Sharp LC-26SB25S Service Manual

2008-03-14
LC-26SB25E/S/RU, LC-32SB25E/S/RU, LC-42SB55E/S/RU
23
Fig.7
Fig.8
2. Remove the 5 screws and disconnect 2 cables. Detach the Power board as Fig.9.
Fig.9
3. Disconnect 1 cable. Detach the Key board as Fig.10.
Fig.10
4. Remove the 4 screws and disconnect 4 cables. Detach the Speakers as Fig.11 and Fig.12.

Sharp LC-26SB25S Specifications

General

Brand	Sharp
Model	LC-26SB25S
Category	LCD TV
Language	English
