Sharp LC-26SB25S Service Manual

LC-26SB25E/S/RU, LC-32SB25E/S/RU, LC-42SB55E/S/RU
160
ZD200 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD500 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD501 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD502 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD503 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD504 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD505 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD506 093T 39GA28 T ZENER DIODE RLZ13B SEMTECH 9JR9300000052
ZD507 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD508 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD509 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD510 093T 39GA28 T ZENER DIODE RLZ13B SEMTECH 9JR9300000052
ZD511 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD512 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD513 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD550 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD551 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD552 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD553 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD554 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD555 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD556 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD557 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD558 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD559 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD560 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD561 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD562 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD563 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD650 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD651 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD652 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD653 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD654 093T 39S 34 T UDZSNP5.6B ROHM 9JR9300000015
ZD655 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD656 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD657 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD658 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD659 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD660 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD661 093T 64 37 N V-PORT-0603-100K V05 9JR9300000045
ZD702 093T 39S906 T DIODE PDZ24B SOD-323 PHILIPS 9JR9300000016
ZD704 093T 39S906 T DIODE PDZ24B SOD-323 PHILIPS 9JR9300000016
Power PCB
1054 ADTV82420PA3 POWER PCB ASSY
BD901 093T 50460 34 BRIDGE KBJ608G 6A/800V KBJ 9JR9300000040
C901 063T107K474 US X2 CAP 0.47UF K 275VAC 9JR6300000006
C902 065G306K4712B3 Y1 CAP 470pF +-10% 250VAC CD SERIES 9JR6500000111
C903 065G306K4712B3 Y1 CAP 470pF +-10% 250VAC CD SERIES 9JR6500000111
C904 063T107K474 US X2 CAP 0.47UF K 275VAC 9JR6300000006
C905 063T210K105HCJ CAP MPH 1UF 500V 10% 9JR6300000008
C906 065T306M2222B3 CER Y2 2200PF M 400VAC TDK 9JR6500000107
C907 067G 4012115L EC 120uF 450V LSG 30x25mm 9JR6700000053
C908 065T306M2222B3 CER Y2 2200PF M 400VAC TDK 9JR6500000107
C909 065T120622522K 3 CAP CHIP 2U2 25V X7R 1206 10% 9JR6500000158
C911 065T080510432K Y CAP CHIP 0805 0.1UF K 50V X7R 9JR6500000071
C912 065T080522131J Y CAP CHIP 0805 220PF J 50V NPO 9JR6500000149
C913 065T080533422K 3 CAP CHIP 0805 330N 25V X7R +/-10% 9JR6500000086
C914 065T080510522K 3 CAP CHIP 0805 1U 25V X7R +/-10% 9JR6500000145
C915 065G080510232K Y CAP CHIP 0805 1N 50V X7R +/-10% 9JR6500000110
C916 065T080510031J Y CAP CHIP 0805 10P 50V NPO +/-5% 9JR6500000143
C931 065T080533432K 3 CAP CHIP 0805 330N 50V X7R +/-10% 9JR6500000151
C932 065T080522422K 3 CAP CHIP 0805 220N 25V X7R -/+ 10% 9JR6500000150
C933 065T080522131J Y CAP CHIP 0805 220PF J 50V NPO 9JR6500000149
C934 065T080510522K 3 CAP CHIP 0805 1U 25V X7R +/-10% 9JR6500000145
C935 065T080510432K Y CAP CHIP 0805 0.1UF K 50V X7R 9JR6500000071
