Sharp LC-32DH57E-BK User Manual

LC-32DH57E-BK/RU-BK/S-BK
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKF111FM08 CB P MAIN Unit (B3KU2H57CG)
N DUNTKF115FM02 AH P LED Unit (B3KU2H57CJ)
N DUNTKF069FM05 AP P KEY Unit (B3KU2A47CK)
N DUNTKF063FM01 BH V POWER Unit
N DUNTKF071FM04 BF V INVERTER Unit
N RUNTKA561WJZZ BK N P LCD CONTROL Unit
N RUNTKA550WJZZ AR J GND PWB Unit
[2] LCD PANEL
N R1LK315T3GW40Y CQ P 32" LCD Panel Module
[3] DUNTKF111FM08 (MAIN Unit)
C501 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C502 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C503 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C507 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C508 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C510 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C520 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C521 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C522 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C523 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C524 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C525 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C526 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C527 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C528 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C529 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C530 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C531 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C532 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C533 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C534 RC-KZA510WJPZY AB J Capacitor
C535 RC-KZA510WJPZY AB J Capacitor
C536 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C537 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C538 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C539 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C540 RC-KZA510WJPZY AB J Capacitor
C541 RC-KZA510WJPZY AB J Capacitor
C542 RC-KZA510WJPZY AB J Capacitor
C543 RC-KZA510WJPZY AB J Capacitor
C544 RC-KZA510WJPZY AB J Capacitor
C545 RC-KZA510WJPZY AB J Capacitor
C546 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C547 VCCCCZ1HH560JY AB J
Capacitor 56p 50V Ceramic
C548 VCCCCZ1HH560JY AB J Capacitor 56p 50V Ceramic
C549 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C550 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C551 VCERMZ1CN477MY AE J Capacitor 470 16V Capacitor(AL)
C552 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C553 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C554 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C555 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C556 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C557 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C558 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C559 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C560 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C561 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C562 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C564 RC-KZA616WJQZY AB N J Capacitor
C565 VCKYCZ1HB472KY AA J Capacitor 4700p 50V Ceramic
C566 VCKYCZ1HB472KY AA J Capacitor 4700p 50V Ceramic
C567 VCEASX1VN226MY AC J Capacitor 22 35V Electrolytic
C568 VCEASX1VN226MY AC J Capacitor 22 35V Electrolytic
C569 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C570 RC-KZA067WJZZY AB J Capacitor
C571 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C572 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C573 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C575 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C576 RC-KZA067WJZZY AB J Capacitor
C577 RC-KZA616WJQZY AB N J Capacitor
C578 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C579 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C580 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C581 RC-KZA510WJPZY AB J Capacitor
C582 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C583
VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C584 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C585 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C586 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C587 VCCCCZ1HH330JY AB J Capacitor 33p 50V Ceramic
C588 VCCCCZ1HH330JY AB J Capacitor 33p 50V Ceramic
