Sharp LC-26SB25S Service Manual

LC-26SB25E/S/RU, LC-32SB25E/S/RU, LC-42SB55E/S/RU
38
Power unit operation check(for LC-32SB25 and LC-26SB25).
↓
LINE_FILTER_UNIT: ↓ YES
POWER_UNIT
↓YES
↓YES
↓YES
↓YES
A
re the power cord and harness in the unit properly connected?
NO
Connect the power cord and harness properly, and turn on the
p
ower.
Is F901 normal?
NO
LINE_FILTER_UNIT:
Isn't L901,L902,RV901,C903,C904,C901,C902, etc. out o
f
order? Moreover, whether the short-circuit with the
circumference circuit is checked.
POWER_UNIT:
BD901, RV902, IC951, etc. out of order?
Moreover, whether the short-circuit with the circumference circuit
is checked.
Is BD901 (+320V) output? (Set the main power SW to OFF.)
* When power on/off switch is on ‧‧‧ About +400V
Does the PFC circuit operate normally?
(L906, Q901, D902, D903, IC901 and etc. And, the circuit around
the protection circuit etc. is checked.)
NO
Is a voltage of +5V applied to pin (11,12) of connector (CN902)?
(Set the main power SW to OFF.)
Does the switching circuit operate normally?
Check circuit around the primary side (T901, IC931, Q931,
ZD981, ZD930, D980, D981, ZD981, etc.), the secondary side
(D935, L980, etc.), the AC_DET circuit (ZD982, IC932, IC982,
Q992, Q993, etc.), and the protection circuit.
NO
A
re +24V output as for the power on/off switch when it is on?
NO
Does the inverter circuit operate normally?
Check circuit around the primary side (T902,Q951,Q952,IC951,
D951,D952, etc.), the secondary side (D955, L971, ZD967,
IC952, IC953, etc.), the STANDBY circuit (Q988, etc.), and the
protection circuit.
Similarly, is +12V output as for the power on/off switch when it is
on?
NO
Check +12V circuit of D956, L931, etc.
