LC-32D65E/RU, LC-37D65E/RU
2 – 3
5. Remove the Speaker (L) , (R) .
6. Remove the 4 lock screws , the 3 hooks and detach the POWER/INVETER Unit.
7. Remove the 7 lock screws , the 1 lock screw and detach the MAIN Unit.
8. Remove the 1 lock screws , and detach the Control Cover Ass’y from the MAIN Unit.
1
2
3
4
5
6
POWER/
INVERTER
Unit
Speaker(R)
POWER
PWB
Holder
MAIN Unit
Control Cover Ass'y
2 Speaker(L)1
3
4
6
5
To Next Page
