Sharp LC-26SA1E Service Manual

LC-26SA1E/RU, LC-32SA1E/RU
14
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
FB2306 RBLN-A068WJZZY AB J Balun, BLN-A068WJ
FB2307 RBLN-A068WJZZY AB J Balun, BLN-A068WJ
FB2308 RBLN-A068WJZZY AB J Balun, BLN-A068WJ
FB2309 RBLN-A068WJZZY AB J Balun, BLN-A068WJ
FB2310 RBLN-A215WJZZY AB J Balun, BLN-A215WJ
FB2701 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB2702 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB2703 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB2704 RBLN-A068WJZZY AB J Balun, BLN-A068WJ
FB2705 RBLN-A068WJZZY AB J Balun, BLN-A068WJ
FB2706 RBLN-A068WJZZY AB J Balun, BLN-A068WJ
FB2707 RBLN-A068WJZZY AB J Balun, BLN-A068WJ
FB2708 RBLN-A068WJZZY AB J Balun, BLN-A068WJ
FB2709 RBLN-A068WJZZY AB J Balun, BLN-A068WJ
FB2710 RBLN-A068WJZZY AB J Balun, BLN-A068WJ
FB2711 RBLN-A068WJZZY AB J Balun, BLN-A068WJ
FB2715 RBLN-A215WJZZY AB J Balun, BLN-A215WJ
FB3001 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB3002 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB3003 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB3004 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB3005 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB3006 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB3007 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB3008 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB3009 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB3010 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB3011 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB3012 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB3013 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB3014 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB3015 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB3016 RBLN-A192WJZZY AA J Balun, BLN-A192WJ
FB3018 RBLN-A192WJZZY AA J
Balun, BLN-A192WJ
FB3020 R
BLN-A192WJZZY AA J Balun, BLN-A192WJ
FB3307 RBLN-A068WJZZY AB J Balun, BLN-A068WJ
FB3308 RBLN-A068WJZZY AB J Balun, BLN-A068WJ
FL2301 RFILN0003TAZZY AD J Filter
FL2302 RFILN0003TAZZY AD J Filter
FL2303 RFILN0003TAZZY AD J Filter
IC1701 VHIBU4239G+-1Y AE J IC, BU4239G-TR
IC1702 VHIPQ20WZ11-1Y AF J IC, PQ20WZ1UJ00H
IC1703 VHIPQ20WZ11-1Y AF J IC, PQ20WZ1UJ00H
IC1704 VSSSM6J57TU-1Y AF J FET
IC1704 VSSSM6J57TU-1Y AF J FET
IC1706 VHIMP1410ES-1Y AP J IC, MP1410ES-LF-Z
IC1707 VHIPQ20WZ11-1Y AF J IC, PQ20WZ1UJ00H
IC1708 VHIMP1410ES-1Y AP J IC, MP1410ES-LF-Z
IC1710 RH-IXB823WJZZQ AR N J IC, EPM240T100C5N
IC1901 VHI24LC2BINEES AH J IC, 24LC02BT-I/SN
IC1905 VHISII9021+-1Q BC J IC, SII9021CTU
IC2301 VHIISL83220-1Y AQ J IC, ISL83220ECVZ-T
IC2303 RH-IXB731WJZZS AH J IC, EEPROM
IC2701 VHITVHC153T-1Y AE J IC, TC74VHC153FT(EL,M)
IC2702 VHIMM1507XN-1Y AD J IC, MM1507XNRE
IC2704 VHICD4052BP-1Y AD J IC, CD4052BPWR
IC3001 VHIBR24L64F-1Y AK J IC, BR24L64F-WE2
IC3002 RH-IXB624WJN1Q BR J IC, VCT6973G-FA-B3
IC3003 RH-IXB664WJZZY AY N J IC, PIC16F913-I/SS-G-GW902T
IC3005 VHIBU4215G+-1Y AE J IC, BU4215G-TR
J2701 QJAKEA073WJZZ AD J Jack, HDMI INPUT
J2702 QJAKEA073WJZZ AD J Jack, RGB INPUT
L1701 RCILPA213WJZZY AG J Coil, Peaking 15µH
L1702 RCILPA213WJZZY AG J Coil, Peaking 15µH
L1901 RCILFA134WJZZY AF J Coil
L1902 RCILFA134WJZZY AF J Coil
L1903 R
CILFA134WJZZY AF J Coil
L1904 RCILFA134WJZZY AF J Coil
L2301 RCILFA071WJZZY AD J Coil
L2302 RCILFA071WJZZY AD J Coil
L2303 RCILFA071WJZZY AD J Coil
L2304 RCILFA071WJZZY AD J Coil
L2305 RCILFA071WJZZY AD J Coil
LUG1701 QLUGHA006WJZZY AC J Lug
LUG1702 QLUGHA006WJZZY AC J Lug
LUG1703 QLUGHA006WJZZY AC J Lug
LUG1704 QLUGHA006WJZZY AC J Lug
LUG1705 QLUGZA002WJZZY AC J Lug
LUG1706 QLUGZA002WJZZY AC J Lug
LUG1707 QLUGZA002WJZZY AC J Lug
LUG1708 QLUGZA002WJZZY AC J Lug
LUG1709 QLUGZA002WJZZY AC J Lug
P1702 QPLGN1075TAZZY AD J Plug, 10Pin
P2301 QPLGNA341WJZZY AD J Plug, 7Pin(SH)
P2302 QPLGNA337WJZZY AC J Plug, 3Pin(KM)
[8] DUNTKD890FM12/FM13 (MAIN Unit) (LC-26SA1E/RU, LC-32SA1E/RU)
