LC-26SA1E/RU, LC-32SA1E/RU
19
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[9] CABINET PARTS (LC-26SA1E/F/I/K/RU)
1 CCABAB517WJ01 N Front Cabinet Ass'y
1-1 Not Available - N - Front Cabinet
1-2 GCOVAB810WJSA N LED Cover
1-3 HBDGBA056WJSA J SHARP Badge
1-4 PSPAHA890WJZZ N Mask Spacer (Side), x2
1-5 PSPAHA891WJZZ N Mask Spacer (T-B), x2
1-6 PSPAZB212WJZZ Speaker Cusion, x2
2 CCABBA894WJ01 N Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 LHLDWA055WJKZ AC J Wire Holder
2-3 PSPAHA892WJZZ N Spacer, x2
2-4 PSPAHA893WJZZ N Spacer, x3
3 CCOVAB808WJ01 N Top Control Cover Ass'y
3-1 Not Available - N - Top Control Cover
3-2 JBTN-A595WJKA N J Button, Power
3-3 JBTN-A596WJKA N J Button, Operation
3-4 MSPRCA068WJFW J Spring
3-6 XEBS930P08000 AA J Screw, x2
4 CDAI-A307WJ02 Stand Ass'y
4-1 CDAI-A307WJ01 Stand Base Ass'y
4-1-1 GDAI-A307WJKA N Base Cover
4-1-2 LANGKA813WJFW N Base Angle
4-1-3 PSPAZB214WJZZ N Leg Cushion A, x3
4-1-4 PSPAZB215WJZZ N Leg Cushion B, x4
4-1-5 XEBS740P10000 N Screw, x8
4-2 CDAI-A308WJ01 Stand Support Ass'y
4-2-1 GDAI-A308WJSA N Stand Support
4-2-2 GCOVAB811WJSA N Support Cover
4-2-3 HDECQA671WJSA N Screw Guide, x4
4-3 LX-BZA146WJF7 AC N J Screw, x4 (for Stand)
4-4 LX-BZA147WJF8 AE N J Screw, x4 (for Stand)
5 R1LK260T3LF14 N J 26V LCD Panel Module Unit
6 DUNTKD890FM12 N J MAIN Unit
7 DUNTKD604FM12 N J
AV Unit
8 D
UNTKD605FM10 N J POWER Unit
9 DUNTKD606FMV0 N J OPERATION Unit
10 DUNTKD607FMV0 N J R/C,LED Unit
11 DUNTKD608FM06 N J TUNER Unit
12 GCOVAB809WJKA N Bottom Cover
13 HINDPB883WJSA N Model Label (26SA1E/F/K)
13 HINDPB884WJSA N Model Label (26SA1I)
13 HINDPB885WJSA N Model Label (26SA1RU)
14 LANGKA812WJFW N LCD Angle
15 LANGTA367WJFW N Center Angle
17 LANGTA370WJFW N Stand Angle
18 LCHSMA321WJZZ N J Chassis Tray
20 LHLDW1205CEZZ AC N J Wire Holder, x2
21 LHLDWA032WJZZ AD J Wire Holder, x2
22 LHLDWA055WJKZ AC N J Wire Holder
23 PMLT-A315WJZZ AP N J Absorber, x2
24 PSLDMA974WJFW AG N J Main Shield New
25 QCNW-E877WJQZ N J Connecting Cord, (SH)
26 QCNW-E878WJQZ N J Connecting Cord, (LA)
27 QCNW-F023WJPZ J Connecting Cord, (LV)
28 QEARPA212WJFW AE N J Earth Plate A
29 QEARZA096WJFW N J Tuner Earth Plate
30 XBBS740P06000 AA J Screw, x8 (LCD Angle/LCD)
31 XBBS930P06000 AA J Screw, x8 (Rear Cabinet/Chassis)
32 XBPS730P06WS0 AA J Screw, x6 (Center Angle)
33 XBPS830P06000 AA J Screw (HDMI)
34 XEBS930P08000 AA J Screw, x9
35 XEBS940P16000 AB J Screw, x18 (Rear Cabinet/Bottom Cover)
36 XJPS730P08WS0 AA J Screw, x12 (PWB)
37 PSPAHA995WJZZ Spacer, x2
38 PCUSGA009WJKZ Cushion
39 TLABZB264WJZZ N POP Label
40 LX-HZA003WJFN AC J Screw, x2 (for Speaker)
41
QCNW-E907WJQZ N J C
onnecting Cord, (SP)
42 QCNW-E908WJQZ N J Connecting Cord, (RA)
43 RSP-ZA184WJN1 J Speaker (L)
44 RSP-ZA184WJN2 J Speaker (R)
45 QCNW-E232WJQZ AG J Connecting Cord (KM)
