2.19. IC2601, IC9601 (VHiHC2G66DP-1Y)

2.19.1 Block Diagram

2.19.2 Pin Connections and short description

2.20. IC7201 (VHiSTRY64761E)

This IC is a block diagram and description LC-32A47E/RU/V (S59Z4LC32A47E) please see the service manual.

2.21. IC7101 (VHiNCP1606B-1Y)

This IC is a block diagram and description LC-32A47E/RU/V (S59Z4LC32A47E) please see the service manual.

2.22. IC7700 (VHiBD9897FS-1Y)

This IC is a block diagram and description LC-32A47E/RU/V (S59Z4LC32A47E) please see the service manual.

Pin No. Pin Name I/O Pin Function

1 1Y I/O Independent input or output.

2 1Z I/O Independent input or output.

3 2E I Enable input (active HIGH).

4 GND — Ground

5 2Y I/O Independent input or output.

6 2Z I/O Independent input or output.

7 1E I Enable input (active HIGH).

8 VCC — Supply voltage.
