Sharp LC-26SA1E Service Manual

LC-26SA1E/RU, LC-32SA1E/RU
4
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
D314 RH-EXA101WJZZY AB J Zener Diode, UDZSTE-1730B
D315 RH-EXA101WJZZY AB J Zener Diode, UDZSTE-1730B
D316 RH-EXA101WJZZY AB J Zener Diode, UDZSTE-1730B
D317 RH-EXA101WJZZY AB J Zener Diode, UDZSTE-1730B
D318 VHD1SS390++-1Y AB J Diode, 1SS390TE61
D1101 RH-EX1068CEZZY J Zener Diode, EX1068CE
D1102 RH-EX1026CEZZY J Zener Diode, 3.9V
D1103 RH-EX1026CEZZY J Zener Diode, 3.9V
D1104 RH-EX1068CEZZY J Zener Diode, EX1068CE
D1105 RH-EX1064CEZZY J Zener Diode, EX1064CE
D1106 RH-EX1034CEZZY J Zener Diode, EX1034CE
D1107 RH-EX1034CEZZY J Zener Diode, EX1034CE
D1108 RH-EX1064CEZZY J Zener Diode, EX1064CE
D1109 RH-EX1049CEZZY J Zener Diode, EX1049CE
D1110 RH-EX1049CEZZY J Zener Diode, EX1049CE
D1111 RH-EX1049CEZZY J Zener Diode, EX1049CE
D1112 RH-EX1049CEZZY J Zener Diode, EX1049CE
D1113 RH-EX1034CEZZY J Zener Diode, EX1034CE
D1114 RH-EX1034CEZZY J Zener Diode, EX1034CE
D1115 RH-EX1034CEZZY J Zener Diode, EX1034CE
D1116 RH-EX1034CEZZY J Zener Diode, EX1034CE
D1117 RH-EX1034CEZZY J Zener Diode, EX1034CE
D1118 RH-EX1026CEZZY J Zener Diode, 3.9V
D1119 RH-EX1026CEZZY J Zener Diode, 3.9V
D1120 RH-EX1026CEZZY J Zener Diode, 3.9V
D1121 RH-EX1026CEZZY J Zener Diode, 3.9V
D1122 RH-EX1026CEZZY J Zener Diode, 3.9V
D1123 RH-EX1026CEZZY J Zener Diode, 3.9V
D1201 RH-EX1239CEZZY AB J Zener Diode, , EX1239CE
FB1101 RBLN-A345WJZZY N J Balun, BLN-A345WJ
FB1102 RBLN-A345WJZZY N J Balun, BLN-A345WJ
FB1103 RBLN-A074WJZZY N J Balun, BLN-A074WJ
FB1104 RBLN-A074WJZZY N J Balun, BLN-A074WJ
FB1105 RBLN-A073WJZZY AA N J
Balun, BLN-A073WJ
FB1106 R
BLN-A345WJZZY N J Balun, BLN-A345WJ
FB1107 RBLN-A073WJZZY AA N J Balun, BLN-A073WJ
FB1108 RBLN-A345WJZZY N J Balun, BLN-A345WJ
FB1109 RBLN-A345WJZZY N J Balun, BLN-A345WJ
FB1110 RBLN-A345WJZZY N J Balun, BLN-A345WJ
FB1111 RBLN-A073WJZZY AA N J Balun, BLN-A073WJ
FB1112 RBLN-A073WJZZY AA N J Balun, BLN-A073WJ
FB1201 RBLN-A073WJZZY AA N J Balun, BLN-A073WJ
FB1202 RBLN-A073WJZZY AA N J Balun, BLN-A073WJ
FB1203 RBLN-A345WJZZY N J Balun, BLN-A345WJ
FB1204 RBLN-A345WJZZY N J Balun, BLN-A345WJ
FB1213 RBLN-A215WJZZY AB N J Balun, BLN-A215WJ
FB1218 RBLN-A192WJZZY AA N J Balun, BLN-A192WJ
FL1101 RFILN0017TAZZY AC J Filter
FL1102 RFILN0017TAZZY AC J Filter
FL1103 RFILN0017TAZZY AC J Filter
FL1104 RFILN0017TAZZY AC J Filter
FL1105 RFILN0017TAZZY AC J Filter
FL1106 RFILN0017TAZZY AC J Filter
FL1107 RFILN0017TAZZY AC J Filter
FL1108 RFILN0017TAZZY AC J Filter
FL1109 RFILN0017TAZZY AC J Filter
FL1110 RFILN0017TAZZY AC J Filter
FL1211 RFILN0017TAZZY AC J Filter
FL1212 RFILN0017TAZZY AC J Filter
IC301 VHITDA8931T-1Y AS N J IC, TDA8931T/N1,118
IC302 VHITDA8931T-1Y AS N J IC, TDA8931T/N1,118
IC303 VHINJM4558M-1Y AD J IC, NJM4558M-TE1
IC1101 VHIMM1506XN-1Y AD J IC, MM1506XNRE
IC1102 VHIMM1506XN-1Y AD J IC, MM1506XNRE
IC1201 VHIMM1507XN-1Y AD J IC, MM1507XNRE
J1101 QSOCZA116WJZZ AK N J Socket
J1201 QJAKZA033WJZZ AK N J Jack, 16Pin
J1301
QJAKJA007WJZZ AD J Jack,
Headphone Out
L301 RCILPA386WJZZ AF J Coil, Peaking 47µH
L302 RCILPA386WJZZ AF J Coil, Peaking 47µH
LUG301 QLUGHA009WJZZY AC J Lug
LUG302 QLUGHA009WJZZY AC J Lug
LUG303 QLUGHA009WJZZY AC J Lug
LUG304 QLUGHA009WJZZY AC J Lug
P301 QPLGNA173WJZZY AD J Plug, 4PIN(SP)
P1101 QCNCMA250WJZZ AE J Connector, 23Pin
P1102 QCNCMA250WJZZ AE J Connector, 23Pin
P1201 QCNCMA250WJZZ AE J Connector, 23Pin
Q301 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q302 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q303 VSDTC314TK/-1Y AC J Transistor, DTC314TKT146
Q304 VSDTC314TK/-1Y AC J Transistor, DTC314TKT146
Q307 VS2SA1530AR-1Y AB J Transistor, 2SA1530A-T112-1R
Q1101 VSDTC314TK/-1Y AC J Transistor, DTC314TKT146
Q1102 VSDTC314TK/-1Y AC J Transistor, DTC314TKT146
[3] DUNTKD604FM12/FM13 (AV Unit) (LC-26SA1E/RU, LC-32SA1E/RU)
