC-26SA1E/RU, LC-32SA1E/RU)
C301 VCKYCY1CB273KY AB J Capacitor, 0.027 16V Ceramic
C302 VCKYCY1CB273KY AB J Capacitor, 0.027 16V Ceramic
C303 VCKYCY1HF224ZY AA J Capacitor, 0.22 50V Ceramic
C304 VCKYCY1HF224ZY AA J Capacitor, 0.22 50V Ceramic
C305 VCKYCY1HB104KY AA J Capacitor, 0.1 50V Ceramic
C306 VCEASX1HN225MY AB J Capacitor, 2.2 50V Electrolytic
C307 VCEASX1HN225MY AB J Capacitor, 2.2 50V Electrolytic
C308 VCKYCY1HB104KY AA J Capacitor, 0.1 50V Ceramic
C309 VCKYCY1HB222KY AA J Capacitor, 2200p 50V Ceramic
C310 VCKYCY1HB222KY AA J Capacitor, 2200p 50V Ceramic
C311 VCEASX1CN226MY AC J Capacitor, 22 16V Electrolytic
C312 VCKYCY1HB222KY AA J Capacitor, 2200p 50V Ceramic
C313 VCKYCY1HB222KY AA J Capacitor, 2200p 50V Ceramic
C314 VCKYCY1HB153KY AA J Capacitor, 0.015 50V Ceramic
C315 VCKYCY1HB153KY AA J Capacitor, 0.015 50V Ceramic
C316 VCCCCY1HH330JY AA J Capacitor, 33p 50V Ceramic
C317 VCCCCY1HH330JY AA J Capacitor, 33p 50V Ceramic
C318 VCCCCY1HH470JY AA J Capacitor, 47p 50V Ceramic
C319 VCCCCY1HH470JY AA J Capacitor, 47p 50V Ceramic
C320 VCEASX1HN225MY AB J Capacitor, 2.2 50V Electrolytic
C321 VCEASX1HN225MY AB J Capacitor, 2.2 50V Electrolytic
C322 VCKYCY1HF224ZY AA J Capacitor, 0.22 50V Ceramic
C323 VCKYCY1HF224ZY AA J Capacitor, 0.22 50V Ceramic
C324 VCEASX1HN106MY AC J Capacitor, 10 50V Electrolytic
C325 VCEASX1HN106MY AC J Capacitor, 10 50V Electrolytic
C326 VCKYCY1HB153KY AA J Capacitor, 0.015 50V Ceramic
C327 VCKYCY1HB153KY AA J Capacitor, 0.015 50V Ceramic
C328 VCEASX1HN225MY AB J Capacitor, 2.2 50V Electrolytic
C329 VCEASX1HN225MY AB J Capacitor, 2.2 50V Electrolytic
C330 VCESYA1VM477M+ N J Capacitor, 470 35V Electrolytic
C331 VCESYA1VM477M+ N J Capacitor, 470 35V Electrolytic
C332 VCKYCY1HB221KY AA J Capacitor, 220p 50V Ceramic
C333 VCKYCY1HB221KY AA J Capacitor, 220p 50V Ceramic
C334 VCKYCY1HB221KY AA J Capacitor, 220p 50V Ceramic
C335 V
CKYCY1HB221KY AA J Capacitor, 220p 50V Ceramic
C336 VCEASX1HN105MY AB J Capacitor, 1 50V Electrolytic
C337 VCEASX1HN105MY AB J Capacitor, 1 50V Electrolytic
C338 RC-EZA513WJZZ AH J Capacitor, 470 50V Electrolytic
C339 RC-EZA513WJZZ AH J Capacitor, 470 50V Electrolytic
C340 VCKYTV1EB224KY AA J Capacitor, 0.22 25V Ceramic
C341 VCKYTV1EB224KY AA J Capacitor, 0.22 25V Ceramic
C342 VCFYFA1HA334J+ AB J Capacitor, 0.33 50V
C343 VCFYFA1HA334J+ AB J Capacitor, 0.33 50V
C344 VCEASX1HN105MY AB J Capacitor, 1 50V Electrolytic
C345 VCEASX1HN105MY AB J Capacitor, 1 50V Electrolytic
C346 VCEASX1HN105MY AB J Capacitor, 1 50V Electrolytic
C347 VCEASX1HN105MY AB J Capacitor, 1 50V Electrolytic
C348 VCEASX1VN226MY AC J Capacitor, 22 35V Electrolytic
C349 VCEASX1VN226MY AC J Capacitor, 22 35V Electrolytic
C350 VCKYCY1HB103KY AA J Capacitor, 0.01 50V Ceramic
C351 VCKYCY1HB103KY AA J Capacitor, 0.01 50V Ceramic
C352 VCKYCY1HB103KY AA J Capacitor, 0.01 50V Ceramic
C353 VCKYCY1HB103KY AA J Capacitor, 0.01 50V Ceramic
C354 VCKYCY1HB102KY AA J Capacitor, 1000p 50V Ceramic
C355 VCKYCY1HB102KY AA J Capacitor, 1000p 50V Ceramic
C356 VCEASY1HN476MY AD J Capacitor, 47 50V Electrolytic
C357 VCEASY1HN476MY AD J Capacitor, 47 50V Electrolytic
C358 VCEASX1HN106MY AC J Capacitor, 10 50V Electrolytic
C359 VCEASX1HN106MY AC J Capacitor, 10 50V Electrolytic
C360 VCEASY1CN476MY AC J Capacitor, 47 16V Electrolytic
C361 RC-KZA073WJZZY AD J Capacitor, 10 16V Ceramic
C362 VCKYTV1EB224KY AA J Capacitor, 0.22 25V Ceramic
C363 VCKYTV1EB224KY AA J Capacitor, 0.22 25V Ceramic
C364 VCEASY1CN477MY AD J Capacitor, 470 16V Electrolytic
C365 VCKYCY1HB222KY AA J Capacitor, 2200p 50V Ceramic
C366 VCKYCY1HB222KY AA J Capacitor, 2200p 50V Ceramic
